This Manual Must Always be Available to the Stove Operator
This manual must be used in
conjunction with document IN1173.
The Wood and Mutlifuel Chimney and
Installation Guide.
Installation Instructions
Rika
Cult,Eco,Fox,Jazz,
Tara,Twist,Tema
Vitra,Scena
IN1219 Edition 2 July 2011
PART NUMBER
SERIAL NUMBER
Advertisement
Table of Contents
Related Manuals for RIKA cult
Summary of Contents for RIKA cult
-
Page 1: Installation Instructions
This Manual Must Always be Available to the Stove Operator Installation Instructions Rika Cult,Eco,Fox,Jazz, Tara,Twist,Tema Vitra,Scena This manual must be used in IN1219 Edition 2 July 2011 conjunction with document IN1173. The Wood and Mutlifuel Chimney and Installation Guide. PART NUMBER... - Page 2 IMPORTANT Since April 2002 only Registered Competent Engineers may install solid fuel fired appliances without involving the Local Authority Building Control Department. For more details contact HETAS. Euroheat would suggest only Registered Competent Engineers install Euroheat appliances. If the installer is not a registered Competent Engineer we would advise that property owners insurance company is contacted to confirm their insurance is not affected.
-
Page 3: The Model Range Explained
This manual offers installation information for the range of RIKA wood stoves: Cult, Eco, Fox, Jazz, Scena, Tara, Tema ,Twist and Vitra. Although the exterior clothes change between model ranges the internal workings are very much the same. - Page 4 Flue Spigot Wood Connection deg C 83.2% Net 153mm/6” Cult RKC1 1.6 kg/h 12pa 222* 75.7% Gross 83.2% Net 153mm/6” Cult Plus RKC2 1.6 kg/h 12pa 238* 75.7% Gross 79.1% Net 153mm/6” RKE1 2.0 kg/h 10pa 72.0% Gross 79.1% Net 153mm/6”...
- Page 5 Stoves Construction The RLS control is the centre of the air inlet system. The fuel selection controls direct the air flow, either air wash or under grate. The burning rate controlled by the amount the fuel selsction control is adjusted. Top or Rear Flue Options Soapstone,...
-
Page 6: Flue Options
Changing Flue Direction The procedure for changing the flue direction is very similar for all the Rika stoves. If there is a soapstone top and sides these may have to be removed first to be able to remove the rear heat shield and top flue collar. If there are plate fins fitted to the top of the stove these will need to be removed as the new top cover plate and finns will replace these. -
Page 7: Fireplace Design
Fireplace Design Do not be tempted to fit the stove into an unsuitable fireplace. Beyond the requirements of Building Regulations and access to facilitate servicing the stove, providing a setting which will complement a stove is not a luxury, it is the practicality of making the most of an investment. A good builder or fireplace specialist will be able to transform even the most utilitarian of fireplaces. -
Page 8: Minimum Installation Clearances
Minimum Installation Clearances From Combustible Materials Minimum clearances from combustible materials Model Cult & Cult Plus 300mm 200mm 300mm 200mm 200mm 12mm Eco & Eco Plus 300mm 200mm 300mm 200mm 200mm 12mm 300mm 200mm 300mm 200mm 200mm 12mm Jazz 300mm... -
Page 9: General Advice
Minimum Installation Clearances From Non-Combustible Materials From Non-Combustable Materials Model Cult, Cult Plus, Eco, Eco Plus, 300mm 100mm 300mm 100mm 100mm 12mm Fox, Jazz, Tara, Tema, Vitra Scena 300mm 100mm 300mm# 100mm 100mm 12mm Twist 300mm 300mm 300mm 100mm 300mm... - Page 10 300mm accommodate the weight of the appliance and its unsupported flue components. 12mm All the Rika wood stoves conform to standards EN 13240, where the hearth temperature does not exceed 100°C. This means a hearth of only Non-combustable board 12mm of non combustible material may be used.
-
Page 11: Commissioning Check List
Information from the Euroheat Technical Team Euroheat and RIKA have a policy of continual research and development and reserve the right to modify its appliances without prior notice. We make every effort to ensure that the information provided in this document is correct and accurate at the time of printing. Continued updates occur to adapt documents to customer requirements and appliance changes. - Page 12 Need more info? with over 10,000 pages of technical information, spare parts, product shots, news and 1001 other things, - you will not find a more comprehensive solution to your queries, whatever time of the day. www.euroheat.co.uk Court Farm Business Park, Bishops Frome, Worcestershire WR6 5AY Pre sales: 01885 491112...
