Spark Plugs
Spark Plug Removal and Replacement
1. Remove the cargo box access
panel.
2. Clean the area around the spark
plugs before removing the
plugs.
3. Remove the spark plug caps.
4. Using the spark plug wrench
provided in the tool kit,
remove the plugs by rotating
them counter-clockwise.
5. Reverse the procedure for
spark plug installation. Torque
to specification. See page 94.

Spark Plug Condition

Normal Plug
The normal insulator tip is gray, tan or light brown. There will be few
combustion deposits. The electrodes are not burned or eroded. This
indicates the proper type and heat range for the engine and the service.
Tip: The tip should not be white. A white insulator tip indicates overheating,
caused by use of an improper spark plug or incorrect throttle body
adjustments.
Wet Fouled Plug
The wet fouled insulator tip is black. A damp oil film covers the firing
end. There may be a carbon layer over the entire nose. Generally, the
electrodes are not worn. Fouling may be caused by excessive oil or by
frequent short trips, especially in cold weather.
MAINTENANCE
Spark Plugs
95
