BenQ MW571 User Manual

Digital
Hide thumbs Also See for MW571:
Table of Contents

Advertisement

Quick Links

Download this manual
MW571
Digital Projector
User Manual

Advertisement

Table of Contents
loading

Related Manuals for BenQ MW571

Summary of Contents for BenQ MW571

  • Page 1 MW571 Digital Projector User Manual...

  • Page 2: Table Of Contents

    Table of contents Important safety Using the teaching templates ....33 Shutting down the projector ....34 instructions ......3 Direct power off........34 Introduction ......7 Menu operation ........35 Projector features........7 Maintenance......46 Shipping contents ........8 Care of the projector......46 Projector exterior view......9 Lamp information ........

  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before In some countries, the line voltage is...
  • Page 4 Safety Instructions (Continued) The lamp becomes extremely hot Do not place this product on an during operation. Allow the projector unstable cart, stand, or table. The to cool for approximately 45 minutes product may fall, sustaining serious prior to removing the lamp assembly damage.
  • Page 5 Safety Instructions (Continued) Do not place this projector in any of Do not block the ventilation holes. the following environments. - Do not place this projector on a blanket, bedding or any other soft - Space that is poorly ventilated or surface.
  • Page 6 If you intend to mount your projector on the ceiling, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit and that you ensure it is securely and safely installed.

  • Page 7: Introduction

    3D Function supported Various 3D formats make the 3D function more flexible. By presenting the depth of the images, you can wear BenQ 3D glasses to enjoy the 3D movies, videos and sporting events in a more realistic way. •...

  • Page 8: Shipping Contents

    Hızlı başlangıç kılavuzu Kurzanleitung Průvodce rychlým používáním Guida rapida Guía de inicio rápido Guia de iniciação rápida Snabbstartsguide クイックスタートガイド BenQ.com Краткое руководство Snelgids Quick start guide Warranty card* User manual CD Remote control with batteries Optional accessories Spare lamp kit...

  • Page 9: Projector Exterior View

    Projector exterior view External control panel Front/upper side (See "Controls and functions" on page 10 for details.) Vent (heated air exhaust) Adjuster foot Focus and Zoom ring Vent (cool air intake) Speaker grill Front IR remote sensor Projection lens AC power jack Audio input jack Audio output jack S-Video input jack...

  • Page 10: Controls And Functions

    Controls and functions Projector Focus ring AUTO Adjusts the focus of the projected image. Automatically determines the best picture timings for the displayed image. Zoom ring 10. POWER indicator light Adjusts the size of the image. Lights up or flashes when the projector is TEMPerature warning light under operation.

  • Page 11: Remote Control

    Remote control 10. Page Up/Page Down Operate your display software program (on a connected PC) which responds to page up/ down commands (like Microsoft PowerPoint). 11. Digital Zoom (+, -) Magnifies or reduces the projected picture size. 12. Timer On Activates or displays an on-screen timer based on your own timer setting.

  • Page 12: Remote Control Effective Range

    Remote control effective range The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor(s) to function correctly. The distance between the remote control and the sensor(s) should not exceed 8 meters (~ 26 feet). Make sure that there are no obstacles between the remote control and the IR sensor(s) on the projector that might obstruct the infra-red beam.

  • Page 13: Positioning Your Projector

    Note that a special rear projection screen portability. and the BenQ Projector Ceiling Mount Kit are required for this installation location. Set Rear Ceiling in the SYSTEM SETUP: Basic > Projector Installation menu after you turn the projector on.

  • Page 14: Obtaining A Preferred Projected Image Size

    All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 15: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. • In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 16: Connecting Video Source Devices

    • If you wish to use this connection method when the projector is in standby mode, make sure the Monitor Out function is turned on in the SYSTEM SETUP: Advanced menu. See "Standby Settings" on page 44 for details. Connecting video source devices You need only connect the projector to a video source device using just one of the connecting methods, however each provides a different level of video quality.

  • Page 17: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a power outlet. Turn on the power outlet switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied. Please use the original accessories (e.g.

  • Page 18: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 adjuster foot. It changes the image height and projection angle. To adjust the projector, screw the adjuster foot to fine- tune the horizontal angle. To retract the foot, screw the rear adjuster foot in a reverse direction.

  • Page 19: Correcting Keystone

    Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, you will need to manually correct it following ONE of these steps. •...

  • Page 20: Using The Menus

    Projector Installation Front Table Position Menu Settings Phase Operation Settings H. Size Panel Key Lock Digital Zoom Background Color BenQ Splash Screen BenQ Teaching Template Analog RGB MENU Exit Analog RGB MENU Exit to highlight the SYSTEM Press to select a SETUP: Basic menu.

  • Page 21: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector. See item 19 on page for details.

  • Page 22: Entering The Password Recall Procedure

    BenQ Customer Center. Write down the number and turn off your projector. Recall Code: Seek help from the local BenQ service 255 255 255 255 center to decode the number. You may be required to provide proof of purchase MENU...

  • Page 23: Switching Input Signal

    ii. If the password is incorrect, the password error message will appear, and the message “INPUT PASSWORD” appears for your retry. You can press MENU/EXIT to cancel the change or try another password. Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password.

  • Page 24: Magnifying And Searching For Details

    Magnifying and searching for details If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture. • Using the remote control Press Digital Zoom+/- to display the Zoom bar. Press Digital Zoom+ to magnify the center of the picture.
  • Page 25 About the aspect ratio • In the pictures below, the black portions are inactive areas and the white portions are active areas. • OSD menus can be displayed on those unused black areas. Auto Scales an image proportionally to fit the projector's native resolution in its horizontal or vertical width.

  • Page 26: Optimizing The Image

    Optimizing the image Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s colors to prevent possible color difference between the source and projected pictures. To use this function, go to the DISPLAY >...

  • Page 27: Adjusting Brightness

    Press to select a menu item to be changed and adjust the value with . See "Fine-tuning the image quality in user modes" below for details. Fine-tuning the image quality in user modes According to the detected signal type and selected picture mode, some of the below functions may not be available.

  • Page 28: Setting A Preferred Color Temperature

    Setting a preferred color temperature To set a preferred color temperature: Highlight Color Temperature and select Warm, Normal or Cool by pressing on the projector or remote control. Press to highlight Color Temperature Fine Tuning and press MODE/ ENTER. The Color Temperature Fine Tuning page appears. Press to highlight the item you want to change and adjust the values by pressing...

  • Page 29: Setting The Presentation Timer

    Please refer to the illustration to the right for how the colors relate to each other. For example, if you select Red and set its range at 0, only pure red in the projected Yellow GREEN picture will be selected. Increasing its range will include red close to yellow and red close to magenta.

  • Page 30: Remote Paging Operations

    Press to highlight Timer Position and set the timer position by pressing Top-Left Bottom-Left Top-Right Bottom-Right Press to highlight Timer Counting Direction and select your desired counting direction by pressing Selection Description Count Up Increases from 0 to the preset time. Count Down Decreases from the preset time to 0.

  • Page 31: Hiding The Image

    Hiding the image In order to draw the audience's full attention to the presenter, you can use ECO BLANK on the projector or remote control to hide the screen image. When this function is activated with an audio input connected, the audio can still be heard. SYSTEM SETUP: Basic >...

  • Page 32: Adjusting The Sound

    symptoms. However, this is not to state that this projector can operate under any and all harsh or extreme conditions. Adjusting the sound The sound adjustments made as below will have an effect on the projector speaker(s). Be sure you have made a correct connection to the projector audio input. See "Connection"...

  • Page 33: Using The Teaching Templates

    Using the teaching templates The projector provides several preset patterns for various teaching purposes. To activate the pattern: Open the OSD menu and go to the DISPLAY > Teaching Template and press to select Blackboard or Whiteboard. Press to choose the pattern you need. Press MODE/ENTER to activate the pattern.

  • Page 34: Shutting Down The Projector

    Shutting down the projector Press POWER and a confirmation message will display prompting you. If you don't respond in a few seconds, the message will disappear. Press POWER a second time. The POWER indicator light flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to cool down the projector.

  • Page 35: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected and the projector model you are using. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Green/Blue/ Wall Color Blackboard Aspect Ratio Auto/Real/4:3/16:9/16:10 Keystone Position Phase H.
  • Page 36 Operation Quick Cooling On/Off Settings Instant Restart On/Off Disable/5 min/10 min/15 min/20 Blank Timer min/25 min/30 min Disable/30 min/1 hr/2 hr/3 hr/4 hr/8 Sleep Timer hr/12 hr Panel Key Lock On/Off Background Color BenQ/Black/Blue/Purple Splash Screen BenQ/Black/Blue Operation...
  • Page 37 Main menu Sub-menu Options High Altitude Mode On/Off Mute On/Off Audio Volume Settings Power On/Off Ring On/Off Tone Normal/Economic/SmartEco/ Lamp Mode LampSave Lamp Settings Reset Lamp Timer Lamp Timer Change Password Security Change Security Settings Settings Power On Lock On/Off 2400/4800/9600/14400/19200/ Baud Rate 38400/57600/115200...
  • Page 38 Note that the menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible. Operation...

  • Page 39: Description Of Each Menu

    Description of each menu Function Description Corrects the projected picture’s color when the projection surface is Wall Color not white. See "Using Wall Color" on page 26 for details. There are several options to set the image's aspect ratio depending on Aspect Ratio your input signal source.
  • Page 40 Function Description This projector features a 3D function which enables you to enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view the 3D images.
  • Page 41 Function Description Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. See "Selecting a picture mode" on page 26 for details. Selects a picture mode that best suits your need for the image quality Reference and further fine-tune the image based on the selections listed on the same page below.
  • Page 42 Function Description Presentation Reminds the presenter to finish the presentation within a certain time frame. See "Setting the presentation timer" on page 29 for details. Timer Sets the language for the On-Screen Display (OSD) menus. See "Using Language the menus" on page 20 for details.
  • Page 43 Function Description Panel Key Disables or enables all panel key functions except POWER on the projector and keys on the remote control. See "Locking control keys" Lock on page 31 for details. Background Sets the background color for the projector. Color Splash Allows you to select which logo screen will display during projector...

  • Page 44: Monitor Out

    Function Description Closed Caption Enable Activates the function by selecting On when the selected input signal carries closed captions. • Captions: An on-screen display of the dialogue, narration, and Closed sound effects of TV programs and videos that are closed captioned Caption (usually marked as "CC"...
  • Page 45 Function Description Network BenQ Network Projector Operation Guide for details. Settings Returns all settings to the factory preset values. The following settings will still remain: Keystone, User 1, User 2, Reset All Reference Mode, 3D Color Management, Reset Picture Settings,...

  • Page 46: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens and case clean. Never remove any parts of the projector. Contact your dealer if other parts need replacing.

  • Page 47: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. Total (equivalent) lamp hour = 2.5 x (hours used in Normal mode) + 1.67 x (hours used in Economic mode) + 1.54 x (hours used in SmartEco mode) + 1.00 x (hours used in LampSave mode).

  • Page 48: Timing Of Replacing The Lamp

    47), you may continue to operate the Equivalent lamp hour > XXXX Hours projector until the next hour lamp warning appears. Order a new lamp at www.BenQ.com Press MODE/ENTER to dismiss the message. It is strongly recommended that you replace the Notice lamp at this age.
  • Page 49 Replacing the lamp (FOR SERVICE PERSONNEL ONLY) To reduce the risk of electrical shock, always turn the projector off and • disconnect the power cord before changing the lamp. • To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp.
  • Page 50 Disconnect the lamp connector from the projector as illustrated. Loosen the screw that secures the lamp. Lift the handle so that it stands up. Use the handle to slowly pull the lamp out of the projector. • Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector.

  • Page 51: Resetting The Lamp Timer

    Close the lamp cover. Tighten the screw(s) that secures the lamp cover. • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screw. Connect the power and restart the projector. Do not turn the power on with the lamp cover removed. Resetting the lamp timer After the startup logo, open the On-Screen Display (OSD) menu.
  • Page 52 Indicators Light Status & Description Power events Stand-by mode Orange Green Powering up Flashing Normal operation Green Orange Normal power-down cooling Flashing Download Red Flashing Flashing Flashing CW start fail Green Scaler shutdown fail (data abort) Red Flashing Scaler reset fail LAN download fail Green LAN download processing...

  • Page 53: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC power jack on the projector, and plug the power cord into the There is no power from the power cord. power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 54: Specifications

    Specifications Projector specifications All specifications are subject to change without notice. Optical Control Resolution RS-232 serial control 1280 x 800 WXGA 9 pin x 1 Display system IR receiver x 1 1-CHIP DMD LAN control Lens F/Number RJ45 x 1 F = 2.59 ~ 2.87, f = 16.88 ~ 21.88 mm Input terminals Clear focus range...

  • Page 55: Dimensions

    Dimensions 283 mm (W) x 95 mm (H) x 222 mm (D) 54.46 59.5 Unit: mm Ceiling mount installation Ceiling Mount screw: M4 (Max L = 25 mm; Min L = 20 mm) 207.54 105.77 59.5 201.55 44.94 81.9 Unit: mm 104.42 225.4 128.9...

  • Page 56: Timing Chart

    1024 x 768 XGA_85 84.997 68.667 94.500 XGA_120** 119.989 97.551 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 BenQ 1024 x 576 60.0 35.820 46.966 Notebook_timing BenQ 1024 x 600 64.995 41.467 51.419 Notebook_timing 1280 x 720 1280 x 720_60* 45.000...
  • Page 57 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 1280 x 768 1280 x 768_60* 59.87 47.776 79.5 1024 x 576@60Hz BenQ Notebook Timing 60.00 35.820 46.996 1024 x 600@65Hz BenQ Notebook Timing 64.995 41.467 51.419 1280 x 720 1280 x 720_60* 45.000...
  • Page 58 • *Supported timing for 3D signal in Frame Sequential, Top Bottom and Side by Side formats. **Supported timing for 3D signal in Frame Sequential format. ***Supported timing for 3D signal in Top Bottom and Side by Side formats. • The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen.
  • Page 59 Supported timing for Component-YP input Vertical Horizontal Pixel Frequency Timing Resolution Frequency (Hz) Frequency (kHz) (MHz) 480i* 720 x 480 59.94 15.73 13.5 480p* 720 x 480 59.94 31.47 576i 720 x 576 15.63 13.5 576p 720 x 576 31.25 720/50p 1280 x 720 37.5...
  • Page 60 Supported timing for Video and S-Video inputs Horizontal Vertical Frequency Color sub-carrier Video mode Frequency (kHz) (Hz) Frequency (MHz) NTSC* 15.73 3.58 15.63 4.43 SECAM 15.63 4.25 or 4.41 PAL-M 15.73 3.58 PAL-N 15.63 3.58 PAL-60 15.73 4.43 NTSC4.43 15.73 4.43 *Supported timing for 3D signal in Frame Sequential format.

  • Page 61: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.
