AVG-UDA2
The AVG-UDA2 is a HDMI splitter with the
capability to transmit a HDMI or DVI source to 2
displays synchronously.
Features
2 simultaneous HDMI outputs
Supports Hot-plugging
Compliant with HDMI 1.4, able to
transmit 1080p 3D& 4K signals
Transmits 1080p HDMI up to
15m
High bandwidth: 10.2Gbps
HDCP compliant
Auto-identify input resolution
Supports EDID management,
automatically adopts the lowest
compatible resolution when
connecting several displays
Intuitive indicator for connection
status & input HDCP compliance
status
