Page 6
Attach the primary protective grill using the screws provided with the heater. Ensure all screw holes on both sides of the top and bottom of the grill are securely fastened to the heater. (Please see diagram on page 14 showing the grill and its attached position to the heater)
Page 15
Code Description Main front protective screen Fastener 1 Scatter panel Igniting electrode Burner assembly Burner board Top cover Plastic seat Bolt Ignitor assembly knob Gas pipe Nut Plastic seat Gas safety valve Rear blocked board Fastener Rear cover board Rear insulation board Front insulation board Tip over safety switch Universal wheel...
