Outline; Major Service Parts - Sharp LC-40D68UT Service Manual

LC-40D68UT

OUTLINE

MAJOR SERVICE PARTS

PWB UNIT
Ref No. Parts Code
N DUNTKF463FM02
N DUNTKF465FM02
N DUNTKE266FM02
N DUNTKF096FM01
N RDENCA393WJQZ
N 9JS-5540T04C04
N 9JS-1940T04001
OTHER UNIT
Ref No. Parts Code
N R1LK400D3LF31Z
IC FOR EXCLUSIVE USE OF THE SERVICE
Ref No. Parts Code
IC602 VHiS24CS02JHES
IC1610 VHiR24002AS3YS
IC1611 VHiR24002AS2YS
IC1612 VHiR24002AS4YS
IC2002 RH-iXC165WJN5Q
IC8451 RH-iXC895WJN1S
SERVICE JIGS
Ref No. Parts Code
N QCNW-G401WJQZ
N QCNW-H649WJPZ
N QCNW-H762WJQZ
N QCNW-K865WJQZ
N QCNW-K866WJQZ
N QCNW-K867WJQZ
MAIN Unit
TERMINAL Unit
KEY Unit
R/C, LED Unit
POWER Unit
LCD CONTROL Unit
INVERTER Unit
40" LCD Panel Module Unit
IC R1EX24002ASAS0A
IC R1EX24002ASAS0A
IC R1EX24002ASAS0A
IC R1EX24002ASAS0A
IC R5F212A8SNFP
IC MX25L6405DMI-12G
L=1000mm 4-5pins, Main to Key (KM)
L=1000mm 4pins, Main to Speaker (SP)
L=1000mm 10pins, Main to R/C LED (RA)
L=1000mm 51pins, Main to T-CON (LW)
L=1000mm 12-14pins, Main to Power (PD)
L=1000mm 14pins, Power to Inverter (LB2)
iv
Service Manual
Description
Description
Description
Description
LC-40D68UT
Q'ty
1
1
1
1
1
1
Q'ty
1
1
1
1
1
1
