4. Removing of 40" LCD Panel Module Unit, TERMINAL Unit, MAIN Unit and POWER Unit.
1. Remove the 2 lock screws
2. Remove the 8 lock screws
3. Remove the 6 lock screws
POWER Unit
3
40" LCD Panel
Module Unit
, 6 hooks and detach the 40" LCD Panel Module Unit
and detach the TERMINAL Unit
and detach the POWER Unit
7
8
2
2
2
.

/MAIN Unit

.
.
1
2
2
2
4 – 4
4
5

TERMINAL Unit

6 MAIN Unit
LC-40D68UT
