Key Button; Key Unit; Bottom Cover - Sharp LC-40D68UT Service Manual

2. Removing of Speaker-L/R, KEY Unit Ass'y, Bottom Cover and R/C, LED Unit.
1. Disconnect SP wire and detach the Speaker-L
2. Detach the KEY Button Cover Ass'y.
3. Detach the KEY Unit from KEY Button Cover
4. Detach the Bottom Cover
5. Detach the R/C, LED Unit
Speaker-R 2
/Speaker-R
and disconnect KM wire.
.
and disconnect RA wire.
RA
SP
6
R/C, LED Unit
.
SP
RA
5

Bottom Cover

4 – 2
LC-40D68UT

KEY Button

Cover Ass'y
KEY Button
Cover
KM
KM
4

KEY Unit

SP
1 Speaker-L
3
