  • Page 2 Preface  Copyright 2010  All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if...

  • Page 3: Table Of Contents

    Table of Content   ................2 EFORE YOU TART ..........6   ET YOUR COMPUTER ACCLIMATE ITSELF ............ 6   UMIDITY LARE ..............6   UITABLE PLACE TO WORK   ..................9 NTRODUCTION ..................12   IEWS ..................13   IGHT  ...
  • Page 4   ................47 ROUBLESHOOTING ................ 48   O SPEAKER OUTPUT ............48   OUND CANNOT BE RECORDED ..49   HE HARD DISK DRIVE DOES NOT WORK OR IS NOT RECOGNIZABLE ..... 49   HE HARD DRIVE IS MAKING ABNORMAL WHINING NOISES ......

  • Page 6: Before You Start

    Use this manual will help you get the most from your notebook computer.  If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories.
  • Page 7 Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted.
  • Page 8 The minimum specifications for the flexible cord are  No. 18 AWG, (2) Type SPT-2, and (3) 2-conductor. For Japan: All components of the cord set must bear a “PSE”  mark and in accordance with the Japanese Dentori Law. The minimum specifications for the flexible cord ...
  • Page 9 manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special instructions. Do not use the AC adapter near open water or other liquids. Never spill liquid into the AC adapter. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.

  • Page 10: Let Your Computer Acclimate Itself

    Your notebook can easily stand temperature extremes but it doesn’t like rapid changes in temperature, like going from the cold outdoors to a warm office. Rapid changes in temperature can cause water droplets to condense inside your case, threatening to damage the electronic parts inside.
  • Page 11 A lithium-ion battery pack will be available when you are traveling. If you are running your system for the first time on battery power, remove the battery from the package, install it into the system and recharge the battery to fully prepare for service.

  • Page 13: Introduction

    Install the battery pack Connecting the AC adapter Opening the display panel Turning on your computer...
  • Page 14 With the LCD screen open, you will see several features important for operating your notebook computer.
  • Page 15 Camera LCD Display Keyboard Microphone LED Status Indicator System & Power Status Indicators LED Graphic Indication Symbol Blue light indicates the system is ON. Blinking blue light indicates the notebook is in suspend mode. Blue light indicates the LAN/Bluetooth is active. Battery status Charging –...

  • Page 16: Left Views

    Touchpad Touchpad Buttons Kensington Lock Ventilation Opening CRT Port Ethernet / LAN Port When using a LAN, please use an EMI Shielding Cable to minimize interference when transmitting HDMI Port  USB 2.0 Port...

  • Page 17: Right View

    Microphone/Audio Line-in Jack Stereo Headphone Jack  USB 2.0 Port  Combo USB (with USB 2.0 and e-SATA) Optical Drive DC In...
  • Page 18 Battery Lock 4-in-1 Card Reader ( SDHC/MMC/MS/MS pro Memory Card) Battery Compartment Battery Release Latch...

  • Page 20: Connecting The Ac Adapter

    A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. To connect the computer to an external power source:...
  • Page 21 Whenever possible, keep the AC adapter plugged into the notebook and an electrical outlet to recharge the battery. ’ ’ Hold the button down for a second or two and release. The Power- On Self Test (POST) runs automatically. After the POST is completed, the computer reads the operating system from the hard disk drive into computer memory (this is commonly referred to as “booting”...

  • Page 22: T I B Pack

    ’ ’...

  • Page 23: T R B Pack

    The installed battery pack charges automatically any time the computer is connected to the AC adapter and an external power source. It is a good idea to occasionally discharge the battery pack fully to preserve its operating performance.

  • Page 25: Using The Notebook Computer

    The LCD screen display can be adjusted by the following key combinations.  F4 - Changes Display Mode: LCD-only, CRT/HDMI-only and simultaneous LCD&CRT/HDMI.  F7 - Decrease the brightness level.  F8 - Increase the brightness level. LCD screens are delicate devices that need careful handling. Please pay attention to the following precautions: ...
  • Page 26 You can switch between these display configurations by pressing the key combination [Fn] + [F4]. ’ ’  Fn + F1 : Suspend  Fn + F2 : Silent Mode  Fn + F3 : Mute  Fn + F4 : LCD/CRT/HDMI ...

  • Page 27: Touch Pad Precautions

    The TouchPad is a pressure sensitive device. Please take note of the following precautions.  Make sure the TouchPad does not come into contact with dirt, liquids or grease.  Do not touch the TouchPad if your fingers are dirty. ...

  • Page 28: Calibration )

    Charging the battery takes about 2.5 hours to charge when the system is in off state. If possible, always charge the battery completely. “ ” “ ” “ ” “ ” “ ” “ ” To remove the battery pack from its compartment, please refer to Chapter 3, Inserting and Removing the Battery Pack.

  • Page 29: Automatic Battery Pack Charging Function

    discharge/charge cycle) will ensure the accurate reporting of the battery gauge status. To charge the battery, while the battery pack is in the notebook, plug the AC adapter into the notebook and an electrical outlet. The charging time is approximately 3-4 hours when the notebook is turned off and approximately 6-7 hours when the notebook is turned on.
  • Page 30 accelerates 2 minutes of battery charge remaining. Save your work and turn off the notebook, or connect the AC adapter. When there is only one minute of battery charge remaining, the notebook will suspend to the HDD and power off. You should connect AC power and resume to save your work.

  • Page 31: Help Windows

    For Windows 7 help, click Start Help and Support icon will open the dialog box. Desktop may vary differently on the software installed in your notebook with different or additional shortcuts.

  • Page 32: Recycle Bin

    Recycle Bin Used for storing deleted files in case you want to recover and save it in your system. The files will only be deleted from the Recycle Bin permanently only if you empty it by right clicking your mouse and select the “Empty Recycle Bin”.
  • Page 33 The Start menu allows you to adapt and show the programs used most frequently. If you wish to keep an item, right click the item and click Pin to Start menu. Log Off will enable the current user to log off and allows a new user to log on.
  • Page 34 It is in this area that you can change how Windows looks and works. Click Start  Control Panel dialog box. There are two interfaces – Classic View.

  • Page 39: Running Bios Setup

    The Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is menu-driven software, which allows you to easily configure and change the settings. The BIOS contains manufacture’s default settings for the computer’s standard operations.
  • Page 40 Function Key Command Description Leaves a sub-menu to return to the Exit previous menu OR exits the BIOS setup while saving changes. Go to Sub Enter Shows the Sub Menu Screen General Help Shows the Help Screen Default Set to default Saves changes and reboots the Save and Exit computer.

  • Page 46: Vga Utilities

    You can click the touchpad or mouse right button and select the “Personalize” item.

  • Page 51: Troubleshooting

    Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.

  • Page 52: N O Speaker Output

     Be sure all the device drivers are installed properly. For example, without the audio driver properly installed, the speakers and microphone will not work.  If external devices such as USB camera, scanner, printer do not function correctly when connected to the system, it is usually the device’s own problem.

  • Page 53: The Hard Disk Drive Does Not Work Or Is Not Recognizable

    taskbar to see if the microphone has been muted. Click Options and select Properties.   Select Recording and click the OK button.  After Click OK button, the recording volume control panel will appear.  Go to [Start > Settings > Control Panel] and double-click the Multimedia icon (or Sounds and Audio Devices icon).
  • Page 54 longer use.

  • Page 55: The Hard Disk Takes Longer To Read A File

     Many browsers store files in the hard drive as a cache to speed up the performance. Check the program’s Online Help for instructions on decreasing the cache size or on removing temporary Internet files.  Empty the Recycle Bin to create more disk space. When you delete files, Windows saves them to the Recycle Bin.

  • Page 56: The Screen Flickers

     It is normal if the display flickers a few times during shutting down or powering up.  Make sure there is no excess perspiration or humidity on your hand when using the touch pad. Keep the surface of the touch pad clean and dry. ...

  • Page 57: The Post Does Not Show An Increased Memory Capacity When

    battery. This battery normally lasts two to five years. The battery is of type CR2032 (3V). Send the battery to the dealer for replacement.  Certain brands of memory module may not be compatible with your system. You should ask your vendor for a list of compatible DIMM.

  • Page 58: Windows Crashes Or Freezes When You Remove The Wpc Card

     The card may be defective. Try the card on another system, if possible.  Make sure you have <Stop> the PC card before removing it. Double-click the Safely Remove Hardware icon at the lower right corner of the task bar and select the card you wish to stop.

  • Page 59: The Usb Device Does Not Work

     Check the settings in the Windows Control Panel.  Make sure you have installed the necessary device drivers.  Contact the device vendor for additional support.  Detach the external device; insert it into the Enhanced USB port. Separate the cable with the equipment; first insert the wire into the port, then connect the device with the cable that is inserted into the Enhanced USB port.

  • Page 61: Specification

    O.S.  Support Windows 7 Home Premium x64, x32, XP Capable with WHQL  Intel Calpella  P6000, 1.86GHz, rPGA, TDP 35W, L3 cache 3MB  P6100, 2.00GHz, rPGA, TDP 35W, L3 cache 3MB  i3-330M, 2.13GHz, rPGA, TDP 35W, L2 cache 3MB ...
  • Page 62  ATI Madison-XT, TDP 28W  DX11 and OpenGL 3.1 and OpenCL 2.1  PCI-Express V2.0 (support x1, x2, x4, x8, x16 lane width) bus Interface.  W/ DDR3 1GB VRAM Audio Codec  Realtek ALC269-GR Card reader (4 in 1) ...
  • Page 63  GBAS bezel w/o printing  Support SATA interface only Battery Pack  6 cell, BAT H41 LI SMP 3S2P BAK 4.4AH 1A D  6 cell, BAT H41 LI GLW 3S2P LG-L3 4.4AH 1A D AC-Adapter  Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, 19V/90 Watts, Level 5 Delta ADP-90SB-AB Delta ADP-90SB-AD...
