Operation, Parts, Service and Repair
GAP Pro Spray Gun
For use with non-flammable polyurethane foams. For professional use only.
Not for use in explosive atmospheres.
See page 3 for model information.
3000 psi (20.7 MPa, 207 bar) Maximum Working Fluid Pressure
125 psi (0.86 MPa, 8.6 bar) Maximum Working Air Pressure
Important Safety Instructions
Read all warnings and instructions
in this manual. Save these instructions.
311322L
EN
Advertisement
Table of Contents
Related Manuals for Graco 311322L
Summary of Contents for Graco 311322L
- Page 1 Operation, Parts, Service and Repair GAP Pro Spray Gun 311322L For use with non-flammable polyurethane foams. For professional use only. Not for use in explosive atmospheres. See page 3 for model information. 3000 psi (20.7 MPa, 207 bar) Maximum Working Fluid Pressure 125 psi (0.86 MPa, 8.6 bar) Maximum Working Air Pressure...
-
Page 2: Table Of Contents
Graco Standard Warranty ....34 Graco Information ......34... -
Page 3: Gun Models
Mix Module Round Pattern Gun #00 round 295557 Round Pattern Gun, Recirculating #00 round 295558 Round Pattern Gun #01 round 295559 Round Pattern Gun #02 round 295560 Round Pattern Gun #03 round 295561 Round Pattern Gun #04 round 295562 311322L... -
Page 4: Warnings
Do not stop or deflect leaks with your hand, body, glove, or rag. • Do not spray without tip guard and trigger guard installed. • Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning, checking, or servicing equipment. 311322L... - Page 5 Graco/Gusmer replacement parts only. • Do not alter or modify equipment. • Use equipment only for its intended purpose. Call your Graco/Gusmer distributor for infor- mation. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot sur- faces.
-
Page 6: Important Two-Component Material Information
Posting a placard such as the following outside the work area is recommended: TOXIC FUMES HAZARD DO NOT ENTER DURING SPRAY FOAM APPLICATION OR FOR ___ HOURS AFTER APPLICATION IS COMPLETE DO NOT ENTER UNTIL: DATE: ____________ TIME: ____________ 311322L... -
Page 7: For All Applications Except Spray Foam
NOTE: The amount of film formation and rate of crystallization varies depending on the blend of ISO, the humidity, and the temperature. Some materials may become self-igniting if applied too thick. Read material manufacturer’s warnings and Safety Data Sheet (SDS). 311322L... -
Page 8: Foam Resins With 245 Fa Blowing Agents
• When changing between epoxies and urethanes or polyureas, disassemble and clean all fluid com- ponents and change hoses. Epoxies often have amines on the B (hardener) side. Polyureas often have amines on the B (resin) side. 311322L... -
Page 9: Overall View
Overall View Overall View Major Components Safety Stop A-Manual Valve A-Screen Screw R-Manual Valve Spray Tip R-Screen Screw Trigger . 1. Major Components (shown with round spray tip) 311322L... - Page 10 Overall View O-Ring R-Side Block Mixing Chamber Gun Block Air Cap Flat Tip Side Block Screws Gun Block Air Seal Screws A-Side Block . 2. Front End Components (shown with flat spray tip assembly) 311322L...
-
Page 11: Operation
Check your local electrical code and propor- tioner manual for detailed grounding instruc- Isocyanate Hazard tions. Ground the spray gun through connection to a Graco-approved grounded fluid supply hose. Spraying materials containing isocyanates creates potentially harmful mists, vapors, and atomized particulates. Read material manufacturer’s warnings and material MSDS to know specific hazards and precautions related to isocyanates. -
Page 12: Safety Stop
. 3. Engage Safety Stop Manual 2. To disengage the safety stop, push in Valves and turn the safety stop knob counterclock- wise. See F . 4. Coupling Blocks . 4. Disengage Safety Stop . 5. Manual Valves 311322L... -
Page 13: Air Hose Configurations
6. Connect air hose to nipple and use wrench ual valves, and disconnect air before chang- to tighten. ing air hose configuration. Install Pipe Nipple Air Hose Remove Pipe Plug Install Pipe Plug Remove Long Pipe Nipple . 6. Air Hose Configuration 311322L... -
Page 14: Initial Set Up
9. Disengage safety stop. 1. Follow Pressure Relief Procedure, page 10. Test spray on disposable surface. 2. Shutdown proportioning unit as required. 11. Proceed with Daily Start-up procedure or Shutdown procedure as required. 3. Grease gun, page 15. 311322L... -
Page 15: Pressure Relief Procedure
To relieve pressure in hose after gun is 5. Disconnect gun air supply, page 13. removed, place fluid manifold over containers, facing away from you. Very carefully open fluid valves. Under high pressure, fluid will spray sideways from fluid ports. 311322L... -
Page 16: Repair
A-side block. 1. Follow Pressure Relief Procedure, page Manual Valve Assembly Side Block Screen Screw Seal Check Valve Assembly Spring Check Valve Retainer Side Seal O-Ring Screen Screw Screen Side Seal Assembly Swivel Fitting . 7. Side Block Components 311322L... - Page 17 15. Install side blocks to gun body with two mounting screws. Tighten screws alter- nately and evenly to prevent leakage. 16. Return gun to service. See Daily Start-Up, One quarter of a page 14. full turn (max.) . 8. Tighten Check Valve Retainer 311322L...
-
Page 18: Mixing Chamber And Gun Block
Clean mixing chamber with gun cleaner and drill bits. Inspect for damage and replace if neces- sary. 7. Hold end of piston shaft with a 3/16 in. wrench or needle-nose pliers. Screw mix- ing chamber onto shaft by hand. 311322L... - Page 19 Repair O-Ring R-Side Block Mixing Chamber Gun Block Air Cap Flat Tip Side Block Gun Block Screws Air Seal Screws A-Side Block . 10. Mixing Chamber and Gun Block 311322L...
-
Page 20: End Cap And Air Piston
Be sure to retain o-ring located between gun block and mounting flange. Piston Assembly Piston Spring Mixing Chamber End Cap/Safety Stop Assembly Socket Head Cap Screw Cylinder Retaining Ring Clamp . 11. End Cap and Piston Assembly 311322L... - Page 21 19. Install side blocks to gun body with two mounting screws. Tighten screws alter- nately and evenly to prevent leakage. Piston Shaft O-Rings 20. Return gun to service. See Daily Start-Up, Piston page 14. Piston O-Ring . 12. Piston Assembly 311322L...
-
Page 22: End Cap O-Ring And Safety Stop Seal
To repair side blocks, see Side Blocks, aged. Lightly coat new o-ring with Lubri- page 16. plate grease and install on end cap. End Cap/Safety Stop Assembly Retaining Ring Cylinder Clamp Socket Head Cap Screw . 13. End Cap Assembly 311322L... - Page 23 12. Install side blocks to gun body with two mounting screws. Tighten screws alter- Stop Pin nately and evenly to prevent leakage. Set Screws 13. Return gun to service. See Daily Start-Up, page 14. Cup Seal End Cap O-Ring . 14. Safety Stop Assembly 311322L...
-
Page 24: Trigger/Air Valve
19. Return gun to service. See Daily Start-Up, port at rear of gun. page 14. 9. Brass spring seat is visible inside port at rear of gun. Use a 1/4 in. diameter (maxi- mum) punch and hammer to gently tap 311322L... - Page 25 Repair Optional Air Hose and Nipple 1/8 in. Pipe Plug Spring 1/16 in. Seat Pipe Plug Valve Liner O-Rings Valve Spool Valve Spring Trigger Mounting Screw Lock Nut Valve Retainer Nut Trigger Lever . 15. Trigger/Air Valve Assembly 311322L...
-
Page 26: Air Passage Diagrams
.3125 dia. .250 dia. .375 dia. 1.858 dia. .687 dia. 1.750 dia. .3125 dia. 8-32 UNC-GH3 TAP 1/8 in. drill 1/8 in. drill 5/32 in. drill 8-32 UNC-2B TAP . 16: Air Cylinder Air Passages 311322L... - Page 27 10-32 UNC-2B TAP 5/32 in. drill (3) 10-32 UNC-2B TAP 5/32 in. drill 1/8 in. NPT TAP 1/2 in. dia. 1/16 in. NPT TAP 5/8-18 UNC-2B TAP 5/32 in. drill 1/8 in. drill 1/8 NPT TAP . 17: Handle Air Passages 311322L...
-
Page 28: Parts
Parts Parts GAP Pro Spray Gun Assembly Round Spray 3, 42 . 18: GAP Pro Final Assembly 311322L... - Page 29 296297 296302 296490 ◆ This model uses qty. 2 each of items 1 and 2. ✖ Kit includes qty. 2 each of items 23 and 26. † Kit includes (1) 27, (1) 28, and cleanout tools 40 and 41. 311322L...
-
Page 30: Gap Pro Spray Gun Handle Assembly
Parts GAP Pro Spray Gun Handle Assembly . 19: GAP Pro Handle Assembly 311322L... - Page 31 84 296962 CYLINDER, air 65 296535 CLAMP, cylinder 85❄ 114054 O-RING 66❄ 108103 O-RING 86 295665 NIPPLE 67❄ 168518 O-RING 68 295695 SCREW, cap; button hd 69 295671 SCREW, trigger ❄ Included in Handle Seal Repair Kit 296938 (purchase separately). 311322L...
-
Page 32: Accessories
. 20: Pour Package Components Mixing Chamber Cleanout Drills Round Mixing Mixing Chamber Mixing Chamber Chamber (27) Nozzle Cleanout Drill Port Cleanout Drill 296846 118369 296289 296847 296296 296293 296848 296297 118369 296849 296302 296296 296850 296490 296297 296851 296491 296302 311322L... -
Page 33: Technical Data
R Component (Resin) Inlet Size -6 JIC; 9/16-18 UNF Length 7 in. (17.8 cm) Height 7.25 in. (18.4 cm) Width 4.4 in. (11.2 cm) Weight 2.34 lb (1.06 kg) Wetted Parts Stainless steel, carbon steel, brass, nylon, acetal, PTFE, aluminum 311322L... -
Page 34: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
