- Page 1 User Manual Compact HMI Touch Panels...
-
Page 2: Table Of Contents
Table of Contents Safety Information ............................4 Important Information ..........................5 Physical Overview ............................8 Package Contents ............................8 Panel PC Description ..........................8 Panel PC Front View ..........................8 Panel PC I/O View (7”) .......................... 9 Panel PC I/O View (10.1”, 12.1”, 15”, 17”, 18.5”, 21.5”) ..............9 Characteristics ............................. - Page 3 SATA ................................ 30 Configuration of the BIOS ........................... 30 Hardware Modification ..........................43 Installing the Hard Disk in the Hard Drive Bay ..................43 Maintenance ............................... 49 AIS Support ..............................50 New Product Satisfaction Return ........................ 50...
-
Page 4: Safety Information
Safety Information Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Caution! Always ground yourself to remove any static charge before touching the CPU card. -
Page 5: Important Information
o The equipment has obvious signs of breakage. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. CAUTION – Use the recommended mounting apparatus to avoid risk of injury. ... - Page 6 Certifications and Standards Agency Standard for Marking Description UL/cUL/CB 61010 Safety of electrical equipment; measurement, control, industrial process, and laboratory electrical equipment. UL/cUL/CB 62368 Safety of electronic equipment; audio, video, information and communication technology, and business and office machines. Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
- Page 7 In addition, free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call or e-mail us. AIS contact information, please go to http://www.aispro.com/contactus.
-
Page 8: Physical Overview
Physical Overview Package Contents Before using this Panel PC, please make sure that all the items listed below are present in your package: Panel PC AC adapter 2 x Power Cord (EU and USA type) Engineering display Mounting Fasteners stand Panel PC Description Panel PC Front View... -
Page 9: Panel Pc I/O View (7")
Panel PC I/O View (7”) Panel PC I/O View (10.1”, 12.1”, 15”, 17”, 18.5”, 21.5”) -
Page 10: Characteristics
Characteristics Panel PC Characteristics (4:3) Part Number HMI-TCND0U-12AR- HMI-TCND0U-15AR- HMI-TCND0U-17AR- X00H X00H X00H Display Size in inches / resolution in pixels 12.1" / XGA, 1024 x 768 15" / XGA, 1024 x 768 17" / SXGA, 1280 x 1024 Brightness / luminance 330 nits / 330 cd/m²... -
Page 11: Panel Pc Characteristics (16:9)
Relative humidity 10 to 90% at 40˚C (non-condensing) Certifications / regulations UL/cUL/CB 62368, UL/cUL/CB 61010 Physical Specifications Operator panel / cut-out (W x H) 303 x 229 mm 392 x 292 mm 422 x 311 mm Installation dimensions (W x H x D) 319 x 245 x 52 mm 401 x 310 x 55 mm 439 x 348 x 64.8 mm... - Page 12 Current supply 24 V DC Bezel / housing Aluminum die-casting Mounting options Panel / wall mount Packages / bundles Packages with Wonderware InTouch, ready-to-use HMI software (optional) Environmental / Ambient Conditions Degree of protection Front: IP65; Rear: IP20 / Fanless / thermal Electromagnetic CE, FCC A, EN 61000-6-2, EN 61000-6-3, CISPR22, RoHS...
-
Page 13: Environmental Characteristics
Environmental Characteristics Chemical Resistance for Resistive Touch The active area of the touch screen is resistant to the following chemicals when exposed for a period of one hour at a temperature of 70 F (21 Industrial Chemical Acetone Methylene chloride ... -
Page 14: Mechanical Dimensions
Mechanical Dimensions 7” Dimensions... -
Page 15: 10.1" Dimensions
10.1” Dimensions... -
Page 16: Dimensions
12.1” Dimensions... -
Page 17: 15" Dimensions
15” Dimensions... -
Page 18: 17" Dimensions
17” Dimensions... -
Page 19: 18.5" Dimensions
18.5” Dimensions... -
Page 20: 21.5" Dimensions
21.5” Dimensions... -
Page 21: System Mounting To A Sub Frame Or Panel
System Mounting to a Sub Frame or Panel With the mounting clamps and screws, it provides fast and easy mounting of the in Touch Panel PC onto an instrument panel or wall panel. To mount the device to a sub frame or panel, do the following: 1. -
Page 22: Engineering Display Stand Mounting To The Unit
5. Hook the mounting clamp into the corresponding mounting pair slots of the display. Then fasten the clamp with the included mounting screw to secure its position on the sub frame or panel. Repeat the same procedure for the remaining mounting clamps. Engineering Display Stand Mounting to the Unit With the engineering display stand mount, it provides ease of use to the unit is provided ease of use when user wants to place the unit on the surface. -
Page 23: Getting Started
Getting Started Connecting to Power Connecting to AC Power Source 1. Plug one end of the terminal block cable firmly to the DC IN Jack. 2. Plug the other end of the terminal block plug to the AC adapter. 3. Connect the AC adapter to the power cord. 4. - Page 24 Turning On Your Device The unit is configured to power on when the power is applied to the device. Adjusting the LCD Display Brightness 1. Tap Start > Control Panel > Hardware and Sound > Power Options. 2. Drag the brightness bar to adjust the brightness level according to your preference Calibrating Touch Screen When turning on the Panel PC for the first time, it is highly recommended to calibrate the touch screen to ensure touch accuracy.
- Page 25 When the screen is touched, the conductive coating makes electrical contact with the coating on the glass. The voltages produced are the analog representation of the position touched. The controller digitizes these voltages and transmits them to the computer for processing. The five-wire technology utilizes the bottom substrate for both X and Y axis measurements.
- Page 26 Touch Screen Calibration (Resistive Touch) Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is Connected, but not calibrated. Follow the procedures below to carry out calibration. 1. Click the PenMount Monitor icon “PM” in the menu bar. 2.
- Page 27 Projected Capacitive Touch screens Projected Capacitive Technology enables touch to be sensed through a protective layer in front of a display, allows the complete system to have unsurpassed ressistance to impacts, scratches and vandalism. It is also unaffected by moisture, heat, rain and other fluids making it ideal for outdoor applications.
-
Page 28: Connectors And Pin Assignment
Turning Off Your Device To shut down your device, do the following: 1. Tap Start > Shut down. 2. Wait for your Panel PC completely turn off before disconnecting the power cord (if necessary). Connectors and Pin Assignment Power The device offers 24 VDC power input with the terminal block. Grounding help limit the effects of noise due to electromagnetic interference (EMI). -
Page 29: Serial
Serial Use a serial cable to plug user serial device into the embedded computer’s serial port. Serial ports have male DB9 connectors and can be configured for RS-232, RS-422, or RS-485. The pin assignments are shown in the following table: Signal Name Signal Name DCD_A... -
Page 30: Sata
SATA Signal Name Signal Name CN11 +V12S +12V1 PRSNT1# +12V2 +12V3 +V12S +V12S RSVD1 +12V4 GND1 GND6 +V12S SMCLK JTAG2 SMDAT JTAG3 GND2 JTAG4 +3.3V1 JTAG5 JTAG +3.3V2 3.3VAUX +3.3V3 WAKE# PWRGD +V5S RSVD2 GND7 +V5S GND3 REFCLK+ HSOP_0 REFCLK- +V5S +V5S HSON_0... - Page 31 BIOS Setup Keys The following keys are enabled during POST: Function Enters the BIOS setup menu. Display the boot menu. Lists all bootable devices that are connected to the system. With cursor ↑ and cursor ↓ and by pressing <ENTER>, select the device used for the boot.
- Page 32 Main Immediately after the [DEL] key is pressed during startup, the main BIOS setup menu appears: BIOS setting Description Setting options Effect This is current time setting. The time is Adjustment of the Set the time in the System Time maintained by the time format [hh:mm:ss]...
- Page 33 BIOS Advanced Setup Utility BIOS Setting Description Enable and disable BIOS support for Intel Active Management Intel AMT Support Technology. Enable and disable the boot interruption <Ctrl+P> to call up Intel Intel AMT Setup Prompt Management Engine BIOS Extention (MBEx) configuration page. Enable Client Initiated Remote Access (CIRA) Fast Call for Help.
- Page 34 Configures system System Component Enter Opens submenu component settings Network stack Configures network stack Enter Opens submenu configuration settings Configures CSM: Enable/Disable, Option CSM Configurations Enter Opens submenu ROM execution settings, etc. Configures SDIO SDIO Configurations Enter Opens submenu parameters USB Configuration Configures USB settings Enter...
- Page 35 User can enable or Enable USB 3.0 is enable USB 3.0 Support disable USB 3.0 (XHCI) Disable USB 3.0 is disable controller support. This is a workaround for Disable Disables this function XHCI Hand-off OSs without XHCI hand- Enable Enables this function off support.
- Page 36 Chipset – North Bridge Parameters BIOS Setting Description Setting Effect options Provides onboard graphics- Intel IGD Configuration related configuration Enter Opens submenu options. IGD – LCD Control Configures IGD – LCD setting Enter Opens submenu Provides power saving Graphic Power configuration options for the Enter Opens submenu...
- Page 37 USB controller, such as Enable / Disable USB Port 0 enabling/disabling a specific this function USB port and support for Enable / Disable USB Port 1 certain features. this function Enable / Disable USB Port 2 this function Enable / Disable USB Port 3 this function PCI Express...
- Page 38 Security Allows user to configure an administration or user password, user must enter the administrator or user password at system startup and when entering BIOS setup. BIOS Setting Description Setting Effect options Displays whether or not an Administrator Password administrator password has Enter Enter Password been set.
- Page 39 Security – Secure Boot Menu BIOS Setting Description Setting options Effect Disables this Disable function Displays the current boot Secure Boot state. Enables this Enable function Disables this Disable function Allows user to configure the Secure Boot Mode secure boot mode. Enables this Enable function...
- Page 40 Boot BIOS Setting Description Setting Effect options Allows user to configure the Set the prompt Setup Prompt Timeout number of seconds to stay in Enter timeout BIOS setup prompt screen. Enables or disables Remains On NumLock feature on the Boot NumLock State numeric keypad of the keyboard after the POST Remains Off...
- Page 41 Specifies the boot order for Enter the a specific device type, such submenu that as hard drives, optical present the Hard Drive BBS Priority Enter drives, floppy disk drives, devices of the and devices that support same type are Boot from LAN function. connected.
- Page 42 Saves the Enter <Yes> changes Reset the system after Save Changes and Reset Return to the saving the changes. Esc <No> BIOS Setup Main Menu Saves the Enter <Yes> changes Reset system setup without Discard Changes and Reset Return to the saving any changes.
-
Page 43: Hardware Modification
Hardware Modification Installing the Hard Disk in the Hard Drive Bay This Device supports one solid state drive (1.8” & 2.5”), no tools are required to upgrade or replace this hard disk. To replace/upgrade, disconnect the device from the power source and do the following to perform this task 1. - Page 44 c. Take out SSD Card bracket. d. You can replace SSD card by unscrewing four screws as shown in the picture. Note: four screws are packed in the packing list. e. There is a SD card hole in the side of the machine. You can replace SD card from there.
- Page 45 Gently screw the screws. 2. Installing the HDD – 10.1” a. There are two screws to deal with when enclosing or removing the chassis. Gently remove two screws.
- Page 46 b. Take the storage cover beside the HMI. c. You can put or remove HDD into the machine by pulling the HDD bracket. d. There is a SD hole in the side of machine. You can replace SD card from there.
- Page 47 3. Installing the HDD – 12.1”/15”/21.5” a. There are two screws to deal with when enclosing or removing the chassis. Gently remove two screws. b. You can put or remove HDD into the machine by pulling the HDD bracket.
- Page 48 c. You can remove HDD by unscrewing four screws in the HDD bracket. Note: four screws are packed in the packing package. d. There is a SD hole in the side of machine. You can replace SD card from there.
-
Page 49: Maintenance
Maintenance Regular Cleaning and Maintenance Before Cleaning: Make sure the device is turned off. Disconnect the power cable from any AC outlet. When Cleaning: Never spray or pour any liquid directly on the screen or case. Wipe the screen with a clean, soft, lint-free cloth. -
Page 50: Ais Support
(888) 485-6688. New Product Satisfaction Return AIS tests all of its products to help ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned for repair, you can submit request at http://www.aispro.com/support/rma-request...
