- Page 1 USER MANUAL 10.1” Touch Panel PC PMW10ID3S-H1-4RT Rev 1.0 May, 2013...
- Page 2 • Room Information Display User Guide PMW10ID3S-H1-4RT 10.1” Multi-Touch Panel PC Multi Touch Analog Resistive 4-wire Fanless All-in-one Panel PC Ultra-low power with Intel Atom D2550 processor Automation: I/O Ports for HMI/SCADA PMW10ID3S-H1-4RT User Guide - American Industrial Systems age 2...
-
Page 3: Table Of Contents
Serial COM port............................10 USB ports..............................10 VGA port for 2nd industrial monitor.......................10 Speaker ports top side ..........................10 Mother Board ..............................11 Product Overview ............................11 BIOS.................................11 Main Memory ............................12 Chipset ..............................12 PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 3 Storage Device ............................12... - Page 4 Paper back recovery manual........................14 12 VDC Power supply ..........................15 Standard AC Power cord ..........................15 American 3 Prong ............................15 Phoenix to power supply prewired ......................15 Wire for screw connectors ..........................15 PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 4 Product Dimension ............................16...
- Page 5 Mounting the Panel PC ..........................16 Panel mount hardware ...........................17 Dimensions .............................17 Make a rectangle hole to match the panel dimensions.................18 To use the mounting clips, panel must not exceed 12 mm..............18 PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 5...
-
Page 6: Copyright
Recycle or dispose in accordance with local, state, or federal Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG. For lamp specific disposal information check WWW.LAMPRECYCLE.ORG PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 6... -
Page 7: Usage Notice
Do not operate the product under the following conditions: • Extremely hot, cold or humid environment. Areas susceptible to excessive dust and dirt. Near any appliance generating a strong magnetic field. In direct sunlight. PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 7... -
Page 8: Introduction
• Contrast Ratio 500:1 • 75 x 75 VESA Mount Dimensions (W x H x D) 286 x 182 x 49.5 mm • • OS: Windows Embedded Standard 7 or Windows XP Embedded PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 8... -
Page 9: Back Panel I/O Port
RJ-45 jacks. • LAN data collection / storage Why 2 Ethernet ports • WAN separate and secure • PLC / machine control interface • Camera for security or machine vision PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 9... -
Page 10: Serial Com Port
• Use of the Panel PC without blocking the view of critical Gages • Add remote viewing outside the control room • Locate the second display closer to the action • Room Information Display Speaker ports top side PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 10... -
Page 11: Mother Board
BIOS AMI BIOs (detailed instructions exist on the CD shipped with the panel) Just after power on, pressing the Del key will open the BIOs configuration application. PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 11... -
Page 12: Main Memory
Designed for CE/FCC Display type Antiglare, Hard-Coating (3H) with EWV film 10.1” diagonal, Active matrix TFT LCD Frame Rate average 60 Hz Aspect Ratio 16:10 (Widescreen) Active/Area 220.416 (H) x 129.15 (V) mm PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 12... -
Page 13: Native (Optimal) Resolution
▪ Robust design with aluminum NEMA 12, NEMA 4, IP52, IP54, IP65 ratings ▪ Technical support for drivers, hardware, troubleshooting procedures and general system issues ▪ Customer service and sales support for product selection, order management, and warranty status PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 13... -
Page 14: Package Content
Package Content Driver CD for touch screen and other features Recovery CD for restoring back to factory condition Paper back recovery manual PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 14... -
Page 15: 12 Vdc Power Supply
This connector has adhesive as a strain relief. Wire for screw connectors This is used when installed in an environment that already has 12 volts available. A second phoenix connector is supplied without adhesive. PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 15... -
Page 16: Product Dimension
Product Dimension PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 16... -
Page 17: Mounting The Panel Pc
Mounting the Panel PC Panel mount hardware Dimensions PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 17... -
Page 18: Make A Rectangle Hole To Match The Panel Dimensions
Make a rectangle hole to match the panel dimensions. To use the mounting clips, panel must not exceed 12 mm. PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 18... - Page 19 PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 19...
