P5Q-E specifications summary

CPU
Chipset
System Bus
Memory
Expansion Slots
Multi-GPU Support
Storage
LAN
IEEE 1394
xii
LGA775 socket for Intel
Core™2 Quad / Core™2 Duo / Pentium
Celeron dual-core / Celeron
®
Compatible with Intel
Intel 45nm Multi-Core CPU support
®
* Refer to www.asus.com for Intel CPU support list
Intel P45 / ICH10R with Intel
®
Technology
1600 / 1333 / 1066 / 800 MHz
4 x DIMM, max. 16GB, DDR2 1200 / 1066 / 800 /
667 MHz, non-ECC, un-buffered memory
Dual channel memory architecture
* Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lists).
** When installing total memory of 4GB capacity or more,
Windows 32-bit operation system may onlyl recognize
less than 3GB. Hence, a total installed memory of less
than 3GB is recommended.
2 x PCI Express 2.0 x16 slots, support ATI CrossFireX™
technology at x8 link (PCIe x16_1 blue, PCIe x16_2
black*)
1 x PCI Express x16 slot at max. x4 link (black)
2 x PCI Express x1 slots
2 x PCI slots
*PCIe 2.0 x16_2 slot (black, at max. x8 link)
Supports ATI CrossFireX™ technology, up to Quad
CrossFireX™
Intel ICH10R Southbridge:
®
- 6 x SATA 3.0 Gb/s ports
- Intel Matrix Storage supporting SATA RAID 0,1,
®
5, and 10
Marvell 88SE6121 controller:
- 1 x Ultra DMA 133/100/66 for up to 2 PATA devices
- 1 x External SATA 3.0 Gb/s port (SATA On-the-Go)
Silicon Image SIL5723 controller (Drive Xpert
technology):
- 2 x SATA 3.0 Gb/s ports
- Supports EZ Backup and Super Speed
Dual Gigabit LAN controllers
Marvell 88E8056 / 88E8001 Gigabit LAN controller
®
featuring AI NET2, Teaming and Redundant
LSI L-FW3227 controller supports 2 x IEEE 1394a ports
®
(one at midboard; one at back panel)
(continued on the next page)
Core™2 Extreme /
®
Processors
®
05B/05A/06 processors
®
Fast Memory Access
®
dual-core /
®
