- Page 1 IR Vandal Dome Camera 사용 설명서 MANUAL 용 서 650TVL...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.
-
Page 4: Table Of Contents
■ Contents --------------------------------- 6 1.Features --------------------------------- 7 2. Cable Connection & OSD Control --------------------------------- 8 3. Setup Menu Operation --------------------------------- 19 4. Troubleshooting --------------------------------- 20 5. Dimensions --------------------------------- 21 6. Specifications... -
Page 5: Features
1. Features ☺ High Resolution 620 TV Lines Clear image quality has been achieved by employing a SONY CCD with 410,000(effective) pixels, which provides a horizontal resolution of 620 TV lines. ☺ Excellent Sensitivity The built-in high sensitivity COLOR CCD enables a clear image even in 0Lux (B/W, IR-LED ON) ☺... -
Page 6: Cable Connection & Osd Control
2. Cable Connection & OSD Control 1) Cable Connection ( DC12V Type ) (Dual Type DC12/AC24V) 2) OSD Control ① 3AXIS BRACKET - Please loosen screws and fix tilted and panned position. ③ LENS : Vari-Focal Auto Iris Lens ( 2.8mm ~ 12.0mm / F1.2 ) with ICR OSD PCB - SETUP button : Used for the menu display. -
Page 7: Setup Menu Operation
3. Setup Menu Operation 5. Setup Menu Operation •Please press the SETUP button to set OSD menu. The SETUP menu is displayed like under the picture on the monitor. SETUP LENS EXPOSURE WHITE BAL BACKLIGHT DAY& NIGHT COLOR SPECIAL RESET EXIT •... - Page 8 Down buttons so that the indicates EXPOSURE. Select a desired mode using the UP and DOWN buttons. ① SHUTTER You can select either auto or manual shutter. • FLK: Select this when you experience picture flicker, which can happen when there is a clash with the frequency of the installed lighting.
- Page 9 The screen color can be adjusted by using the WHITE BALANCE function. Please select the mode you wish to operate by pressing the LEFT or RIGHT button. ①ATW1: This automatically finds white color from color temperature between 2000~18,000°K. ② ATW2: This automatically finds white color from temperature between 4000~12,000°K. ③...
- Page 10 • GAIN – Adjust GAIN of BLC area. (LOW, MIDDLE, HIGH) • HEIGHT – Adjusting height of up-down in BLC AREA SEL. AREA1 ARA STATE area GAIN MIDDLE • WIDTH – Adjusting left-right width in BLC area HEIGHT IIIIIIIIIIIIIIIIIIIII 3 WIDTH IIIIIIIIIIIIIIIIIIIII 4 •LEFT/RIGHT - Moving left-right in BLC area.
- Page 11 DOWN buttons so that the arrow indicates “DAY NIGHT”. Please select the mode you wish to operate by pressing the LEFT or RIGHT button. ① COLOR : The picture is always displayed in color. ② AUTO : The mode is switched to ‘Color’ in a normal environment, but switches to ‘B/W’ mode when ambient illumination is low.
- Page 12 When the camera has white defect in the CCD with ages, user can restore it using OSD menu. Before pressing the Start menu, you have to cover camera lens using lens cap SPECIAL Select ‘FUNCTION’ key from SETUP menu and press Set key to change ‘FUNCTION’ setup.
- Page 13 • If you press the SETUP button after moving the cursor to CLR, all the letters will be erased. If you want to correct a letter, please move the cursor to the arrow at the bottom left of the screen and press 'SET'. •...
- Page 14 ▶ ON: If ‘MOTION’ function is active, character of person is flickering on right above position when motion is detected on selected area. MOTION DETECTION Setting •AREA SEL: Select the programmed area. •AREA STATE: Turn on and off the programmed motion area. •...
- Page 15 ④IMAGE IMAGE ADJ. SPECIAL LENS SHAD CAM TITLE 2D DNR MOTION MIRROR PRIVACY FONT COLOR → PARK LINE CONTRAST IMAGE ADJ. ↙ SHARPNESS LANGUAGE ENGLISH DISPLAY VERSION NEG. IMAGE RETURN RETURN - LENS SHAD. User ought to control lens shading at the areas of operating AGC because each lens has difference brightness.
- Page 16 SPECIAL CAM TITLE MOTION PRIVACY PARK LINE IMAGE ADJ. ↙ LANGUAGE ENGLISH VERSION RETURN ⑥VERSION It’ll be appears in the menu for effective management of the products ⑦RETURN Press this button to reverse previous screen RESET Be careful when this button press. If you press this button, all saved memory will be delete. EXIT Use this button to be out of menu and all you changed will be save automatically.
-
Page 17: Troubleshooting
4. Troubleshooting If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. • Nothing appears on the screen. Check that the power cord and line connection between the camera and monitor are fixed properly. -
Page 18: Dimensions
5. Dimensions... -
Page 19: Specifications
6. Specifications ▪ GENERAL Signal system NTSC Image Sensor 1/3” Sony HAD CCD Total Pixels 811(H) Χ 508(V) 795(H) Χ 596(V) 768(H) Χ 494(V) 752(H) Χ 582(V) Effective Pixels Resolution 620 TV lines Scanning Frequency 15.734KHz(H), 60(V) 15.625KHz(H), 50(V) Shutter Speed 1/60 ~ 1/100,000 sec 1/50 ~ 1/100,000 sec Min.
