D-MAX DIC-5430DV Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
DISTRIBUTED BY

Advertisement

loading

Related Manuals for D-MAX DIC-5430DV

Summary of Contents for D-MAX DIC-5430DV

  • Page 1 DISTRIBUTED BY...
  • Page 2 Super Wide Dynamic Range IR Vandal Dome Camera 사용 설명서 MANUAL 용 서 DIC-5430DV...
  • Page 3 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 4 1. Features Our WDR IR camera is a superb wide dynamic range camera which achieves 120dB max(102dB typical) of dynamic range of the image by implementing PIXIM's Seawolf digital imaging system. With Seawolf digital imaging system, - Delivers high-resolution, crystal clear images that accurately capture every aspect of any scene - Offers the highest resolution of 690TVL(horizontal) - Ultra-wide dynamic range imaging accurately captures all of the critical details in a...
  • Page 5 2. Cable Connection and OSD Control 1) Cable Connection ( DC12V Type ) (Dual Type DC12/AC24V) 2) OSD Control ② SETUP button : Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. ③...
  • Page 6 3. Setup Menu Operation 1) In the menu Use ▲, ▼ buttons to move menu, ◀, ▶ buttons to change the settings and press button shortly to select or enter. button stands for MENU or ENTER button. 2) Entering menu Press button longer than 2 sec on the back of camera.
  • Page 7 4) EXPOSURE To enter EXPOSURE menu, press button at MAIN>EXPOSURE. EXPOSURE Default Descriptions EXPOSURE Descriptions In NTSC system, the entire color tone on the monitor may continuously <WDR MID> Medium level of the dynamic range control for each PRESETs. move reddish and greenish. WDR HIGH Increases the dynamic range control.
  • Page 8 5) DAY/NIGHT To enter EXPOSURE menu, press button at MAIN>DAY/NIGHT>AUTO... IMPORTANT!!! IMPORTANT!!! DAY->NIGHT and NIGHT->DAY operations must be examined and verified at the final step of the installation. Block the lens for a few seconds for NIGHT mode and release and let it return to DAY mode. If camera stays at NIGHT mode more than 10sec, increase N-->D THRES a little and repeat the fore-mentioned steps.
  • Page 9 6) 3D NR To enter EXPOSURE menu, press button at MAIN>3D NR 3D NR Default Descriptions Determines the depth of Three Dimensional Noise Reduction. DEPTH High value reduces the noise strongly but the comet effect may occur for the fast moving object and vice versa. 7) LENS SELECT To enter EXPOSURE menu, press button at MAIN>LENS SELECT>DC...
  • Page 10 PICTURE Factory PICTURE Factory Descriptions Descriptions CONTROL Default PICTURE Factory CONTROL Default Descriptions Sets ATW Normal, ATW Desat, ATW Xtnd or MANUAL. CONTROL Default Sets ATW Normal, ATW Desat, ATW Xtnd or MANUAL. ATW NORMAL – Compensates automatically in range of 2800K-7500K. Sets ATW Normal, ATW Desat, ATW Xtnd or MANUAL.
  • Page 11 SPECIAL Default Descriptions If it is set to ON and motion is detected, MOTION message will MOTION appear on the monitor. See ‘7.9.1 MOTION ’ for settings. If set to ON, it is available up to 6 privacy masks. PRIVACY MASK See ‘7.9.2 PRIVACY menu’...
  • Page 12 Up to 6privacy area can be programmed in size, position and mask color. Use joystick to change size, position and mask color. button at ,ON..>, the button, the Right after pressing Right after one more pressing 1st zone appears on top-left corner in orange. 1st zone changes to blue.

  • Page 13: Save And Exit

    D-EFFECT Default Descriptions FREEZE Image freezes and shows the still image at the moment when set to ON.. OFF(Normal display), H-FLIP(left & right flipped), V-FLIP(upside down FLIP flipped), H/V-FLIP(left & right flipped and upside down flipped.) Direction of joystick control should be flipped if V-flip is flipped to H/V-flip. D-PTZ Able to set digital zoom up to x12 and digital PAN/TILT if zoom ratio >1.

  • Page 14: Manual Mode

    If there are problems in operation, please refer to the items below. If the problem persists, Troubleshooting please contact the agent you purchased this product from Problems Troubleshooting • Please check the power connection. Nothing appears on the screen. • Please check the video signal line connection. •...
  • Page 15 5. Dimensions...

  • Page 16: Specifications

    6. Specifications Model name NTSC Image Device 1/3" CMY Color DPS SENSOR (Pixim Seawolf D8800C series) Effective Pixels 768(H) x 540(V) TV system NTSC, 525lines / 2:1interlace PAL, 625lines / 2:1interlace Scan frequency. 59.94Hz(V), 15.734Khz(H) 50Hz(V), 15.625Khz(H) Synchronization Internal/Line lock (Default: Internal) H.
