Summary of Contents for D-MAX DIC-700PM
- Page 1 IR Dome Camera MANUAL 680 TVL...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.
- Page 4 ■ Precautions Only use the camera under conditions It can cause the image quality to be where temperatures are between poor. -10°C and +50°C. Be especially careful to provide ventilation when operating under high temperatures Severe lighting change or flicker can It is one of the most important parts of cause the camera to work improperly.
-
Page 5: Table Of Contents
■ Contents --------------------------------- 6 1.Features --------------------------------- 7 2. Cable Connection & OSD Control --------------------------------- 8 3. Setup Menu Operation --------------------------------- 16 4. Troubleshooting --------------------------------- 17 5. Dimensions --------------------------------- 18 6. Specifications... -
Page 6: Features
1. Features ■SONY 1/3" 480K/570K-Effective Pixel Ex-view HAD CCD II Minimum 0.1 Lux (F1.2, 50 IRE), LED On : 0 Lux ■High Resolution: More than 680 TV Lines This camera has realized high resolution of 680 TV lines using the top-notch full digital image processing, 12 Bit A/D serial signal processing and special algorithm technologies. -
Page 7: Cable Connection & Osd Control
2. Cable Connection & OSD Control 1) Cable Connection 2) OSD Control ① 3AXIS BRACKET - Please loosen screws and fix tilted and panned position. ③ LENS : Vari-Focal Auto Iris Lens / Fixed Lens ③ OSD PCB SETUP button : Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. -
Page 8: Setup Menu Operation
3. Setup Menu Operation •Please press the SETUP button to set OSD menu. The SETUP menu is displayed like under the picture on the monitor. • if it has been selected. You may move up/down to use another function by up/down buttons and change the status by pressing left/right buttons. - Page 9 •AUTO (HIGH LUMINANCE) - AUTO IRIS Select this to control the shutter speed automatically. -SHUT+AUTO IRIS Select AE control on the medium and high brightness side -Brightness Select the high and medium brightness side reference (LOW LUMINANCE) -AGC Select AE control on the low-brightness side -Brightness Select the low brightness side reference •MANUAL...
- Page 10 •ATW - SPEED Adjusts the pull-in speed ATW - DELAY CNT Sets the time-based hysteresis of ATW - ATW FRAME Sets the pull-in frame magnification - ENVIROMENT Sets the pull-in frame(indoor/outdoor)of ATW •USER1 - B-GAIN Used for operating the B gain in the WB fixed gain mode -R-GAIN Used for operating the R gain in the WB fixed gain...
- Page 11 BACKLIGHT SETUP MENU •OFF LENS AUTO Backlight compensation OFF SHUTTER/AGC AUTO •BLC WHITE BAL BACKLIGHT Backlight compensation ON PICT ADJUST •HLC MOTION DET High light compensation ON NEXT EXIT SAVE ALL PICT ADJUST SETUP MENU LENS AUTO SHUTTER/AGC AUTO WHITE BAL BACKLIGHT PICT ADJUST MOTION DET...
- Page 12 •LUMINANCE Sets the extent of the luminance compression (LOW/MID/HIGH) •CONTRAST Sets the extent of the contrast enhancement (LOW/MIDDLE/MID/MIDHIGH/HIGH) MOTION DET SETUP MENU LENS AUTO SHUTTER/AGC AUTO WHITE BAL BACKLIGHT PICT ADJUST MOTION DET NEXT EXIT SAVE ALL •DETECT SENSE: Sets the motion detection sensitivity •BLOCK DISP OFF: Controls the ON/OFF status of the motion detection block display •BLACK DISP ENABLE: The display switches to the "dead band setting"...
- Page 13 PRIVACY SETUP MENU PRIVACY DAY/NIGHT AUTO CAMERA ID SYNC LANGUAGE ENGLISH CAMERA RESET BACK EXIT SAVE ALL •AREA SEL: Selects the mask frame to be adjusted •TOP: Sets the top side of the mask frame selected by the AREA SEL parameter •BOTTOM: Sets the bottom side of the mask frame selected by the AREA SEL parameter.
- Page 14 the Day status. -NIGHT→DAY Set the threshold for identifying the Day status from the Night status. •B/W -BURST Burst signal OFF enable, Burst signal ON •COLOR The picture is always displayed in color. The function is used to set the noise reduction SETUP MENU PRIVACY -NR MODE...
- Page 15 •↑↓→ ← The camera ID cursor moves •CLR The character selected by the camera ID cursor is cleared •POS The display switches to the camera ID display position setting screen SYNC •INT SETUP MENU Internal mode PRIVACY DAY/NIGHT AUTO •LL Line lock mode CAMERA ID SYNC...
-
Page 16: Troubleshooting
Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from Problems Troubleshooting • Please check the power connection. Nothing appears on the screen. • Please check the video signal line connection. •... -
Page 17: Dimensions
5. Dimensions... -
Page 18: Specifications
6. Specifications MODEL IR DOME CAMERA Signal system NTSC Image Sensor 1/3” Sony 480K/570K, Ex-view super HAD CCDⅡ Total Pixels 1020(H)X508(V) 1020(H)X596(V) Effective Pixels 976(H)X494(V) 976(H)X582(V) Resolution 680 TV lines (B/W 750 TV Lines) Scanning frequency 15.734KHz(H), 60(V) 15.625KHz(H), 50(V) Shutter speed 1/60~1/10,000 sec 1/50~1/10,000 sec...
