D-MAX DIC-5830DV Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
IR Vandal Dome Camera
MANUAL
사용 설명서
DIC-5830DV
용 서
650TVL, D-FOG

Advertisement

loading

Related Manuals for D-MAX DIC-5830DV

Summary of Contents for D-MAX DIC-5830DV

  • Page 1 IR Vandal Dome Camera MANUAL 사용 설명서 DIC-5830DV 용 서 650TVL, D-FOG...
  • Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 ■ Warning The camera needs periodic inspection. Contact an authorized technician for inspection. Stop using your camera when you find a malfunction. If you use your camera around smoke or unusual heat for a long time, fire may be caused. Do not Install the camera on a surface that can not support it.

  • Page 4: Table Of Contents

    ■ Contents --------------------------------- 6 1.Features --------------------------------- 7 2. Cable Connection & OSD Control --------------------------------- 8 3. Setup Menu Operation --------------------------------- 19 4. Troubleshooting --------------------------------- 20 5. Dimensions --------------------------------- 21 6. Specifications...

  • Page 5: Features

    1. Features ☺Ultra High Resolution 650 TV Lines Clear image quality has been achieved by employing a double-speed SONY CCD with 410,000(effective) pixels, which provides a horizontal resolution of 650 TV lines. ☺Visual Distance & Smart IR It is 0.1lux at color mode and its LED will be lit at lower light enabling that observer could see object in the distance of 30M.(visible distance 30M) In addition, the Smart IR feature protects saturation when object is too close to the camera.

  • Page 6: Cable Connection & Osd Control

    2. Cable Connection & OSD Control 1) Cable Connection ( DC12V Type ) (Dual Type DC12/AC24V) 2) OSD Control ① 3AXIS BRACKET - Please loosen screws and fix tilted and panned position. ③ LENS : Vari-Focal Auto Iris Lens ( 2.8mm ~ 12.0mm / F1.2 ) with ICR OSD PCB - SETUP button : Used for the menu display.

  • Page 7: Setup Menu Operation

    3. Setup Menu Operation Menu Structure • LENS DC / VIDEO / MANUAL EXPOSURE SHUTTER AUTO / FLK / MANUAL / 1/60 LOW / MIDDLE / HIGH / OFF SENSE-UP AUTO / OFF RETURN BACK LIGHT OFF / DWDR / BLC / HSBLC WHITE BAL ATW / AWB / AWC-SET / MANUAL DAY &...
  • Page 8 wish to change mode. When the LEFT or RIGHT button is pressed, available values and modes are displayed in order. Please keep pressing the button until you get to the mode you wish to operate. ④ Please select 'EXIT' and then press the SETUP button to finish the setting. Note) •...
  • Page 9 LOW / MIDDLE /HIGH • AREA: Select area and then adjust size and position of the area. DEFAULT: Initialize all data you set. ▶ DWDR When there are both bright and dark areas at the same time, this mode makes both areas distinctive.
  • Page 10 Please select the mode you wish to operate by pressing the LEFT or RIGHT button. ▶ COLOR: The picture is always displayed in color. ▶ AUTO: The mode is switched to ‘Color’ in a normal environment, but switches to ‘B/W’ mode when ambient illumination is low.
  • Page 11 7. F-DNR (Defog) This camera supports DEFOG function which does a process of clearing blurred image caused by fog and snow by analyzing the brightness of input image and compensating the color of the image ▶ OFF: Deactivates F-DNR. ▶ F-DNR MANUAL F-DNR MANUAL This function is operated manually 1.
  • Page 12 AREA: Select the programmed area that can be set up MOTION to 4 areas. 1. AREA AREA DISPLAY: Turn on and off the programmed 2. AREA DISPLAY ON↙ 3. VALUE IIIIIIIIIII 0~100 motion area. 4. MOTION VIEW VALUE: Adjust motion sensitivity of the programmed 5.
  • Page 13 SHARPNESS: Adjust sharpness of the video picture IMAGE ADJ MONITOR: Select the kind of the monitor (LCD / CRT) 1. SHARPNESS IIIIIIIII 0~31 OSD COLOR: User can select OSD color 2. MONITOR CRT↙ 3. LENS SHADING ON↙ ▶ CRT: Select this menu when using a CRT monitor. 4.
  • Page 14 phase of multiple cameras using the power synchronization function (Line-Lock) without using a synchronization signal generator. INT : Internal Synchronization Type • L/L : Power Synchronization Type, Line-lock • Press the SET button and you can select a desired phase between 0 and 359. synchronization.

  • Page 15: Troubleshooting

    4. Troubleshooting If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. • Nothing appears on the screen. Check that the power cord and line connection between the camera and monitor are fixed properly.

  • Page 16: Dimensions

    5. Dimensions...

  • Page 17: Specifications

    6. Specifications ▪ GENERAL Signal system NTSC Image Sensor 1/3” Sony HAD CCD∥ Total Pixels 811(H) Χ 508(V) 795(H) Χ 596(V) 768(H) Χ 494(V) 752(H) Χ 582(V) Effective Pixels Resolution 650 TV lines (B/W 0Lux) Scanning Frequency 15.734KHz(H), 60(V) 15.625KHz(H), 50(V) Shutter Speed 1/60 ~ 1/100,000 sec 1/50 ~ 1/100,000 sec...
