2.2.4

Layout contents

Slots
1. DDR2 DIMM slots
2. PCI slots
3. PCI Express x1 slot
4. PCI Express x16 slots
Jumper
1. Clear RTC RAM (3-pin CLRTC)
Rear panel connectors
1. PS/2 mouse port (green)
2. Serial port
3. IEEE 1394a port
4. Center/Subwoofer port (orange)
5. Rear Speaker Out port (black)
6. Line In port (light blue)
7. Line Out port (lime)
8. LAN 1/2 (RJ-45) port)
9. USB 2.0 ports 1 and 2, 3 and 4
10. USB 2.0 ports 1 and 2, 3 and 4
11. Microphone port (pink)
12. Side Speaker Out port (gray)
13. External SATA port
14. Optical S/PDIF Out port
15. Coaxial S/PDIF Out port
16. PS/2 keyboard port (purple)
2-4 Chapter 2: Hardware information
Page
2-13
2-21
2-21
2-21
Page
2-23
Page
2-24
2-24
2-24
2-24
2-24
2-24
2-24
2-24
2-25
2-25
2-25
2-25
2-25
2-26
2-26
2-26
