- Page 1 Installation Guide WT-C 500 WT-C 750 © Danfoss A/S (Dept./Init.), 2014-05 VIILD102...
- Page 2 Danfoss A/S is not liable or bound by warranty if these instructions are not adhered to during installation or service. The English language is used for the original instructions. Other languages are a translation of the original instructions. (Directive 2006/42/EC) ©...
-
Page 3: Technical Data
Volume, coil litre 4x3,5 6x3,5 Length, coil 4x12 6x12 Max. pressure, hot water heater bar/MPa Max. pressure, coil bar/MPa Max. immersion heater length Height (incl. feet) 1730 1830 Net weight Immersion heater max. output © Danfoss A/S (Dept./Init.), 2014-05 VIILD102... -
Page 4: Electrical Installation
3. The hot water tap can only be shut off when the water heater is filled, which is when only water comes out of the tap (initially an air-water mixture comes out of the tap). VIILD102 © Danfoss A/S (Dept./Init.), 2014-05... -
Page 5: Water Temperature
If the valve does not work satisfactory, it must be replaced. • If there is a risk of freezing, the water heater must be drained. • In the event of malfunctions - contact the installer. © Danfoss A/S (Dept./Init.), 2014-05 VIILD102... - Page 6 500 litres Test pressure 4,3 bar Working pressure 3 bar Rated temperature 100 °C Weight 142 kg Dimensions WT-C 500 Height (mm) 1730 Dimensions (mm) 696 x 760 Required ceiling height for tilting: min. 1840mm VIILD102 © Danfoss A/S (Dept./Init.), 2014-05...
- Page 7 Volume hot water accumulator 750 litres Test pressure 4,3 bar Working pressure 3 bar Rated temperature 100 °C Weight 157 kg Ø Dimensions WT-C 750 Height (mm) 1830 Diameter (ømm) Required ceiling height for tilting: min. 2085mm © Danfoss A/S (Dept./Init.), 2014-05 VIILD102...
- Page 8 Internet: www.heating.danfoss.com, www.thermia.com Danfoss assumes no responsibility whatsoever for any errors occurring in catalogues, brochures or other printed material. Danfoss reserves the right to make changes to (the design of) its products with no prior warning. The same applies to products already on order provided that the previously agreed specifications remain unchanged.
