Dear Customer,
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfil your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
To get the most out of your new machine, we recommend that you read
the operating instructions before using the machine. The operating
instructions also include information on how you can help protect the
environment.

Operating Instructions

Tumble dryer

T884XLHP
WARNING: Read the instructions before using the machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T884XLHP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asko T884XLHP

Summary of Contents for Asko T884XLHP

  • Page 1: Operating Instructions

    Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Table Of Contents

    CONTENTS BEFORE USING YOUR MACHINE FOR THE SETTINGS FIRST TIME You can carry out the following settings Language selection Language Laundry labels Child-safe SAFETY INSTRUCTIONS CARE AND CLEANING General Cleaning the lint filter Safety Emptying the condensed water container Installation Cleaning the evaporator filter and evaporator Transport/winter storage Cleaning the auto filter...

  • Page 3: Before Using Your Machine For The First Time

    BEFORE USING YOUR MACHINE FOR THE FIRST TIME LANGUAGE SELECTION You will be prompted to select the display language when you have connected your machine and start it for the first time. Do as follows: 1. Turn the programme selector to choose from: US English, English, Svenska, Dansk, Norsk, Suomi, Français, Deutsch, Italiano, Espanol, Русский, Nederlands.

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS GENERAL SAFETY Read the operating instructions and keep • The machine must not be used for drying items that them in a safe place! have been dry-cleaned at home or fabrics that may contain residues of flammable liquids. •...
  • Page 5 SAFETY INSTRUCTIONS To minimize the risk of fi re in a tumble dryer, Vented dryers the following should be observed: • There has to be adequate ventilation to avoid the • Items that have been spotted or soaked with back fl ow of gases into the room from appliances vegetable or cooking oil constitute a fi re hazard burning other fuels, including open fi res, when and should not be placed in a tumble dryer.Oil-aff...

  • Page 6: Child Safety

    SAFETY INSTRUCTIONS CHILD SAFETY WARNING! DO NOT ALLOW CHILDREN TO PLAY WITH THE TUMBLE DRYER. • If the door is opened when a programme is running the garments may be very hot, with a risk of burn injuries. • The tumble dryer does not start automatically when the door is closed (if a child pulls the door shut from the inside, for example).

  • Page 7: Description Of The Tumble Dryer

    DESCRIPTION OF THE TUMBLE DRYER 1. Main power switch 5. Lint filter 2. Condensed water container 6. Outer door 3. Panel 7. Steamer and filter 4. Serial Number...

  • Page 8: Advice And Tips Before You Tumble-Dry

    ADVICE AND TIPS BEFORE YOU TUMBLE-DRY STATIC ELECTRICITY Here are some tips that may help you before you begin tumble-drying. To reduce the risk of static electricity in the laundry after tumble drying you can: HAVE THE CLOTHES BEEN SPUN? •...

  • Page 9: Tumble Drying

    TUMBLE DRYING Below are step-by-step instructions to help you achieve and buttons, fasten belts, sort the items and adjust the the best possible tumble-drying results. load and temperature. Press the main power switch until the display lights. SORT YOUR FABRICS Open the door, load the items and then close the door.

  • Page 10: Selecting Options

    TUMBLE DRYING SELECTING OPTIONS Delayed Start By selecting options, you can tailor a drying programme First select which programme you want to use and to suit your requirements. The available options depend then select Delayed Start by pressing the + button. The on the selected programme.

  • Page 11: Drying Programme Finished

    TUMBLE DRYING DRYING PROGRAMME FINISHED The text Done appears on the display when the programme is finished. If the Anti crease option has been selected, the drum will rotate for three seconds per minute for two hours after the programme is finished. The compressor’s cooling fan continues to run after the program fi nishes, but stops automatically or when any button/knob is activated.

  • Page 12: Programme Chart

    TUMBLE DRYING PROGRAMME CHART Here we present the energy and time consumption of a few different programmes. The table shows the effect of using different spin speeds when washing the load. Consumption can vary depending on room temperature, humidity, load, variations in the power supply and selected options.

  • Page 13: Settings

    SETTINGS YOU CAN CARRY OUT THE FOLLOWING SETTINGS • Language • Child-safe You will be prompted to select the display language when you have connected your machine and start it for the first time. LANGUAGE Do as follows: 1. Turn off the machine using the main power switch. 2.

  • Page 14: Care And Cleaning

    CARE AND CLEANING CLEANING THE LINT FILTER EMPTYING THE CONDENSED WATER CONTAINER The lint filter must be cleaned after each load. 1. Lift the filter from the holder in the door. 2. Lift the filter from the holder in the door. Open the lint filter.

  • Page 15: Cleaning The Evaporator Filter And Evaporator

    CARE AND CLEANING CLEANING THE EVAPORATOR FILTER AND EVAPORATOR Clean the evaporator and the evaporator filter at the intervals shown on the machine’s display or more often. 1. Turn off the Main power switch and open the outer door. 2. Remove the plinth. RECOMMENDATION: Wash the sponge filter in the washing machine after 30 drying cycles (use the rinse or quick wash program).

  • Page 16: Cleaning The Auto Filter

    CARE AND CLEANING CLEANING THE AUTO FILTER Clean the filter at the intervals shown on the machine’s display or more often 1. Pull the condensed water container out and up. 2. Unscrew and remove the auto filter. Sealing 3. Rinse the auto filter clean with water. 4.

  • Page 17: Troubleshooting

    TROUBLESHOOTING ERROR MESSAGES NOTE! • If Over Flow appears on the display, the condensed When starting the tumble dryer for the first time or water container is full or the evaporator filter is after a long period without use, you may notice a slight blocked.

  • Page 18: Technical Information

    TECHNICAL INFORMATION TECHNICAL DATA Height: 850 mm Width: 595 mm Depth: 745 mm Weight (net): 59 kg Cylinder volume: 145 l Max. drying capacity: 10 kg Speed: 50-55 rpm Rated power: See type plate. Drum material: Stainless steel Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel Setup: Stacking or freestanding...

  • Page 19: Service

    SERVICE BEFORE CONTACTING THE SERVICE DIVISION See the Troubleshooting and Care and cleaning chapters to see whether you can rectify the problem. If you need to contact the service division, make sure that you know the model designation, type designation and serial number.The model designation (1) can be found on the first page of the operating instructions and on the machine panel.

  • Page 20: Installation

    INSTALLATION How to assemble the stack: WARNING! 1. Undo the screw on the back of the ASKO washing Do not start the machine until it has been in position for machine as shown in the figure. 24 hours. If for some reason the tumble dryer needs to be laid down for transport or service, it must be laid on its left side viewed from the front.

  • Page 21: Condensed Water

    INSTALLATION 5. Fasten or undo the rear feet of the appliance until it is fully level, either on the floor or on the washing machine. CONDENSED WATER The machine is supplied as shown in Option 1 (inset). This means that the condensed water is pumped into the condensed water container, which must be removed and 6.

  • Page 22: Door Hanging

    DOOR HANGING 1. Hinge pins (top and bottom) 4. Locking hook 2. Cover plate 5. Hinges (left + right side) 3. Plastic plugs (on the upper and lower edges) 6. Plinth...

  • Page 23: Follow These Instructions

    DOOR HANGING You can choose whether the door is hung on the right or the left. Follow these instructions: 1. Remove the plinth. 2. Remove the hinge, two screws 3. Lift the door up and remove it. Support the door at the same time.

  • Page 24: Quick Guide

    The text End appears on the display when the programme is finished. Clean the lint filter after each load. Turn off the main power switch. Close the door. We reserve the right to make changes. www.asko.com TD80.2 HP T884XLHP AU/NZ en (11-14)
