artisan 1988-MDZ Instruction Manual

Single needle high speed dry lubricated lockstitcher with thread trimmer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1988-MDZ
Single Needle High Speed Dry Lubricated Lockstitcher With
Thread Trimmer

Instruction Manual

Parts Catalog
Artisan Sewing Supplies, LLC. San Francisco, CA 94103

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1988-MDZ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for artisan 1988-MDZ

Summary of Contents for artisan 1988-MDZ

  • Page 1: Instruction Manual

    1988-MDZ Single Needle High Speed Dry Lubricated Lockstitcher With Thread Trimmer Instruction Manual Parts Catalog Artisan Sewing Supplies, LLC. San Francisco, CA 94103...

  • Page 3: Table Of Contents

    ----- CONTENTS ----- PR E C AU TION S B E F O RE S T A RTING OPE R A TION ..............1 S a f e t y pr ec a u t i on s ........................... 1 Pre c au t i on be f ore S t a r ti ng Oper ati on ·················...

  • Page 4: Precautions Before Starting Operation

    PRECAUTIONS BEFORE STARTING OPERATION Safety precautions ( 1) When turning the power on, keep your hands and fingers away from the area around/under the needle and the area around the pulley. ( 2) Power must be turned off when the machine is not used,. (3) The power must be turned off before tilting the machine head, installing or removing the "V"...

  • Page 6: Adjustment Of The Amount Of Oil For Hook

    4) If the tip of the oil level indicator drops below the line in he oil check window during operation, replenish the oil 2) Adjustment of the amount of oil for hook turn the oil level adjustment screw, and adjust amount of oil for hook.

  • Page 7: Precaution For Position Detector

    Precaution for position detector A light type detection element is used in the detector. Thus, take care not to adhere dust or oil on the de­ (1 ) tector plate sewing machine pulley is removed for adjustments, etc. If dust or oil does adhere, wipe off with a soft cloth while taking care not to scratch the detector plate.

  • Page 8: Threading

    Threading Raise the thread take-up lever to its highest position and thread the upper thread in the following order..-- - - Thread ----:- --------( 6) Left to right 3) Adjusting of stitch length & reverse lever Push lever (1) Rotate the drop feed dial while depressing the reverse lever and then, pressing the push lever, when making the stitch length shorter.

  • Page 9: A Dj U S T M En T Of T He T Hre A D G Ui D E

    Adjusting of the thread guide Thread guide position Left Middle Right �ceD) �8 � � � Materials Heavy Medium Light Polyester #50 to #60 Polyester Cotton Polyester Thread(Ref) Cotton Vinyl on #50 to #60 Vinylon #30 or more #50 to #80 Refer to the table above, and adjust according to the stitching conditions, the material and thread 5) Adjusting of pressure of presser foot Pressure of the presser foot can be adjusted by...

  • Page 10: A Dj U S T M En T Of U Pper T Hre A D T En S I On

    7 ) Adjusting of upper thread tension ( l ) Upper thread tension can be adjusted by Thread take up spring thread tension nut. (2) Upper thread is to be adjusted according to the lower thread tension. (3 ) For special fabric sewing with special thread. the desired tension can be obtained by adjusting the strength and operating range of thread take-up spring.

  • Page 11: Thread Wiper(For Machine Equipped With Thread Wiper)

    9) Thread wiper(for machine equipped with thread wiper) (1 ) When the thread wiper is operated, in next sew­ ing at starting point the end of upper thread does not remain on the surface of fabric. ( 2) Turn the switch OFF when not required. The switch is located in the wiper solenoid cover be­...

  • Page 12: A D . I U S T M Ent O F F Eed Do G He I Gh T A N D I N C L I N Ati

    11) Adjustment of feed dog height and in­ clination (l) As a standard, the eccentric shaft CD mark on the left of the horizontal feed arm is set to the direct left side, and the feed dog height is set to O.Snnn (maximwn) as shown in the figure.

  • Page 13: A Dj Us T M En T Of F Eed T I M I Ng

    1 3) Adjustment of feed timing (l) Adjust by changing the position of the vertical feed eccentric ring. (2) As a standard, the vertical feed timing Is set to when the screw CD on the bearing bushing is linear with screw @on the vertical feed eccen- tric ring.

  • Page 14: Adjustment Of Knife Engagement

    15) Adjustment of knife engagement Position of fixed knife (1) As a standard, the dimension between the fixed knife's end and the needle center is 2.5mm (2) The standard relation of the knife (left) and fi x ed re. As a standard, Di­ knife is shown in the fi mension A is 0.3nmi (3) When Dimension A is too large, the three piece...

  • Page 15: Sp E C! F L Ca T I On S

    SPECIFICATIONS Material weight Light to medium 5,000rpm Max. speed Stitch length Oto 4nnn Needle bar stroke 31.Snnn Hand Lifter Presser foot 6111111 clearance Knee lifter 13 111111 Needle type DBX 1 #14 Hook (for thread tri1m11ing) Full rotation automatic lubrication (standard) Bobbin case With spring for dry nm prevention Bobbin...

  • Page 16: Part S Ca T Al O G

    A.ARMB., ED AND ITS A CCESSORIES � &- � \. � 13 1 ,9 / J \ � j n � @- 3 5 I / - (2 1) , 21 � �- ]," f @ • 2 (2 9) (38) - 13 -...
  • Page 17 A.ARM BED AND ITS ACCESSORIES Fig. Part No. Description Pcs. Remarks H67!9N8001 R ubber ring H67!8N8001 Bobbin winder wheel A.03 H007013050 E-type stop ring 5 H6725N8001 Bobbin winder cam H431050060 Socket sets screw M5x6 HB2252N072 Bobbin winder base H6723N8001 Cam shaft H6722N8001 Spacer HA !001-12150 Screw 9/64(40)x 11...

  • Page 18: A R M Be D & I T S A Cc E Ss Or I E S

    CCESSORIES ARM BED AND ITS A ·· � 2 � � 1 3 1 (®-- f � ,: 1 l� 6 � � � � � "-- 1, ®- 3 5 ( 3 8) - 15 -...
  • Page 19 A.ARM BED AND ITS ACCESSORIES Fig. Part No. Description Pcs. Remarks A4 4 H674488001 Screw l/2(24)x8 SM l/2( 24)x8 H675888001 0-ring HA 700821 IO Screw 9/64( 40)x6 SM9/64( 40)x6 HAIOOB2140 Thread guide HA300B2080 Set screw I 5/64(28)x6 SM I 5/64(28)x6 Thread take-up cover A4 9 HB225 ll081...

  • Page 20: S Ew I N G M E C H A N I Sm

    B.SEWINGM ECHANISM - 17 -...
  • Page 21 B.SEWING MECHANISM Fig. Part No. Description Pcs. Remarks HAIOOC2020 Set screw l 5/64(28)x IO SM15/64(28)x 1 0 H671618001 Thread take-up support shaft H671818001 B earing support H671718001 Needle bearing H67191800 1 Thrust collar HAIOOB21 IO Set screw l l/64(40)x5.5 SM! l/64(40)x5.5 H671018001 Thread take-up lever link HB2254!072...
  • Page 22 C.FEEDING AND FEED LIFTING & ROTATING HOOK SHAFT MECHANISM "'- ") �(11) � 4 9 i � �, � , 50 29 ) 5 2 ( ® f � ,@ ; ;\� � '-;:: 7 � � .,,,.,/ (29) - 19 -...
  • Page 23 C.FEEDING AND FEED LIFTING & ROTATING HOOK SHAFT MECHANISM Fig. Part No. Description Pcs. Remarks H6725D8001 Thrust co llar HA341 ID308 Set screw l 5/64(28)x7 SM l 5/64(28)x 7 H6720D8001 Needle bearing H6722D8001 Feed lifting connecting rod HA30082 I 60 Screw l l/64(40)xJO SMI l/64(40)x IO 11672308001 Connecting block H3205GI 1 1 4 Socket set screw M5x5...
  • Page 24 C.FEEDING AND FEED LIFTING & ROTATING HOOK SHAFT MECHANISM � "l � (11) _ / , 41 ,.'' / 45 � � 4 9 i � 35 g..- 34 l§l ,,, ,J I �, /" ,� � ' 50 (29) ·...
  • Page 25 C.FEEDING AND FEED LIFTING & ROTATING HOOK SHAFT MECHANISM Fig. Part No. Description Pcs. Remarks HA710E0691 Thread trimmer cam HA710E0692 Socket set screw I /4( 40)x IO SMl/4(40)x 10 H6705F8001 Lower shaft HA706Cl 182 Oil wick HA104EOOl l Screw complete HA706C1182 Feed rock shaft crank pin HA73 I 1C606 Screw I l /64(40)x5 SMI l/64(40)x5...

  • Page 26: S Tit C H Re G U L A Tor M E C H A N I Sm

    D.STITCH REGULATOR MECHANISM � 2 3 22 � ' � \ � r· 3 5 � ( 3 0 ) �� ' � /��" °"" ""' (43) ""� � (44) � __________________________ c __ _ - 23 -...
  • Page 27 D.STITCH REGULATOR MECHANISM Fig. Part No. Description Pcs. Remarks HA700C2060 Connecting rod stud HB2253G081 F eed regulating link HAI l IG0683 Screw l l/64(40)x 1 2 SMI l/64(40)xJ2 IJ04 11132252(,08 1 Feed regulator l-lAI!3F0684 Screw l 5/64(28)x8.5 1)()5 SM l 5/64(28)x8 5 HAIOOC2020 Set screw l 5/64(28)x IO SM l 5/64(28)x IO H6713B8001 B ushing for feed regulator...
  • Page 28 D.STITCH REGULA TOR 1\1.ECHANISM �w r· � � @ (3 0 ) \ � ¥ � � ·, .. ' � §!' � � � ,, 3 8 � � � "-. ""- � C'.l (4 3) "' � � �...
  • Page 29 D.STITCH REGULATOR MECHANISM Fig. Part No. Description Pcs. Remarks 1)4 4 H3230K075 I Set screw I l/64(40)x 10 SM! 1/64(40), 10 H6708E8001 Stitch length adjusting crank HA731 IC006 Screw 9/64(40)x8.5 SM9/64(40)x8.5 HA7311CE06 Link stud H6723E8001 Spring 1)49 H6707G800 I Eccentric shaft 1)50 H6713G8001 Coil spring - 26 -...

  • Page 30: P Re Ss Er Foot M E C H A N I Sm

    E.PRESSER FOOT MECHANISM � � � "--... k � � = / � \ � - 27 -...
  • Page 31 E.PRESSER FOOT MECHANISM Fig. Part No. Description Pcs. Remarks HA30082170 Screw I l/64(40)x8.2 SM! l/64(40)x8. 2 Hl204F0651 Presser bar lifter lever HA300H2080 0-ring H6728J8001 Preser bar lifter cam H6708J7101 J-:05 Knee lifter lever (left) HAI07H0662 H inged screw 3/l 6(28)x7 SM3/l 6(28)x 7 H6712J8001 Knee lifter rod...

  • Page 32: K N I Fe A C Tuatin G M E C H A N I Sm

    F.KNIFE ACTUATING MECHANISM (5 ) (5 ) 1 5 �o ( 5) () ', � './ - �1 7 � ( 4) - 29 -...
  • Page 33 F.KNIFE ACTUATING MECHANISM Fig. Part No. Description Pcs. Remarks H67l7K7101 Thre ad trimming sole noid assy H6715K8001 Solenoid bracket HA 710N0683 Nut H6732K8001 Holder HA300C2030 Screw I 1/64(40)x8 SM! l/64(40)x8 HA700N0080 Screw l 5/64(28)x 1 2 SMI5/64(28)x 1 2 H200000360 Screw I l/64(40)x6.2 SM I I /64( 40),6 2 H6727N8001 Cor d holder HA30082170 Screw l l/64(40)x8.2...
  • Page 35 F.KNIFE ACTUATING MECHANISM Fig. Part No. Description Pcs. Remarks HA7121N404 Thread finger HA712JN304 Screw 9/64( 40)x 5 SM9/64(40)x5 HA7121N204 Fixed blade F4 7 l-lA7121NI04 Bracket for fixed blade l-IA7121N604 Set screw 9/64( 40)x8.5 SM9/64(40)x8.5 HA7121N704 N ut 9/64(40) SM9/64(40) HA7311CC06 Screw 9/64( 40)x6.5 SM9/64(40)x6.5 HA712N0696 Spring suppo rt collar HA712N0697 Trimming lever spring...

  • Page 36: T O Uc H B A C K M E C H A N I Sm & D E T E C T Or M E C H A N I Sm

    G.TOUCH BACK MECHANIS1"1 & DETECTOR MECHANISM �' ( 1) - 33 -...
  • Page 37 G.TOUCH BACK MECHANISM & DETECTOR MECHANISM Fig. Part No. Description Pcs. Remarks HA30082 l 70 Screw l l /64( 40)x8.2 SM! l/64(40)x8.2 116 727N800 I Cord holder H6726N8001 Corel holder (i04 HB22638072 Solenoid (i05 l ll-322648081 Solenoid plate HA30082170 Screw I l/64(40)x8.2 SM! l/64(40)x8.2 HA764 I 8319 Terminal pin(male) HA7!2Q0069 Connector cap...

  • Page 38: H J W I Per M E C H A N I

    H. WIPER MECHANISM - 35 -...
  • Page 39 H.WIPER MECHANISM Fig. Part No. Description Pcs. Remarks 110 I H6708M8001 Solenoi d cover for wiper mech 1102 HA 708P0669 Screw -Sw-Pw M3x6 M3x6 1-103 1-1671 IM8001 Wiper solenoi d f- 1 04 HA 708P66 IO Conn ecting I-SD 1105 HB2254M081 Threa d wiper switch 1- 1 06 I- I A7641B319 Terminal pin (male)
  • Page 41 I.OIL LUBRICATION MECHANISM Fig. Part No. Description Pcs. Remarks HA300C2030 Screw 1 1 /64(40)><8 SMI l/64(40)x8 l-16729P8002 Oil wick l-1671 I P8001 Oil wick holder H3200G2030 H older l-1 674188001 G asket for bottom cover 1-16722P8001 Oil sight window l-16712P8001 Oil cap H6709P8001 Oil inlet...
  • Page 42 J.ACCESSORIES �------- - 39 -...
  • Page 43 J.ACCESSORIES Fig. Part No. Description Pcs. Remarks JO I HA307. I 0067 Table hinge with rubber cushion � .I02 HA300.12050 Vihration preventing rubher HA300.12060 Vibration preventing rubber 1()3 . I0 4 HAI 1580706 Thread take-up spring .105 HAIOOC2160 Needle set (DBx 1-2# 14) .106 HS68990204 Hexagon socket screw key 3...
  • Page 48 SHANGHAI HUIGONG N0.3 SEWING MACHINE FACTORY The description covered in this manual is subject to change for improvement of the commodity without notice 2004.2. Printed...
