FEATURES
PS542 ATMO-
SCOPE
®
Power Supply
C) PD525 Pod
F) Power Indicator
Light
E) AF110 Low Static
Air Filter
Fuse, 6.3A
A) Activates System Power.
B) Turns on and shuts off Pump.
C) Tool Holder minimized heat dissipation when Tool is not in use.
D) Includes (1) LN230 Liner, (1) RS199 Cleaning Sponge and RS243
Leveling Pad.
E) Filters air coming in to the Pump. Acts as silencer
F) Lights when power is on.
G) Regulates air flow to Tool. (connect to FA069)
H) Lights when Pump is running.
I) Can accomodate 2 more 120V soldering Tools.

SPECIFICATIONS:

• 120 V, 60 Hz, 150 W
• Weight: 4.6 lbs. (2.09 kgs.)
• Temperature range: 400
• Temperature regulation: ± 6
• Voltage leakage from tip to ground less than 2 MV
• Tip to ground resistance less than 2 ohm
• Maximum pressure: 18 psi.
• UL listed
E) AF110 Low Static
Air Filter
F - 800 F (205 C - 425
0 0 0
F (±3 C)
0 0
G) Air Control
Valve
C)
0
A) Power Switch
B) Pump Switch
H) Pump Indicator Light
D) SH230
Sponge
Holder
I) AC Receptacle
Static Safe
