Scag Power Equipment STR Operator's Manual page 47

Section 8
Ref. Part.
No. Number Description
1 45811 Foot Plate
2 04019-03 Serr. Fl. Hex Nut, 5/16-18
3 48114-04 Grease Fitting
4 45734 Frame, Cutter Deck Support
5 04021-09 Hex Locknut, Elastic Stop, 3/8-16
6 44120 Rod, Deck Prop - L.H.
7 04017-16 Serr. Fl. Hex Head CPSCRW, 5/16-18 x 3/4
8 04030-03 Lockwasher, 5/16
9 04040-15 Flatwasher, 5/16 (.375 x .875 x .083)
10 421932 Guard, U-Joint
11 04021-10 Hex Locknut, Elastic Stop, 5/16
12 04012-06 Setscrew, Hex Socket, 3/8-16 x 1/2
13 04041-07 Flatwasher, 3/8 (.391 x .938 x .105)
14 04063-20 Key, 1/4 x 1/4 x 1.00
15 481263 Drive Shaft
16 04001-09 Bolt, Hex Head, 5/16-18 x 1.00
17 481262 Hinge, Discharge Chute
18 45767 Chute, Cutter Deck
19 04003-12 Carriage Bolt, 5/16-18 x 3/4
20 45764 Cutter Deck
21 04003-23 Carriage Bolt, 3/8-16 x 1.0
22 45766 Adapter, Blade Drive
23 481161 Blade, Cutter - R.H.
24 0404010 Flatwasher, 5/8 (.688 x 1.750 x .134)
25 04030-07 Lockwasher, 5/8
26 04001-131 Bolt, Hex Head, 5/8-11 x 1-3/4
27 481162 Blade, Cutter - L.H.
28 04012-04 Setscrew, Hex Socket, 5/16-18 x 3/8
CUTTER DECK
Ref. Part.
No. Number Description
29 49111
30 45768
31 43022
32 04021-07
33 04001-37
34 48307
35 48006-07
36 48006-06
37 48307-08
38 48307-04
39 48006-05
40 48114-03
41 48307-02
48006-03
42 481311
43 04050-04
44 48100-01
45 422046
46 421928
47 04001-10
48 481346
49 421929
50 44121
51 481264
52 04062-02
53 04066-1
54 04003-11
55 422109
43
Caster Wheel Yoke Assy (Includes 30 hru 34)
Yoke, Caster Wheel
Sleeve
Hex Locknut, Elastic Stop, 1/2-13
Bolt, Hex Head, 1/2-13 x 5-1/2
Caster Wheel Assembly (Includes 35 thru 41)
Retainer, Caster Wheel
Roller Bearing, Caster Wheel
Tapered Hex Nut, 5/16-18
Rim Pair, Caster Wheel
Hub Assembly with Bolts
Grease Fitting
Tire
Inner Tube
Isolator, Rubber
Retainer Ring, 1.00
Bushing, Oilite, .877 ID
Spacer
Mounting Bracket - Front
Bolt, Hex Head, 5/16-18 1-1/4
Gearbox Assembly
Mounting Bracket - Rear
Rod, Deck Prop - R.H.
Bushing, Cutter Deck Support
Hairpin, Cotter, .080 x 1.19
Quick Pin
Carriage Bolt, 3/8-16 x 1-1/4
Bracket, Anti-Rotation
