OPERATOR'S MANUAL
TURF RUNNER
MODEL STR
FROM SERIAL NUMBER 60001 TO 69999
PART 03028

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STR Operator's and is the answer not in the manual?

Questions and answers

Related Manuals for Scag Power Equipment STR Operator's

Summary of Contents for Scag Power Equipment STR Operator's

  • Page 1 OPERATOR'S MANUAL TURF RUNNER MODEL STR FROM SERIAL NUMBER 60001 TO 69999 PART 03028...
  • Page 2 WARNING FAILURE TO FOLLOW SAFE OPERATING PRACTICES MAY RESULT IN SERIOUS INJURY. * Keep all shields in place, especially the grass discharge chute. * Before performing any maintenance or service, stop the machine and remove the spark plug wire and ignition key. * If a mechanism becomes clogged, stop the engine before cleaning.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SUBJECT PAGE Section 1 - General Information Introduction ..........................1 Directional Reference ......................1 Servicing the Engine and Drive Train Components ............... 1 Section 2 - Safety Information Introduction ..........................2 Signal Words .......................... 2 Before Operation Considerations ................... 2 Operation Considerations .......................

  • Page 4: Subject Page

    TABLE OF CONTENTS (CONT'D) SUBJECT PAGE Section 6 - Adjustments Parking Brake Adjustment ....................23 Travel Adjustments ......................24 Throttle Control and Choke Adjustments................28 Engine Belt Adjustment ....................... 28 Blower Drive Belt Adjustment ..................... 28 Transmission Drive Belt Adjustment ................... 28 Belt Alignment ........................

  • Page 5: Section 1 - General Information

    All information is based upon product information available operating, maintenance and adjustment instructions in this at time of approval for printing. Scag Power Equipment manual. reserves the right to make changes at any time without notice and without incurring any obligation.

  • Page 6: Section 2 - Safety Information

    Section 2 SAFETY INFORMATION 2.1 INTRODUCTION Your mower is only as safe as the operator. Carelessness or The signal word “DANGER” denotes that an extremely operator error may result in serious bodily injury or death. Hazard control and accident prevention are dependent upon hazardous situation exists on or near the machine that could result in high probability of death or irreparable injury if the awareness, concern, prudence, and proper training of...

  • Page 7: Operation Considerations

    Section 2 6. Operator hearing protection is recommended, 13. DO NOT operate without a chute deflector installed; particularly for continuous operation of the mower. keep the deflector in lowest possible position. Wear suitable hearing protection. Prolonged exposure to loud noise can cause hearing impairment or loss. 14.

  • Page 8: Maintenance Considerations

    Section 2 7. Be alert for holes, rocks, and roots in the terrain and 2.5 MAINTENANCE CONSIDERATIONS other hidden hazards. Keep away from any dropoff. Beware of overhead obstructions (low limbs, etc.), 1. Never make adjustments to the machine with the engine underground obstacles (sprinklers, pipes, tree roots, running unless specifically instructed to do so.

  • Page 9: Safety And Instructional Decals

    Section 2 2.6 SAFETY AND INSTRUCTIONAL DECALS WARNING DANGER INSTALL BELT COVER BEFORE OPERATING MACHINE SPINNING BLADE READ OPERATOR'S MANUAL 481039 KEEP CLEAR CONTACT CAN INJURE 48071 WARNING ROTATING BLADES AND BELTS KEEP HANDS, FEET & CLOTHING CLEAR KEEP ALL GUARDS IN PLACE SHUT OFF ENGINE &...

  • Page 10: Section 3 - Specifications

    Section 3 SPECIFICATIONS 3.1 ENGINE General Type ................Heavy Duty Industrial/Commercial Gasoline Brand ..................Kohler Model ..................Command Horsepower ................20 HP at 3600 RPM (Scag Model STR48-20CH) 22 HP at 3600 RPM (Scag Model STR48-22CH) Type ................... 4 Cycle Gasoline, Twin Cylinder, Horizontal Shaft Displacement ................

  • Page 11: Hydraulic System

    Section 3 3.3 TRACTOR (CONT'D) Travel Speed: Forward ................0 - 7.5 MPH Reverse ................. 0 - 3.5 MPH 3.4 CUTTER DECK No. of Blades ................2 Width of Cut ................48" Cutter Blades ................Two (2) 24-3/4" Blades, 1/4" thick, milled edge, 5150 Alloy Steel Deck Drive .................

  • Page 12: Section 4 - Operating Instructions

    Section 4 OPERATING INSTRUCTIONS 1. Ignition Switch (Figure 4-1). The ignition switch is CAUTION: used to start the engine and has three positions; OFF, ON, and START. Do not attempt to operate this mower unless you have read this manual. Learn the location and 2.
  • Page 13 Section 4 5. Ammeter (Figure 4-1). Indicates the condition of Dump Valve Handle the charging system. When the engine is running the needle should be at the positive end of the meter. If the needle is on the negative end of the meter, this indicates a discharge condition and the machine should be taken in for service.

  • Page 14: Safety Interlock System

    Section 4 4.2 SAFETY INTERLOCK SYSTEM 4.4 STARTING THE ENGINE The mower is equipped with a safety interlock system CAUTION: that prevents the engine from starting unless the deck drive is disengaged and the speed control is in neutral. DO NOT USE STARTING FLUIDS. Use of starting The interlock system shuts off the engine if the operator fluids in the air intake system may be potentially leaves the seat with the speed control not in the neutral...
  • Page 15 Section 4 -IMPORTANT- Forward Travel Start practice with a slow engine speed and slow forward travel. -NOTE- Use one hand on both steering levers as shown in Do not push the steering control levers forward Figure 4-5 to minimize overcontrol. when traveling forward.

  • Page 16: Engaging The Deck Drive

    Section 4 Reverse Travel 4.6 ENGAGING THE DECK DRIVE (CUTTER BLADES) CAUTION: 1. Set the throttle at about 3/4 speed. Do not attempt to engage the deck drive at high speed as this shortens Before backing up, observe the rear for persons the electric clutch life —...

  • Page 17: Hillside Operation

    Section 4 4.7 HILLSIDE OPERATION WARNING: To minimize the possibility of overturning, the least dangerous method of operating on hills and terraces is to travel vertically up and down the slope, not horizontally along the slope. Avoid any unnecessary turns and travel at reduced speed. 1.

  • Page 18: Hopper/Side Discharge Operation

    Section 4 4. Fill the fuel tank with fresh, clean fuel at the end of Grass Catching Operation every day of operation. CAUTION: 5. Check the tire pressure. Inflate tires if necessary. Never leave grass clippings in the hopper after mowing.

  • Page 19: Removing Clogged Material

    Section 4 B. Raise the tailgate until the u-bolt on top of the Release the latch holding the tailgate and then hopper engages with the latch on the tailgate lower the tailgate. Be careful when lowering the (Figure 4-11). tailgate. It is spring loaded and will close with some force.

  • Page 20: Moving Mower With Engine Stopped

    Section 4 2. If the blower intake becomes clogged, there could be 4.12 MOVING MOWER WITH ENGINE a distinct change in the sound of the blower and/or STOPPED the mower deck will begin to leave a trail of glass clippings. The clogging will generally develop in the To “free-wheel”...

  • Page 21: Adjusting Cutting Height

    Section 4 4.14 ADJUSTING CUTTING HEIGHT 4.15 TILTING THE CUTTER DECK The mower deck can be adjusted from a height of 1-inch WARNING: to 4-1/2 inches at 1/2-inch intervals. To adjust the cutting height: Do not tilt the mower deck with the mower blades rotating.
  • Page 22 Section 4 Pull Back on Collar Drive Shaft Spindle Figure 4-15 Disconnecting the Drive Shaft 2. Tilt the deck and secure in place with the two prop rods (Figure 4-16). Seat Raised Figure 4-17 Removing The Deck 6. Pull the deck from the tractor as shown in Figure 4-17. B.
  • Page 23 Section 4 2. Install the cutter deck onto the push arm shafts just far enough to hold the deck in place. Align the WARNING: cutter deck discharge chute with the blower intake chute (Figure 4-19) and push the cutter deck all the If the driveshaft is not securely fastened to the way onto the push arm shafts, inserting the discharge spindle shaft it will come off the shaft and spin...

  • Page 24: Section 5 - Troubleshooting Cutting Conditions

    Section 5 TROUBLESHOOTING CUTTING CONDITIONS CAUSE CURE CONDITION Stringers - Occasional Low engine RPM Run engine at full RPM Blades of Uncut Grass Ground speed too fast Slow speed to adjust for conditions Wet grass Cut grass after it has dried out Dull blades, incorrect sharpening Sharpen blades Deck plugged, grass accumulation...
  • Page 25 Section 5 TROUBLESHOOTING (CONT'D) CAUSE CURE CONDITION Uneven Cut on Flat Lift worn from blade Replace blade Ground - Wavy High-Low Blade upside down Mount with cutting edge toward Appearance, ground Scalloped Cut, or Rough Contour Deck plugged, grass accumulation Clean underside of deck Too much blade angle (deck pitch) Adjust pitch and level...
  • Page 26 Section 5 TROUBLESHOOTING (CONT'D) CAUSE CURE CONDITION Scalping - Blades Low tire pressures Check and adjust pressures Hitting Dirt or Ground speed too fast Cutting Very Close to Slow speed to adjust for conditions the Ground Cutting too low May need to reduce ground speed, raise cutting height, change direction of cut, and/or change pitch and level Rough terrain...

  • Page 27: Section 6 - Adjustments

    Section 6 ADJUSTMENTS Parking Remove Cotter Pin Here Brake Brake Rod 6.1 PARKING BRAKE ADJUSTMENT Lever WARNING: Swivel Joint Do not operate the mower if the parking brake is Hold Brake Lever In This Direction not operable. Possible severe injury could result.

  • Page 28: Travel Adjustments

    Section 6 6.2 TRAVEL ADJUSTMENTS Jam Nut Adjusting Rod Neutral or tracking adjustments will need to be made if: Spring Cotter Pin A. The speed control lever is in neutral and the Hold Axle Lever machine creeps forward or backward. (Neutral In This Direction Adjustment) B.
  • Page 29 Section 6 3. If the adjustments are okay and you need to adjust the neutral linkages, proceed with the Neutral Bracket Against Neutral Interlock Switch Pressure Switch Adjustment procedures. If the speed control requires adjustment, adjust as follows: A. Loosen both jam nuts (A & B, Figure 6-6) on the adjusting rod (C).
  • Page 30 Section 6 Handles Aligned Flat Turnbuckle Left Handle Right Handle Speed Control Lever 4.5" L.H. Speed Control Lever Figure 6-6 Neutral and Tracking Adjustments 5. Tighten the jam nuts (D & E) to hold the setting in B. To get both wheels to come out of neutral at the place.

  • Page 31: Tracking Adjustment

    Section 6 Tracking Adjustment -IMPORTANT- Before proceeding with this adjustment, be sure that the tire pressure in the three tires is correct, that the caster wheels turn freely, and that the two transmission drive belts are adjusted for the correct tension.

  • Page 32: Throttle Control And Choke Adjustments

    Section 6 6.3 THROTTLE CONTROL AND CHOKE ADJUSTMENTS These adjustments must be performed by your Scag dealer to ensure proper and efficient running of the engine. Should either need adjustment, contact your authorized Scag service center. 6.4 ENGINE BELT ADJUSTMENT WARNING: Adjusting Nut Before removing any guards, shut the...

  • Page 33: Maintenance Chart

    Section 7 MAINTENANCE 7.1 MAINTENANCE CHART - RECOMMENDED SERVICE INTERVALS HOURS Break-In 40 100 200 500 Procedure Comments (First 10) Check all hardware for tightness Check hydraulic oil level See paragraph 7.3 Check all belts for tightness See paragraph 7.8 Change engine oil and filter See paragraph 7.4 (First 5)

  • Page 34: Lubrication

    Section 7 MAINTENANCE CHART - RECOMMENDED SERVICE INTERVALS (CONT'D) HOURS Break-In 40 100 200 500 Procedure Comments (First 10) Apply grease to fittings See paragraph 7.2 Check hardware for tightness Change engine oil filter See paragraph 7.4 Check hydraulic oil level See paragraph 7.3 Replace engine fuel filter See paragraph 7.5...
  • Page 35 Section 7 + Compatible Greases: Mobilix #2 found at Mobil Service Stations Ronex MP found at Exxon Service Stations Super Lube MEP #2 & Super Stay-M #2 found at Conoco Stations Shell Alvania #2 found at Shell Service Stations Lidok EP #2 found at industrial shops RIGHTSIDE UNDERSEAT LEFTSIDE...

  • Page 36: Hydraulic System

    Section 7 7.3 HYDRAULIC SYSTEM B. Changing Hydraulic Oil The hydraulic oil should be changed after every 500 A. Checking Hydraulic Oil Level hours or annually, whichever occurs first. The oil should also be changed if the color of the fluid has The hydraulic oil level should be checked after the first become black or milky.

  • Page 37: Engine Oil

    Section 7 B. Changing Engine Crankcase Oil After the first 5 hours of operation, change the engine crankcase oil and replace the oil filter. Thereafter, Hydraulic Oil Filter change the engine crankcase oil after every 100 hours of operation or bi-weekly, whichever occurs first. Refer to the Engine Operator’s Manual furnished with this mower for instructions.

  • Page 38: Engine Fuel System

    Section 7 7.5 ENGINE FUEL SYSTEM 7.6 ENGINE AIR CLEANER A. Filling the Fuel Tank A. Cleaning and/or Replacing Air Cleaner Element Fill the fuel tank at the end of each operating day to within 1 inch below the filler neck. Do not overfill. Use For any air cleaner, the operating environment dictates clean, fresh unleaded gasoline with a minimum octane the air cleaner service periods.

  • Page 39: Battery

    Section 7 7.7 BATTERY WARNING: A. Checking Electrolyte Level and Cleaning Electric storage battery fluid contains sulfuric Battery acid which is POISON and can cause SEVERE CHEMICAL BURNS. Avoid contact of fluid After every 40 hours of operation or weekly, whichever with eyes, skin, or clothing.

  • Page 40: Drive Belts

    Section 7 -IMPORTANT- Do not overfill the battery. Electrolyte will WARNING: overflow through the vent tube onto parts of BATTERIES PRODUCE EXPLOSIVE GASES. the machine, resulting in severe corrosion. Charge the battery in a well ventilated space so gases produced while charging can 3.

  • Page 41: Cutter Blades

    Section 7 7.9 CUTTER BLADES 3. Check the blades for straightness by marking the tip position of the blade on the inside of the deck. Then rotate the opposite tip of the blade to the same A. Blade Inspection position. Compare the difference in the blade tip track.

  • Page 42: Tires

    Section 7 Blade Adapter B. Blade Sharpening Blade Adapter -NOTE- If possible, use a file to sharpen the blade. Using a wheel grinder may burn the blade. -NOTE- DO NOT sharpen the blades beyond 1/3 of the width of the blade. Attaching Hardware Attaching Hardware Bolt, Lockwasher and...

  • Page 43: Hopper

    Section 7 7.11 HOPPER 1. Underneath the gearbox is a drain plug. This drain plug is accessible through a hole in the gearbox mounting plate and can be reached from the left side The hopper screen should be cleaned after every 8 hours of the mower.
  • Page 44 Section 7 The fluid level in the cutter deck gearboxes (Figure 7-12) 2. Raise the cutter deck and secure in place with the two should be checked after every 100 hours of operation or prop rods. bi-weekly, whichever occurs first. 3.

  • Page 45: Body, Deck, Hopper And Upholstery

    Section 7 12. Clean and remove the check plug dipstick from the 7.14 BODY, DECK, HOPPER AND center gearbox and fill the gearbox with Mobil UPHOLSTERY SHC630 lubricant until it is full, as indicated on the dipstick. Install the check plug dipstick and tighten CAUTION: securely, then back the dipstick out so that the slot is parallel with the front of the gearbox.

  • Page 46: Cutter Deck

    Section 8 CUTTER DECK STR003...
  • Page 47 Section 8 CUTTER DECK Ref. Part. Ref. Part. No. Number Description No. Number Description 45811 Foot Plate 49111 Caster Wheel Yoke Assy (Includes 30 hru 34) 04019-03 Serr. Fl. Hex Nut, 5/16-18 45768 Yoke, Caster Wheel 48114-04 Grease Fitting 43022 Sleeve 45734 Frame, Cutter Deck Support...

  • Page 48: Sheet Metal

    Section 8 SHEET METAL 19 16 88 89 STR002...
  • Page 49 Section 8 SHEET METAL Ref. Part. Ref. Part. No. Number Description No. Number Description 48015 Battery 04001-40 Bolt, Hex Head, 5/8-11 x 9.00 421197 Cover, Battery 04001-19 Bolt, Hex Head, 3/8-16 x 1.00 04003-12 Carriage Bolt, 5/16-18 04030-04 Lockwasher, 3/8 421197 Box, Battery Spacer...

  • Page 50: Blower Assembly

    Section 8 BLOWER ASSEMBLY 32 31 STR009...
  • Page 51 Section 8 BLOWER ASSEMBLY Ref. Part. Ref. Part. No. Number Description No. Number Description 45827 Chute, Side Discharge 45826 Housing, Blower 04001-19 Bolt, Hex Head, 3/8-16 x 1.0 04021-10 Hex Locknut, Elastic Stop, 5/16-18 04030-04 Lockwasher, 3/8 45819 Outlet, Blower 04041-07 Flatwasher, 3/8 (.391 x .938 x .083) 04040-03...

  • Page 52: Engine And Attaching Parts

    Section 8 ENGINE AND ATTACHING PARTS Part of Engine Part of Engine Part of Engine STR007...
  • Page 53 Section 8 ENGINE AND ATTACHING PARTS Ref. Part. No. Number Description 481364 Guard, Muffler 481258 Muffler 481259 Clamp, Muffler 481257 Exhaust Pipe, Flexible 481275 Relay 04030-02 Lockwasher, 1/4 04010-10 Machine Screw, Round Head, 1/4-20 x 1/2 48136-09 Clamp, 2.25 Dia 481297 Hose, Air Intake 481332...

  • Page 54: Traction Drive

    Section 8 TRACTION DRIVE 16 17 18 7 21 7 21 31 35 60 STR005...
  • Page 55 Section 8 TRACTION DRIVE Ref. Part. Ref. Part. No. Number Description No. Number Description 04001-109 Bolt, Hex Head, 1/4-20 x 1-3/8 43277 Spacer, J-Pull 481230 Pulley, 5.55 OD 481048 Pulley 481235 Belt, Drive 04041-12 Flatwasher, 3/8 (.375 x 1.50 x .06) 48926 Hub, Tapered 04003-21...

  • Page 56: Hydraulic Pump

    Section 8 HYDRAULIC PUMP Overhaul SEAL STR012 SC226G...
  • Page 57 Section 8 HYDRAULIC PUMP Ref. Part. Ref. Part. No. Number Description No. Number Description 481225 Pump, L.H. (Includes items 1 thru 30) HGS2003087 Variable Swash Plate 481226 Pump, R.H. (Includes items 1 thru 30) HG70079 BDT-10L Block Assembly HG2513038 Pump Shaft Kit HG9004800-2506 Pin ST Holder HG2003016...

  • Page 58: Hydro-Gear Axle Assembly

    Section 8 HYDRO-GEAR AXLE ASSEMBLY BRAKE ASS'Y. MODEL #481224 BRAKE ASS'Y. MODEL #481223 SC225G STR013...
  • Page 59 Section 8 HYDRO-GEAR AXLE ASSEMBLY Ref. Part. Ref. Part. No. Number Description No. Number Description 481223 Axle, L.H. (Includes Items 1 thru 36) HG44353 Input Gear, 11 Tooth 481224 Axle, R.H. (Includes Items 1 thru 36) HG44354 Retaining Ring HG62768 Axle Housing Assembly 44094 Brake Assembly, L .H.

  • Page 60: Drive Gearbox

    Section 8 DRIVE GEARBOX STR015...
  • Page 61 Section 8 DRIVE GEARBOX Ref. Part. No. Number Description 481227 Gearbox, Drive SGC203815 Capscrew, Socket Head, 3/8-16 x 1-1/2 SCG200300 Plug, Socket Head Plug, Dipstick SGC210003002828 Casting, Upper SGC200900002617 Shaft Assembly, Cross SGC209843 Seal - 1" SGC00002626 Shaft Assembly, Pinion SGC00002569 Seal, 1-1/8"...

  • Page 62: Deck Drive

    Section 8 DECK DRIVE STR006...
  • Page 63 Section 8 DECK DRIVE Ref. Part. Ref. Part. No. Number Description No. Number Description 481234 Belt, Blower Drive 43369 Nut, Special 04001-109 Bolt, Hex Head, 1/4-20 x 1-3/8 43282 Spacer J-Pull Rod 481233 Pulley, 5.35 OD 48068 Pulley, Idler 48141 Hub, Tapered 45739 Idler Arm, Auxiliary Drive...

  • Page 64: Speed And Steering Controls

    Section 8 SPEED AND STEERING CONTROLS STR008...
  • Page 65 Section 8 SPEED AND STEERING CONTROLS Ref. Part. Ref. Part. No. Number Description No. Number Description 481245 Knob 04021-09 Hex Locknut, Elastic Stop, 3/8-16 04002-04 Hex Nut, 3/8-16 48464 Ball Joint, 3/8-24 R.H. Thread 45753 Lever, Speed Control 04020-14 Hex Nut, 3/8-24 R.H. Thread 481243 Disc, Friction 48590...

  • Page 66: Parking Brake And Dump Valve Linkages

    Section 8 PARKING BRAKE AND DUMP VALVE LINKAGES STR014...
  • Page 67 Section 8 PARKING BRAKE AND DUMP VALVE LINKAGES Ref. Part. Ref. Part. No. Number Description No. Number Description Bracket, Dump Valve Lever 45808 Lever, Dump Valve 04019-02 Serr. Fl. Hex Nut, 1/4-20 04062-02 Hairpin 45810 Mounting Bracket, R.H. Dump Valve 44116 Rod, Brake - L.H.

  • Page 68: Hydraulic Components And Lines

    Section 8 HYDRAULIC COMPONENTS AND LINES STR010...
  • Page 69 Section 8 HYDRAULIC COMPONENTS AND LINES Ref. Part. No. Number Description 48894 Cap, Hydraulic Reservoir Fill 481240 Tank, Hydraulic Oil 48571-02 Cap, 3-4-16 JIC 48810-01 Tee, 3/4-16 JIC x O-Ring 481241 Hose Assembly, Filter Inlet 48603-04 O-Ring, 3/32 x 3/4 ID 48572-02 Union, Tube 481358...

  • Page 70: Electrical System

    Section 8 ELECTRICAL SYSTEM To Hopper Harness STR011...
  • Page 71 Section 8 ELECTRICAL SYSTEM Ref. Part. Ref. Part. No. Number Description No. Number Description 48787-01 Nut, Hex, 1/2-27 481238 Harness, Electrical 48717 Switch, Interlock - Seat 48023 Hourmeter 48522 Switch, Interlock - (Neutral and Hopper) Fuse, 20 Amp 04001-44 Bolt, Hex Head, 1/4-20 x 1/2 48017-02 Key &...

  • Page 72: Hopper

    Section 8 HOPPER 10 11 24 29 SWITCH 390S0071...
  • Page 73 Section 8 HOPPER Ref. Part. Ref. Part. No. Number Description No. Number Description 45762 Frame, Hopper Door 481451 Strap, Hopper Stop 481284 Bumper, Rubber 04019-04 Serr. Fl. Hex Nut, 3/8-16 04019-03 Serr. Fl. Hex Nut, 5/16-18 422241 Insulation, Hopper - Rear 422050 Retainer, Screen 04040-15...

  • Page 74: Hopper Actuator Mechanism

    Section 8 HOPPER ACTUATOR MECHANISM STR004...
  • Page 75 Section 8 HOPPER ACTUATOR MECHANISM Ref. Part. No. Number Description 481254 Motor, Actuator 04015-05 Capscrew, Sockt Head, #10-32 x 1/2 04031-01 Washer, External 481285 Cap, Plastic 04021-01 Hex Locknut, Elastic Stop, 1/4 -20 481291 Lever, Actuator 04021-10 Hex Locknut, Elastic Stop, 5/16-18 481189 Rod End, 5/16-18 R.H.
  • Page 76 Section 8 REPLACEMENT DECALS AND INFORMATION PLATES DANGER WARNING HEAVY DUTY ROTATING BLADES AND BELTS COMMERCIAL SPINNING BLADE KEEP HANDS, FEET & CLOTHING CLEAR KEEP ALL GUARDS IN PLACE SHUT OFF ENGINE & DISENGAGE BLADE KEEP CLEAR 48072 CLUTCH BEFORE SERVICING CLEAR AREA OF DEBRIS BEFORE MOWING CONTACT CAN INJURE USE CAUTION IN DIRECTING DISCHARGE...

  • Page 77: Decals

    Section 8 REPLACEMENT DECALS AND INFORMATION PLATES Ref. Part. No. Number Description 48071 Decal, Danger - Spinning Blades 481040 Decal, Warning - Rotating Blades 48072 Decal, Heavy Duty Commercial 48404 Decal, Metalcraft - Made in USA 48656 Decal, Patent 48318 Decal, 48 481314 Decal, Scag...

  • Page 78: Electrical Schematic

    Section 8 ELECTRICAL SCHEMATIC RELAY ENGINE GROUND ADAPTER BLUE SOLENOID STARTER AQUA WIPER MOTOR BLUE ENGINE BLUE HOPPER SWITCH SEAT SWITCH NEUTRAL SWITCH INSTRUMENT PANEL BLUE HOUR METER BLUE CUTTER ELECTRIC DECK CLUTCH SWITCH SWITCH AMMETER RELAY BATTERY FORWARD STR017...
  • Page 79 Scag, are either incompatible with the Scag mower or adversely affect its operation, performance or durability. Scag Power Equipment reserves the right to change or improve the design of any mower without assuming any obligation to modify any mower previously manufactured.
  • Page 80 © 1996 PART NO. 03028 SCAG POWER EQUIPMENT, INC. PRINTED 7/98 DIVISION OF METALCRAFT OF MAYVILLE PRINTED IN USA...
