Installation and Power On

Installation At-a-glance
The following illustration shows a typical installation scenario for a CIS2000 set-top.
Important: With copy-protected digital content, a reduced display quality can occur if the
IP set-top is not directly connected to the TV. Therefore, connect your TV directly to the IP
set-top and not through a DVD or video recorder.
HDMI and the HDMI
logo are trademarks
or registered trade-
marks of HDMI
Licensing LLC.
HDMI Digital AV
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
1. Connect the IP set-top to a router (IAD) with a CAT5, CAT5e, or CAT6 Ethernet cable.
2. Connect the IP set-top to a TV, monitor, or HDMI-equipped device using an HDMI-to-
HDMI cable.
3. Connect the IP set-top to a power supply.
8
LAN 10/100 Mbits
USB
To Router (IAD)
Y
P L
B
AUDIO
P
R
R
HD 1
IN IN
L
R
Analog Video Composite
Back of HDTV
AUDIO
HDMI
CENTER
CHANNEL IN
ON OFF
AUDIO IN
DVI/HDCP
R L
ANT (75 )
VIDEO
Y
L/ ANT-1
P L
MONO B
AUDIO
R
P
R
OUT
R
HD 2
ANT-2
OUT IN
Restore
factory
Optical
default
settings
Reset Digital Audio IR extender DC IN
