Parrot Multicomm User Manual page 6

Keypad Adapter
Join the connector of the kit's control keypad to the connector on the interface's power cable.
Pin Number
1
2
3
4
7
8
9
10
Pin Number
2
3
Pin Number
1
2
3
4
5
6
7
8
Colour
Yellow / Brown
Grey
Yellow / White
Pink
Brown
Blue / Red
Green / Black
Blue
In case of CK3000 EVOLUTION
Colour
Green
White / Yellow
In case of CK3100 LCD
Colour
Black
Red / Blue
Green / Black
Brown
Green / Red
Grey / Black
Blue
Yellow / Red
Connect the LCD display to the LCD adapter.
