Parrot Multicomm User Manual page 5

PARROT MULTICOMM interface
The Parrot MULTICOMM is powered with 12Vdc having negative to the ground.
The Parrot MULTICOMM 14 ways connector has 5 wires that are important for the right
working:
Connect the power cable of the Parrot MULTICOMM interface to the 14-way connector of
the Parrot MULTICOMM interface.
N° Color
1 Red / Orange 12v Permanent
2 Yellow
3 Pink
4 Green / Black
5 Blue
6 Yellow / White
8 Yellow /Brown
9 Grey
10 White
11 Blue / Red
12 Brown
13 Purple
14 Black
Function
Mute input
V2
V1
Ground
Front view
Back view
