- Page 1 WLAN PCI Adaptor User Manual WLG25PCI...
-
Page 2: Table Of Contents
Table of Contents Introduction Package Contents Minimum System Requirements Connecting the Wireless Adapter PCMCIA MiniPCI III. Installing the Wireless Adapter Uninstalling the Wireless Adapter Configuring the Wireless Adapter Connecting to an existing network Configuration... -
Page 3: Introduction
Introduction Thank you for purchasing the Wireless Adapter.. This Wireless Adapter is easy to use and easy to setup. If you are tired of all those messy wires needed to connect a lap-top to your Home network, then take your networking to the next level with the Wireless Adapter. You will be able to share files, printers and even your High-Speed Internet access wirelessly. -
Page 4: Connecting The Wireless Adapter
Connecting the Wireless Adapter PCMCIA 1. Your computer can be on or off, it will not affect the installation process. Locate an available Type II or Type III PCMCIA slot on your laptop. If you are not sure where this may be, please consult your laptop’s User Manual. 2. -
Page 5: Installing The Wireless Adapter
Installing the Wireless Adapter Note: If you have installed the Wireless Adapter driver before, please uninstall the old version first. 1. After you have installed the Wireless Adapter your computer will display a Found New Hardware Wizard screen, click Cancel to continue. 2. - Page 6 3. Main Menu screen will display, click Install Driver to continue. 4. RALINK Wireless Network Card Setup will install the driver on your system, click Next to continue.
- Page 7 5. Select the Country Channel, and click Next to continue. 6. The installation is now complete. Please click Finish. Note: When you complete the installation, the utility icon will appear on the system tray. If not, it means that the installation failed. Please uninstall the driver and repeat the process.
-
Page 8: Uninstalling The Wireless Adapter
Uninstalling the Wireless Adapter 1. For uninstalling the Wireless Adapter, please go to: Start -> Programs -> Ralink -> RT2500 under Windows environment. Then click Uninstall. 2. Select Remove to uninstall the Wireless Adapter. - Page 9 3. The Confirm Uninstall screen will display, click OK to confirm. 4. Wait for removing the utility. 5. After completing the uninstallation, click OK.
-
Page 10: Configuring The Wireless Adapter
Configuring the Wireless Adapter Double-click the utility icon in your system tray to begin the utility configuration. Connecting to an existing network Select Site Survey Tab, all available Access Points would be listed. Click on the desired Access Point, and click Connect to connect. -
Page 11: Configuration
Configuration Profile The Profile Tab allows you to set values for all parameters by selecting a previously defined profile. To create a profile, click Add, type a profile name and set the corresponding parameters. If one of the profiles is no longer used, you may remove it by clicking the Delete button. - Page 12 Link Status Status The field shows the association status to available Access Point with SSID<->MAC address of the Access Point. Channel Shows the channel on which the connection is made. Link Speed Shows the highest transmit rate of the current association. Throughput This displays the instantaneous wireless Receive and Transmit throughput in Kbits per second.
- Page 13 Site Survey Site Survey Tab lists the features of the available Access Points within range of the Wireless Adapter's signal. Click on the desired Access Point, and click Connect to connect. You may click Rescan to refresh the list. Add to Profile You may select an Access Point, and click Add to Profile to include it to Profile List.
- Page 14 Under Add Profile screen / Authentication and Security Tab, you may set Authentication Type, Disable 802.1x, 802.1x Setting, Encryption, WPA Preshared Key, and Wep Keys. Click OK when you have finished the settings. Or click Cancel to abort your new settings for Add to Profile. Select Profile Tab, you may find the new added profile in Profile List.
- Page 15 ! Statistics The Statistics Tab provides information about the Transmit and Receive frames. ! Advance The Configuration Utility also offers the advanced configuration for user to set the Wireless Adapter under certain network environment. These advanced options include Wireless Mode, Ad hoc wireless mode, TX BURST, B/G Protection, Tx Rate, and Turn Off RF.
- Page 16 About About Tab shows the product version including the detail of Configuration Utility, Driver, EEPROM, and NIC MAC Address.
