Summary of Contents for Maytag 760S

  • Page 1 Use & Care Guide Dishwasher MAYTAG MSE 760 FARS...

  • Page 2: Quick Guide

    Remove large food particles and debris. There is no need to rinse thanks to the Super Cleaning System ™ 2. Dispensing dishwasher detergent The detergent compartment has a small compartment for pre-wash and one for main wash. 3. Ensure that the spray arms can rotate freely 4.

  • Page 3: Table Of Contents

    General Winter storage/Transport Overfill protection Cleaning Packaging materials Scrapping Child safety Child-safe button lock Child-safe dishwashing Protect your children! Dishwasher detergent is corrosive Parts of the dishwasher Technical information Baskets Control panel Dispenser Basic Course Load the baskets correctly Dispensing dishwasher detergent...
  • Page 4 C. Adjusting machines with adjustable foot Adjusting the plinth (Only if you have a kick-plate as an accessory) Screw the dishwasher into place Fitting strip seal 22-24 (on floor plinth covering plate) NB! Not all models Setting water hardness Service &...

  • Page 5: Before Doing Your First Wash

    Check the door Check that the door of the dishwasher fits properly: open the door a little and let it go. Does it stay exactly where you released it? If not, you should check the installation instructions or consult the installer.

  • Page 6: Safety

    • Installation of water, drainage and elec- tricity must be carried out by a qualified professional. • Do not use the dishwasher for any pur- poses other than those stated in these directions for use. • Do not load the dishwasher door or the dishwasher baskets with anything other than dishes.

  • Page 7: Is Corrosive

    To prevent children starting the machine, you can activate a button lock. Proceed as follows: 1. Switch off the dishwasher with the main switch. 2. Hold in the Temperature and Drying buttons, and at the same time switch on the main switch.

  • Page 8: Parts Of The Dishwasher

    Parts of the dishwasher* 1. Knife basket 2. Upper basket 3. Lamp 4. Spray arms 5. Lower basket 6. Cutlery basket 7. Rinse Aid Filling 8. Dishwasher detergent compartment 9. Main switch 10. Program panel 11. Filter 12. Type plate...

  • Page 9: Baskets

    Baskets* Upper basket Lower basket Cutlery basket Knife basket 1. Wine glass shelf 2. Cup rack 3. Folding plate stand 4. Cutlery basket with door and folding handle *Details may differ depending on the model and market!

  • Page 10: Control Panel

    Control panel 1. Program selector 2. Intensive wash 3. Strong wash 4. Normal wash 5. Light wash 6. Quick wash 7. Rinse & Hold Dispenser 8. Temperature 9. Delayed start 5 hours 10. Drying 11. Rinse aid indicator 12. Salt indicator 13.

  • Page 11: Basic Course

    Follow the dosage instructions on the deter- gent package. If your machine is fitted with a water softener, dispense as for soft water. Pour the dishwasher detergent into the dish- washer detergent compartment. There is one compartment for pre-wash and one for main wash, see Dispenser.

  • Page 12: Select Program

    Only use dishwasher detergent Detergent for washing by hand cannot be used as the build-up of foam impedes the machine’s performance. Press the main switch Select program Select a program by pressing the program selector one or more times until the required program is displayed.

  • Page 13: If The Machine Is Switched Off At The Main Switch

    – press it again and the symbol will go out. Press Start/Stop and close the door The dishwasher will now start. It manages the entire wash automatically. Ensure that the door is properly closed or the machine will not start.

  • Page 14: Eco-Dishwashing

    Do not rinse before dishwashing Thanks to the dishwasher’s Super Cleaning System™ you do not need to rinse the dishes under running water before loading them into the machine.

  • Page 15: Fragile Dishes

    Certain types of adhesive cannot withstand machine washing. In such cases the handles can come loose. Wood Wooden articles should only be machine washed if they are labelled as dishwasher proof. Aluminium Aluminium can be dulled by machine wash- ing. However, good quality aluminium...

  • Page 16: Standard Program

    Standard program Program Press Intensive Program wash Options How the machine works Temperature 75°C Pre-wash with SCS* (number) Main wash (number) Rinse & Dry (number) 70°C Final rinse Consumption values Wash time (approx. min)** Energy (approx. kWh) Wash time (approx. min)** Energy (approx.
  • Page 17 Standard program Program Press Quick Program wash Options How the machine works 30˚C Temperature Pre-wash with SCS* (number) Main wash (number) Rinse & Dry (number) Final rinse Consumption values Wash time (approx. min)** Energy 0,02 (approx. kWh) Wash time (approx. min)** Energy (approx.

  • Page 18: Cleaning

    However, if you have calciferous (hard) water, lime deposits can form in the dishwasher. In this case, run a normal wash program with two tablespoons of citric acid in the dishwasher detergent compartment.

  • Page 19: Spray Arms

    CAUTION! Do not use a spray bottle or similar around the door catch. Tip! In order to prevent bad odours in the dishwasher, clean the strips and corners with a dish brush and low-lather detergent.

  • Page 20: Rinse Aid

    Rinse aid Pour in rinse aid Drying proceeds more quickly if you use rinse aid. Machines with indicator on the panel When the rinse aid has run out and more is needed, the rinse aid symbol on the panel lights up*. To fill with rinse aid: 1.

  • Page 21: Salt

    Use coarse salt or spe- cial salt for dishwashers. It is best to fill with salt when you are about to do a wash, as the dishwasher needs to be rinsed out immediately after filling. Proceed as follows the first time: 1.

  • Page 22: Settings

    The button lock will automatically be reactivated after three minutes. Switch off the dishwasher with the main switch. Hold in the Temperature and Drying buttons while pressing the main switch. The temperature, drying and start symbols will flash. Release the Temperature and Drying buttons.

  • Page 23: Setting Water Hardness

    Setting water hardness If you have a dishwasher with a water softener, you may need to change the setting, de- pending on the degree of hardness of the water. Phone your local Water Board to check the water hardness in your area. The dishwasher is set for low water hardness on delivery.

  • Page 24: Setting A Signal

    If you want the machine to signal when the wash is complete, you can program it to do this. The machine is set without a signal by default. Switch off the dishwasher with the main switch. Hold in the Delayed start button at the same time as you press the main switch.

  • Page 25: Fault Indications

    To remove the fault indications from the display, turn the main switch off and then on again. Type of fault Action Too much water Phone service in the dishwasher Fault with water inlet Check that the water tap is open Valve leakage Switch off the water tap and con-...

  • Page 26: Troubleshooting

    The dishes are not clean. Stains or a film on the china. Possible causes • The spray arms are not rotating. • Old dishwasher detergent. NB! Detergent is a perishable. • Incorrect dosage of detergent. • Insufficiently powerful dishwashing program.

  • Page 27: The China Has A Whitish-Blue Sticky Film

    (1 part rinse aid, 1 part water). • Rinse off food residue of this type if you do not intend to start the dishwasher immediately. • Seperate your cutlery into the varians compartments in the basket. Make sure silver and stainless steel are not together.

  • Page 28: Water Remains In The Machine

    Problems Water remains in the machine. Bad odour in the machine The dishes are not sufficiently dry Possible causes pump) can be heard from the machine, this does not stop when the power is switched off using the main power switch. •...

  • Page 29: Performance Information

    Main wash 25 gram Standard detergent. Rinse aid dosage 3. Energy labelling Europe: Dishwasher program: Normal wash 55°C, economy drying Program time: Connection: Test method noise measurement: Example of dishwasher loading EN 50 242 Technical information Height: Width: Weight: Capacity: Water pressure: Connection: Output: *The weight can vary due to varying specifications.

  • Page 30: Installation

    Installation Suggestions on positioning the dishwasher The dishwasher can be built in, fully free- standing or semi-freestanding. CAUTION! Connection to electricity, water and drain- age must be carried out by a suitably quali- fied person. A. Built-in The dishwasher can be built in under a worktop with a working height of 820 - 870 mm.

  • Page 31: Connection To Water Supply

    Connection to electricity A dishwasher fitted with a lead and plug must be connected to an earthed socket. Repairs and maintenance relating to safety or performance must be carried out by a qualified professional.

  • Page 32: Positioning The Machine

    Positioning the machine A. Adjusting machines with six feet (freestanding dishwasher) 1. Adjust the height of the dishwasher with the four steel feet. 2. Lock the feet with the nuts. NB! The dishwasher must not be allowed to lean more than 5 mm.

  • Page 33: Adjusting The Plinth

    Adjusting the plinth (Only if you have kick-plate as accessory) The dishwasher has two kick-plates (certain models). The taller one should be used if the machine is to be 850 - 870 mm high and the plinth depth can be varied between 45 - 105 mm.

  • Page 34: Setting Water Hardness

    Setting water hardness If you have a dishwasher with a water softener, you may need to change the setting, de- pending on the hardness level of the water. Phone your local Water Board to check the water hardness in your area. The dishwasher is set for low water hardness on delivery.

  • Page 35: Service & Guarantee

    Service & guarantee Service Before calling for service, check to see whether the faults is due to something that you can put right yourself. See Trouble shooting pages 26-28. Guarantee For guarantee details, see the guarantee card.

  • Page 36: Own Comments

    Own comments...
  • Page 37 Own comments...
  • Page 38 Own comments...

  • Page 39: Search Words

    Control panel 10, 20 Crystal 3, 5, 15, 26 Cutlery basket 8, 9, 11 Light wash 10, 12, 14 Dishwasher detergent 3, 6, 7, 11, 21 Display 21 Door 5, 13, 19, 30, 40 Drainage 18, 28, 31 Environment 3, 11, 14, 40...
  • Page 40 Art. No: 80 785 78. Rev. 02 • We reserve the right to make changes. Printed on environmentally-friendly paper which meets the demands of Friends of the Earth and the Swedish Society for Nature Conservation.
