- Page 1 User Manual...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ......................3 What Is Included ..........................3 Unpacking Instructions ........................3 Claims ..............................3 Text Conventions ..........................3 Symbols ............................3 Disclaimer ............................3 Product at a Glance ........................4 Safety Notes ............................ 4 2. -
Page 3: Before You Begin
Chauvet assumes no responsibility or liability for any errors or omissions that may appear in this manual. Chauvet reserves the right to update the existing document or to create a new document to correct any errors or omissions. -
Page 4: Product At A Glance
Keep this User Manual for future use. If you sell the product to someone else, be sure that they also receive this document. FCQ (Fog Cleaner Quart) was specifically developed by Chauvet to clean your fog machine. Make sure you use FCQ regularly, no longer than 90 days between cleanings, to increase the life of your product. -
Page 5: Introduction
2. I NTRODUCTION Product Overviews Front Views Back Panel Views IR Sensor Sound Sensitivity Microphone UV Strobe Combo Control Panel Buttons Indicator LED DC Power In Fluid Line Fog Fluid Wired Remote Tank Cover Machine Power In Fuse Holder Fog Fluid Level Fog Nozzle Indicator JAM™... -
Page 6: Product Dimensions
Product Dimensions 21.2 in 537 mm UV Strobe 1.6 in Combo 40 mm 2.2 in 55 mm 8.5 in 215 mm Fog Machine 4.9 in 124 mm 7.1 in 180 mm Page 6 of 15 JAM™ Pack Emerald User Manual Rev. 1... -
Page 7: Setup
3. S ETUP The JAM™ Pack Emerald fog machine has a fixed voltage power supply and it can work Fog Machine with an input voltage of 120 VAC at 60 Hz or 230 VAC at 50 Hz. The listed current rating AC Power indicates the product’s average current draw under normal conditions. -
Page 8: Mounting
Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs. Safety Cable Mounting Clamp (such as CH-05 from Chauvet) (such as the CLP-02 from Chauvet) Mounting Bracket Safety Cable Mounting Diagram (such as CH-05 from Chauvet) -
Page 9: Operation
4. O PERATION Fog Machine Trigger the fogger using the included wired remote. The LED indicator on the remote indicates when the fogger has reached the required operating temperature. Press the Wired Remote button on the remote to momentarily output fog. The length of the wired remote cable is 13 ft (4 m). -
Page 10: Infrared Remote Control
The JAM™ Pack Emerald UV Strobe Combo is compatible with the IRC-6 infrared Infrared remote control from Chauvet. IRC mode will activate at the press of any button on the Remote remote. Control IRC-6 Operation Be sure the IRC-6 remote is pointing directly at the product and there is nothing in between the remote and the product. -
Page 11: Maintenance
Always dry the transparent surfaces carefully after cleaning them. Do not allow the fogger to become clogged. After every 40 hours of continuous operation, use CHAUVET® Fog Cleaner Quart (FCQ) through the system to prevent the accumulation of particulate matter in the heating element. -
Page 12: General Fogger Troubleshooting
6. G ENERAL OGGER ROUBLESHOOTING Symptom Possible Cause Possible Action Clean thoroughly with CHAUVET® FCQ. For full Incorrect fluid instructions, see Fog Machine Maintenance. Refill No output or fog machine with CHAUVET® water-based fog fluid. is spitting fluid Blocked pipe or failing part... -
Page 13: Technical Specifications
7. T ECHNICAL PECIFICATIONS Dimensions and Weight Length Width Height Weight UV Strobe Combo 21.2 in (537 mm) 1.6 in (40 mm) 2.2 in (55 mm) 0.6 lb (0.3 kg) Fog Machine 8.5 in (215 mm) 7.1 in (180 mm) 4.9 in (124 mm) 4 lb (1.8 kg) Note: Dimensions in inches rounded to the nearest decimal digit. -
Page 14: Returns
If you are located in Mexico, contact Chauvet Mexico. · If you are located in Benelux, contact Chauvet Europe BVBA. · If you are located in any other country, DO NOT contact Chauvet. Instead, contact your local distributor. See www.chauvetlighting.com for distributors outside the U.S., UK, Ireland, Mexico, or Benelux. -
Page 15: Contact Us
+32 9 388 93 97 Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux, contact the dealer of record and follow their instructions to request support or to return a product. Visit the Chauvet website for contact information. JAM™ Pack Emerald User Manual Rev. 1...
