Snapshot
LEDsplash™ 200B
LEDPAR200B
Use on Dimmer
Outdoor Use
Sound Activated
DMX
Master/Slave
Auto-ranging
Power Supply
Replaceable Fuse
User Serviceable
Duty Cycle
User Manual
th
CHAUVET, 3000 N 29
Ct, Hollywood, FL 33020 U.S.A
(800) 762-1084 – (954) 929-1115
FAX (954) 929-5560
www.chauvetlighting.com
2010-03-09/15:03
Advertisement
Table of Contents
Related Manuals for Chauvet LEDsplash 200B
Summary of Contents for Chauvet LEDsplash 200B
- Page 1 LEDsplash™ 200B LEDPAR200B Use on Dimmer Outdoor Use Sound Activated Master/Slave Auto-ranging Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual CHAUVET, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com 2010-03-09/15:03...
-
Page 2: Table Of Contents
ABLE OF CONTENT 1. BEFORE YOU BEGIN ... 3 ... 3 HAT IS INCLUDED ... 3 NPACKING NSTRUCTIONS AC P ... 3 OWER ... 3 AFETY NSTRUCTIONS 2. INTRODUCTION ... 4 ... 4 EATURES ... 4 DDITIONAL EATURES DMX C ... -
Page 3: Before You Begin
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET®. LED-PAR200B User Manual EGIN Maximum ambient temperature is Ta: 40° C. Do not operate fixture at temperatures higher than this. -
Page 4: Introduction
Selector switch for sound active or automatic programs Static colors and RGB color mixing with or without DMX controller Built-in automated programs via master/slave or DMX Built-in sound activated programs via master/slave or DMX Additional Features Compatible with CHAUVET® Satellite™ system DMX Channel Values 000~029 000~255 030~199... -
Page 5: Product Overview
Product Overview Power Input (Hardwired cable) Power LED Indicator Microphone Sensitivity Adjustment Knob Bracket Adjustment Knob DIP Switches DMX Out DMX In LED-PAR200B User Manual Satellite™ connection Safety attachment point Fuseholder DMX, Master/Slave Signal LED Indicator Standalone Auto/Sound Selection Switch Bracket Adjustment Knob... -
Page 6: Setup
3. S ETUP Power Warning! All fixtures must be connected to circuits with a suitable Earth Ground. To determine the power requirements for a particular fixture, see the label affixed to the back plate of the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating is its average current draw under normal conditions. -
Page 7: Operating Instructions
PERATING NSTRUCTIONS The LEDsplash™ 200B is a DMX controllable, full RGB color mix par can made up of highly efficient and super bright LEDs. All red, green and blue LEDs can be controlled separately allowing the creation of an unlimited range of colors. -
Page 8: Dmx Control Mode
In this mode you will be able to control each individual trait of the fixture and each fixture independently. The LEDsplash™ 200B uses six channels of control. 1. A working DMX signal source plugged into the LEDsplash™ 200B activates the DMX mode. Setting the DMX address This DMX mode enables the use of a universal DMX controller device. -
Page 9: Appendix
5. A PPENDIX DMX Primer There are 512 channels in a DMX connection. Channels may be assigned in any manner. A fixture capable of receiving DMX-512 will require one or a number of sequential channels. The user must assign a starting address on the fixture that indicates the first channel reserved in the controller. There are many different types of DMX controllable fixtures and they all may vary in the total number of channels required. -
Page 10: Dmx Channel Values
DMX Channel Values NOTE! Please read all instructions carefully on fixture DMX control mode and addressing. DMX channels 2, 3, 4, 5 and 6 functions are determined by the current settings of channel 1. For example, while Channel 1 is set between 000 and 029 the following conditions will apply; ... -
Page 11: Returns Procedure
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET® and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Dmx Dip Switch Quick Reference Chart
DMX DIP Switch Quick Reference Chart DMX DIP SWITCH SET #9 0=OFF 1=ON X=OFF or ON DIP Switch Position LED-PAR200B User Manual DMX Address Quick Reference Chart DIP Switch Position DMX Address 2010-03-09/15:03... -
Page 13: Technical Specifications
Data output ... locking 3-pin XLR female socket Data pin configuration ... pin 1 shield, pin 2 (-), pin 3 (+) Protocols ... DMX-512 USITT DMX Channels ... 6 ORDERING INFORMATION LEDsplash™ 200B ... LEDPAR200B WARRANTY INFORMATION Warranty ... 2-year limited warranty Technical Support Address: Service Dept.
