- Page 1 Model VP-12S2 User Guide Projector...
- Page 2 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. Read Instructions – All the safety and operating instructions should be read before the product is operated. Retain Instructions –... -
Page 4: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFEGUARDS...1 Caution Concerning the Lamp Replacement ...1 Caution Concerning the Lamp Unit...1 Cautions Concerning the Setup of the Projector ...1 Notes on Operation...1 FEATURES...2 ACCESSORIES ...3 PROJECTOR LAYOUT AND FUNCTIONAL OVERVIEW ...4 Front and Top View ...4 Rear and Terminals View ...5... -
Page 5: Important Safeguards
Caution Concerning the Lamp Unit There is a potential hazard of glass particle if the lamp ruptures. In case of lamp rupture,contact your nearest Marantz Authorized Dealer or Service Center for a replacement. See “Replacing Lamp Unit”. ( P.30) WARNING... -
Page 6: Features
It is almost impossible to have zero pixel defects, even using the most advanced technology. This is not a problem only for Marantz, but all projector manufactures. Therefore we have to note that the warranty does not cover the DMD defects. -
Page 7: Accessories
ACCESSORIES • Lens Cap x 1 • Remote Controller x 1 • AA Size Batteries x 2 • AC Power Code (Only for 125V) x 1 • Control Adapter Cable (Mini Jack to RCA) x 1 • User Guide x 1 •... -
Page 8: Projector Layout And Functional Overview
Lens Shift knob ( P.10) Manually adjust the position of the image vertically. r POWER key ( P.16) Press to turn the projector ON or STANDBY mode. t MENU key ( P.21) Display the on-screen menu. y ENTER key Confirm "Reset All", "Reset Lamp Life", "New Lamp?". -
Page 9: Rear And Terminals View
. REMOTE switch (EXT. / INT.) When using this projector independently, set this switch to "INT.". When using this projector in a system with a Marantz DVD player or AV Receiver equipped with a remote sensor, set the switch to "EXT.". -
Page 10: Remote Controller
¡4 ¡9 ¡8 ™0 PROJECTOR a POWER ON key ( P.10) Turn the projector on. s STANDBY key ( P.19) Turn the projector off. d 3 / 4 / 1 / 2 keys Control the MENU cursor. f ENTER key Confirm "Reset All", "Reset Lamp Life", "New Lamp?". -
Page 11: Preparing The Remote Controller
– The Remote Controller operation may not function if the projector’s IR sensors are exposed to direct sun light or strong artificial light, or if there is an obstacle between the IR sensors and the Remote Controller. -
Page 12: Connection
Connecting a video source using S-VIDEO IN and VIDEO IN terminals. Connect one of the S-video cable to the S-VIDEO IN terminal, or one end of the video cable to the VIDEO IN terminal on the projector. Connect the other end of the S-video cable or the video cable to the S-video output terminal or video output terminal of the video source. -
Page 13: Connection With A Hd-Video, Satellite, Cable Tuner Or Pc
You can connect this projector to HD-Video /PC using RGB IN port, or Satellite /Cable Tuner /PC using DVI-D IN port. Connect one end of the RGB cable to the RGB IN port, or one end of the DVI-D cable to the DVI-D IN port on the projector. -
Page 14: Initial Setting
INITIAL SETTING Turning on the Power Connect the supplied AC power cord. ( Press the POWER ON key on the remote controller or the POWER key on the projector. The POWER ON indicator lights up. Zooming and Focusing Project an image on the screen roughly at first. -
Page 15: Adjusting The Height
Operate the adjustment lever for releasing the adjustable feet. And lift the projector up carefully. Remove your hands from the lever. Once the adjustable feet have locked in position, release the projector. If the screen is at an angle, the adjusters can be used to adjust the angle of the image. -
Page 16: Keystone Correction
Turn the Focus ring to make an adjustment. Adjust the focus for the sharpest image possible to obtain, using focus pattern. Press the FOCUS key again to clear off the pattern. Keystone Correction When the projecting image is a trapezoid, correct it in Keystone-V and/or Keystone-H in the Display Menu. See “Display”. -
Page 17: Installation
Range from light axis to upper end CAUTION – For ceiling installation, consult with Marantz authorized dealer. – Do not look into the lens when the projector is turned on. It could damage your eyesight. Screen upper end Range from light axis to upper end... -
Page 18: Screen Size And Projection Distance (Inch)
Screen Size and Projection Distance (inch) ❖ 16 : 9 Screen In case of displaying the 16:9 picture on the whole of the 16:9 screen. Width : Image size = Screen size ❖ 4 : 3 Screen In case of displaying the 16:9 picture on the whole of the 4:3 screen. -
Page 19: Screen Size And Projection Distance (M)
Screen Size and Projection Distance (m) ❖ 16 : 9 Screen In case of displaying the 16:9 picture on the whole of the 16:9 screen. Width : Image size = Screen size ❖ 4 : 3 Screen In case of displaying the 16:9 picture on the whole of the 4:3 screen. -
Page 20: Basic Operations
Selecting the Input Signal Source Switch to the equipment connected to the projector. Press the INPUT SELECT key on the projector or the COMPONENT key, S-VIDEO key, VIDEO key, RGB key or AUX key on the remote controller. Selecting the Aspect Mode You can select 4 kinds of ASPECT mode using remote controller. -
Page 21: The Screen Images In A 16:9 Screen
The Screen Images in a 16:9 screen • Press the ZOOM key, the NORMAL key or the FULL key on the remote controller for the 4:3 aspect ratio video source. • Press the FULL key on the remote controller for 16:9 aspect ratio video source, such as 1080i, 1035i, and 720p video systems. •... -
Page 22: The Screen Images In A 4:3 Screen
The Screen Images in a 4:3 screen • Press the ZOOM key, the NORMAL key or the FULL key on the remote controller for the 4:3 aspect ratio video source. • Press the FULL key on the remote controller for 16:9 aspect ratio video source, such as 1080i, 1035i, and 720p video systems. •... -
Page 23: To Turn Off The Power
- When a WARNING indicator lit up or blinks in red, pull out the AC power cord after checking that the fan has stopped. - The projector will not be turned on if the POWER ON key on the remote controller or the POWER key on the projector is pressed immediately after turning off. -
Page 24: Operations
OPERATIONS Menu Structure Main Menu Picture Adjust Contrast Brightness Color Sharpness Tint Noise Reduction Color Temp. (Temperature) Fine Menu Setting Aspect Cinema Black Setup Component Video System RGB System DVI System Display Keystone V (Vertical) Keystone H (Horizontal) Auto Adjust Picture Shift V (Vertical) Size V (Vertical) Picture Shift H (Horizontal) -
Page 25: Using On-Screen Menu
Using On-Screen Menu Refer to the on-screen menu for making various adjustments and settings. ( Press the MENU key. The MENU appears. 3 / 4 / 1 / 2 keys to select a menu item. Make adjustments in Picture Adjust, Setting, Display, Configuration, Trigger2, or Memory. Press the MENU key to exit. -
Page 26: Fine Menu
Fine Menu By adjusting this Fine Menu, you can make fine picture adjustment. Note : There are some parameters can not adjust according to input signal. ❖ Luminance H Detail Gain (Horizontal Detail Processing Gain) : This menu allows the users to set the horizontal detail processing gain. H Detail Threshold (Horizontal Detail processing Threshold) : This menu allows the users to set the lower threshold for horizontal detail processing. - Page 27 A projector is forced into the intra-field only deinterlacing mode. OFF : A projector is used with external field memories and operates in the full set of deinterlacing modes, i.e., motion adaptive video deinterlacing and full frame film source deinterlacing using 3:2 pulldown detection (2:2 pulldown for 625/50 sources).
-
Page 28: Setting
Setting The following settings can be made: Picture Adjust Aspect Full Setting Cinema Auto Display Black Setup 0 IRE Config Component Auto Trigger 2 Auto Video System Auto Memory RGB System DVI System Aspect Full, Normal, Through, Zoom Cinema Auto, Off Cinema mode : The 3-2 pull down for NTSC and the 2-2 pull down for PAL Black Setup... -
Page 29: Display
Display The following adjustments can be made: – Keystone H, V Adjust trapezoid image to rectangle image. – Auto Adjust Yes : For RGB IN signal, Picture Shift V and H, Size V and H, and Phase are adjusted automatically. No : If something wrong with AUTO Adjust, select No, and adjust Size V, Size H, Picture Shift H, Picture Shift V, and/or Phase manually. -
Page 30: Configuration
Configuration The following adjustments can be made: Picture Adjust Lamp Mode High Setting High Bright Display OSD Position 16:9 Config Language English Trigger 2 Ceiling Memory Rear Reset Lamp Life Reset All – OSD Position (16:9 / 4:3) Select OSD position from 16:9 or 4:3. Picture Adjust Contrast Setting... -
Page 31: Trigger 2
❖ Setting the Config Menu 3 / 4 key to adjust. key to go back to the menu item. Trigger 2 Select either 12V output or 0V output by choosing On or Off for each aspect mode. Full, Normal, Zoom, and Through. On: Output DC 12V. -
Page 32: Memory
Memory This unit has 4 picture modes, Theater, Standard, Dynamic, User, for your choice. You can choose one with the direction buttons on the unit or on the remote. • Theater : This mode is designed for high fidelity black appearance and is good for movie pictures. •... - Page 33 Refer to "Replacing Lamp Unit". ( P.30) Connect the AC power cord after replacing lamp unit. ( Press the POWER ON key on the remote controller or the POWER key on the projector. The following message appears for 120 seconds. 1 / 2 Select “Yes”, using the...
-
Page 34: Maintenance
How to replace the Lamp Unit PREPARATION: When replacing the lamp, turn off the power for the projector. After the cooling fan stops, disconnect the power cord and wait for one hour until the lamp is cooled down completely, then replace the lamp. -
Page 35: Cleaning The Lens
This kit is specially designed to mount the unit on ceiling. • Extension Pole This tool is to adjust height with the Ceiling Mount Kit MOUNT 12. P.26) CAUTION: For ceiling installation, consult with the Marantz Authorized dealer. : LU-12VPS1 : MOUNT 12 : EXT-81... -
Page 36: Troubleshooting
The “EXTERNAL” position on the connector panel is selected. Note: • If the lamp still does not function after the replacement and initialization of the lamp life, contact a Marantz authorized dealer, or service center. ERROR MODE WARNING/LAMP indicator, POWER ON indicator, and STANDBY indicator diagnose error mode of the projector as follows. -
Page 37: On Screen Message
Use the list below to check the message displayed on the screen. Message NO SIGNAL No input signal. REPLACE LAMP! The lamp has reached the end of its life. Improper signal feed to the projector. OUT OF RANGE SPECIFICATIONS ❖ Optical characteristics Panel 0.8 inch 16:9... -
Page 38: Glossary
❖ Timing chart V ( Hz ) System Resolution NTSC 768x240 59.94 / 60 PAL-B/G 960x287.5 SECAM 960x287.5 480/60p 720x480 59.94 / 60 576/50p 720x576 1035/60i 1920x518 59.94 / 60 1080/60i 1920x540 59.94 / 60 1080/50i 1920x540 1080/48i 1920x540 720/60p 1280x720 59.94 / 60 720/50p... -
Page 39: Dimensions
