SERVICE MANUAL
Ver 1.0 2001. 04
• SS-CCP300 is the speaker system
in CMT-CP300
Sony Corporation
9-873-887-11
2001D1600-1
Audio Entertainment Group
© 2001.4
General Engineering Dept.
SS-CCP300
Photo: (L-ch)
SPECIFICATIONS
Speaker system
Two-way, bass reflex
system
Speaker units
13 cm dia., cone type
woofer
2.5 cm dia., semi-dome-
type tweeter
Rated impedance
6 ohms
Approx. 170 × 275 ×
Dimensions (w/h/d)
265 mm
Mass
Approx. 3.0 kg net per
speaker
Design and specifications are subject to change
without notice.
Canadian Model
AEP Model
UK Model
E Model
SPEAKER SYSTEM
Advertisement
Related Manuals for Sony SS-CCP300
Summary of Contents for Sony SS-CCP300
- Page 1 SS-CCP300 SERVICE MANUAL Canadian Model AEP Model Ver 1.0 2001. 04 UK Model E Model • SS-CCP300 is the speaker system in CMT-CP300 Photo: (L-ch) SPECIFICATIONS Speaker system Two-way, bass reflex system Speaker units 13 cm dia., cone type woofer 2.5 cm dia., semi-dome-...
- Page 2 SS-CCP300 EXPLODED VIEW AND PARTS LIST NOTE: • The mechanical parts with no reference number in the exploded views are not supplied. L-ch Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks X-4953-651-1 NET ASSY, SPEAKER 4-233-481-01 RING, SPEAKER 4-932-425-01 SCREW (3.5X20)
- Page 3 SS-CCP300 MEMO...
- Page 4 SS-CCP300 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision...
