Muscle Stimulator Device Characteristics; Muscle Stimulator Ab Belt Characteristics - Contour Core Sculpting System II Use And Care Manual

Contractions The batteries are low.
are weak even
though the
intensity is high
The gel pads have lost
conductivity.
The pads are not
positioned properly.
Stimulation is The gel pads may be
uncomfortable worn out.
Intensity level might be
set too high.
The gel pads are not
positioned properly.
Too many sessions in
a row.
My muscles are Intensity level might be
sore after using set too high.
the Ab Belt
I feel tingling in Gel pads are located
my legs near a nerve center.
I'm not Your diet plays a vital
seeing results role.
The intensity level
might not be set high
enough to get good
contractions.
Replace all 4 AAA batteries.
Never mix old and new bat-
teries. IMPORTANT: NEVER
REPLACE BATTERIES
WHILE THE DEVICE IS ON
Replace gel pads.
Turn the device off, remove
the Muscle Stimulator Ab
Belt and reposition as
described in this manual.
Make sure the gel pads are
below your rib cage.
Replace gel pads.
Reduce the intensity level
until your body gets used
to it.
Turn the device off, remove
the Muscle Stimulator Ab
Belt and reposition as de-
scribed in this manual. Make
sure the gel pads are below
your rib cage.
Leave at least six hours
between sessions.
Reduce the intensity level.
Turn the device off and move
the gel pads slightly.
Follow a reduced calorie
eating plan and get some
regular exercise.
Increase the intensity level.
26

MUSCLE STIMULATOR DEVICE CHARACTERISTICS

Device Name: Muscle Stimulator, MX9
Waveforms: The waveform is monophasic rectangular, voltage regulated.
Parameters: The parameters (pulse rate, pulse duration, stimulation time,
rest time) are optimized for each program.
Pulse Duration: Maximal impulse duration is 340 µs
Protection against electric shock: Internal electrical power source
Maximum Output: 40.9 Volts ± 10%
DC Component: 2 Volts ± 10%
Channels: 2 independent, isolated channels
Separate Intensity control levels for each channel
Power Supply: 4 AAA battery 1.5 V (Alkaline)
Approx. max consumption: 130 mA at 100% intensity
Approx. normal consumption: 40 mA at 100% intensity
Battery Life: 20 hours at 100% intensity
Pulse Frequency Range: 1 – 120 Hz
Impedance Range: 500-2.5k Ohms
FDA Clearance: Nonprescription, over-the-counter use.
The device is manufactured in accordance with the requirements of
International Standards IEC 60601-1, IEC 60601-2-10. The device conforms
to requirements of the United States Food and Drug Administration (FDA) for
non-prescription sales.
Environmental Specs: Operating Temperature Range: 10 - 40°C (50 - 104°F)
Operating Humidity: 30 - 75 % RH
Storage and Transit Temperature Range: -29 - 60°C
Storage and Transit Humidity: 20 - 85 % RH

MUSCLE STIMULATOR AB BELT CHARACTERISTICS

Inner material: 85% Nylon
15% Polyester
Elastic Fabric: 100% Neoprene
Outer Material: 60% Polyester
40% Nylon
Other Fabrics: 100% Polyester
Description of symbols : There are a number of technical symbols on your ems device explained as follows:
This symbol means "Serial
number"
applied sections. The outputs are
The supplied isolated from other parts of the device
documentation that provide a protection against
must be consulted electrical shock.
for operating,
cautionary or safety information
before using the device.
(-20 - 140°F)
Muscle Stimulator is a class II This symbol means please apply
device unit with its own internal regulations enforced in your country
electric power, with type BF when disposing your batteries and
product at its end of life Ensuring it
is disposed in an environmentally
friendly manner.
27
