SERVICE MANUAL
Ver 1.0 2004.10
When a Super Audio CD is played
Playing frequency range
Frequency response
Dynamic range
Total harmonic distortion rate
Wow and flutter
When a CD is played
Frequency response
Dynamic range
Total harmonic distortion rate
Wow and flutter
Output connector
Jack type Output
ANALOG
Phono
5.1CH OUT
jacks
DIGITAL
Square
(CD) OUT
optical
OPTICAL*
output
connector
* Output only the audio signals of the CD
Sony Corporation
9-879-168-01
Audio Group
2004J0579-1
Published by Sony Engineering Corporation
© 2004.10
SCD-XE600
SPECIFICATIONS
2 Hz to 100 kHz
2 Hz to 40 kHz (–3 dB)
100 dB or more
0.0035 % or less
Value of measurable limit
(±0.001 % W. PEAK) or
less
2 Hz to 20 kHz
96 dB or more
0.0039 % or less
Value of measurable limit
(±0.001 % W. PEAK) or
less
Load
level
impedance
2 Vrms (at
Over 10
50 kilohms)
kilohms
–18 dBm
(Light
emitting
wave length:
660 nm)
Model Name Using Similar Mechanism
CD Mechanism Type
Base Unit Name
Optical Traverse Unit Name
General
Laser
Semiconductor laser
(Super Audio CD: λ= 650
nm) (CD: λ= 780 nm)
Emission duration:
continuous
Power requirements
110 V AC, 60 Hz
Power consumption
15 W
430 × 95 × 283 mm incl.
Dimensions (w/h/d)
projecting parts
Mass (approx.)
3.1 kg
Supplied accessories
Audio connecting cord
Red and White
Remote commander
RM-SX800 (1)
Battery
R6 (size-AA) (2)
Design and specifications are subject to change
without notice.
SUPER AUDIO CD PLAYER
E Model
NEW
CDM66D-DVBU50
DVBU50
DBU-3
2 (1)
