Summary of Contents for Montigo H38DF-CLCR
Page 1
Danger of harming radiation Environment your hands Gas bottles Watch for Electricity Danger for cutter Entrapment hazard Battery hazard Rotating parts falling objects ® XG0213 150204.2 Canadian Heating Products Inc. Langley, BC V4W 4A1 | Montigo Del Ray Corp. Ferndale, WA 98248...
Introduction Congratulations on your purchase of a Montigo Fireplace. With over 30 years of experience, Montigo is committed to providing you with a gas fireplace that is not only a beautiful addition to your space, but that is also designed and manufactured to the highest safety, reliability and engineering standards.
Should it be impossible to meet the venting requirements laid out in Section 3: Venting, please contact your local Montigo dealer BEFORE YOU START: regarding the use of a Montigo Power Vent. Lay out the Vent run; calculating the required elbows and straight ...
H*38DF-CLCR Corner Gas Fireplace Installation Section 1: Installation Overview and Product Dimensions Safety, as well as efficiency of operation, should be considered when Please review the Pre-Installation Checklist on Page 4 for general selecting the fireplace location. Select a location that does not interfere information on preparing for a successful installation of your fireplace.
H*38DF-CLCR Corner Gas Fireplace Installation Section 2: Framing the Fireplace Frame in the enclosure for the unit with framing materials. The framed Top Vent Ceiling level opening for the assembled fireplace is 48 " wide, 44 " high, 25 1/4" deep, see Figure 2.
H*38DF-CLCR Corner Gas Fireplace Installation Nailing Flange Extension Clearances When installing a shelf over the top of the fireplaces, the following The 4" nailing flange extension is shipped attached to the top edge of guidelines must be adhered to: the fireplace, see Figure 1. For Rear Vent applications, the minimum clearance is 1"...
H*38DF-CLCR Corner Gas Fireplace Installation Section: 3 The Direct Vent System Montigo supplies a variety of direct venting and termination options. 3. Install the (removed) Rear flue cover and gasket material, to the The direct vent termination location MUST be selected such that Top vent outlet.
H*38DF-CLCR Corner Gas Fireplace Installation Section 3-2: Installing a Roof Mounted Direct Vent Termination (PVTK-1) PVTK1 Termination This section applies to installations where the direct vent termi- 2’ min. nation will be roof mounted� Section 3-2-1: Venting Layout Support ring Selection of components and details of venting lay out should Support plate 32’...
Page 12
H*38DF-CLCR Corner Gas Fireplace Installation PVTK1 Termination Storm Collar Support plate 32’ M a. x Support ring *18” Max. See Note below Figure 9c. Rear vent, Roof mounted venting (1 = 90° bend). * Note: Elbow must be installed directly off the back of the fireplace. If additional horizontal distance is required the vent run must be increased a 2:1 Horizontal to Vertical ratio.
H*38DF-CLCR Corner Gas Fireplace Installation Section 3-3: Installing a Wall Mounted Direct Vent Termination 4)� Installation of termination from inside structure This section applies to installations where the direct vent termi- A Termination with a MOSR Frame is installed from the inside of the nation will be wall mounted�...
18 ” fall within the venting graph NOT be an acceptable installation� parameters, please contact a local Montigo dealer for Power Example C: (Unacceptable Installation) Venting options. If the vertical dimension from the floor of the fireplace is 60" and the horizontal run to the wall flange of the vent termination is 144",...
Page 15
H*38DF-CLCR Corner Gas Fireplace Installation Heat 150”max Shield Note: Images are shown without screens for clarity purposes. However, Termination your fireplace should not be operated without proper installation of screens. Solid Section Flex Section Exterior Wall Hearth Figure 13b. H38C*, HL38C* or HP38C* Top Vented, wall mounted Multi-elbow installation.
Page 16
The Venting Graph parameters, please contact local Montigo dealer for Power Measure the vertical height from the fireplace hearth to the centre of Venting options. the termination and the horizontal run from the fireplace flue collar to the wall flange of the termination.
PRF-12 (7/12 - 12/12 pt�) possible hot spots. Montigo recommends the use of a flex section for the final pipe I - Heat Shield RHS103 connected directly to the fireplace offering greater flexibility of...
H*38DF-CLCR Corner Gas Fireplace Installation Section 3-3-3: Heat Shields Installing a Wall Mounted RHS8 Heat shield Installing a Wall Mounted RHS103 Heat shield� Use the RHS103 where the termination is closer to the fireplace than The RHS8 Heat shield CANNOT be used WITHIN 36" horizontal or 36"...
H*38DF-CLCR Corner Gas Fireplace Installation Section 4: Wiring Models Included H38DF-CLN-F HL38 HP38 H38DF-CRN-F HL38 HP38 H38DF-CLL-F HL38 HP38 BATTERY H38DF-CRL-F HL38 HP38 PACK 1.5V AA type 1.5V AA type SPARK GREEN 1.5V AA type WHITE 1.5V AA type BLACK BLACK SENSOR To PPO...
To check pressures, control valves have a provision to remove a 1/8” N.PT. plug to be fitted with a hose barb. Montigo requires a service shut off valve be located in an accessible location to isolate the gas supply.
H*38DF-CLCR Corner Gas Fireplace Installation Section 6: Finishing Mantels & Surrounds NOTE: National Canadian Gas Association mantel test requirements Finishing Around the Fireplace are for fire hazard prevention to combustible materials. Combustible mantels and mouldings may be safely installed over the New technology, to meet consumer and government demands for the top and on the front of the fireplace provided that they do not project wise use of energy, has prompted us to manufacture many models of...
H*38DF-CLCR Corner Gas Fireplace Installation Section 7: Screen Installation and Removal Left Side Detail Upper Screen Removing / Attaching Screens: Removing / A Studs Upper Screen The Safety Sc Stud Catch To Remove the scr To Remove Screens: Simply grasp ea outer corner of with your thum finger and pull...
H*38DF-CLCR Corner Gas Fireplace Installation Section 8: Removing the Door WARNING When reinstalling door(s), always make sure all door Step 4: buckles are properly hooked and fully engaged. Firmly grasp hand-hold end of Door buckle tool and place the machined Removing the Front door: end in the slot under door frame.
Page 24
H*38DF-CLCR Corner Gas Fireplace Installation Step 8: Removing the Door: Grasp the Door on either side, usually midway and lift upward, lift the door carefully up and away from the front of the fireplace. See Figures 24g. Place the Door aside in a safe place while maintenance and / or cleaning is being performed.
H*38DF-CLCR Corner Gas Fireplace Installation Section 9: Installing the Accessories Installing the H38C* Logset The H38C* is supplied with eight (8) fibre logs. The two small bottom Log C logs ("A" ) are mounted on the burner grate by placing them diagonally onto the supplied Log stands�...
H*38DF-CLCR Corner Gas Fireplace Installation Installing the HP38C* Logs and Embers Bottom Logs The HP38C* is supplied with seven (7) fibre logs. The two bottom logs Log F ("A" & B) are mounted on the burner grate as shown in Figure 26a� Top Logs Place logs "C"...
The HL38C* has the option of installing the cultured rocks which mimic real stone. These may be spaced at random or in a visual pattern of your preference in the burner pan. See the Montigo web site for photographs www.montigo.com and ideas.
H*38DF-CLCR Corner Gas Fireplace Operation Operation with American Flame Electronic Ignition For Your Safety - READ BEFORE LIGHTING: WARNING If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. WARNING/ CAUTION: Hot while in operation.
H*38DF-CLCR Corner Gas Fireplace Operation Standing (Continuous) Pilot Ignition (SIT NOVA 820) Lighting Instructions: Igniter button. Continue to hold the control knob in for about 1� STOP! Read the safety information above on this label. (1) minute after the pilot is lit. Release the knob and it will pop 2�...
H*38DF-CLCR Corner Gas Fireplace Operation Honeywell Electronic Ignition Lighting Instructions: 1� STOP! Read the safety information above on this label. 8� If the fireplace does not operate, follow the instructions "To Turn Off Gas To Appliance" and call your service technician 2�...
H*38DF-CLCR Corner Gas Fireplace Maintenance Maintenance Lighting Instructions Hi-Lo Burner Adjustment: (SIT Nova 820)� See pages 24 - 26 The H*38C* is equipped with an adjustable burner, allowing you to raise or lower the flames. To adjust the flames, locate the black knob marked General 'Hi-Lo', in the centre of the gas control valve (See Figure 29).
If your fireplace still does not operate correctly, consult your local Montigo dealer. All service and repairs should be performed by a qualified Technician� All spare parts, optional fans, and optional trim finishes are available from your local Montigo dealer. Page 32 XG0213 -150204.2...
RLGS47 LGSH38STCRPF Log Set RGC1006 NG Gas Valve RGC1005 LP Gas Valve RPA020 NG Pilot RPA021 LP Pilot NG Burner Contact Local Montigo Dealer LP Burner RTC182 Thermocouple RPG001 Thermopile PIEZO Piezo Ignitor RPTA03 Pilot Tubing RDTH38CL01, RDTH38CL02 Door (CL = left, CR = right)
H*38DF-CLCR Corner Gas Fireplace Maintenance Replacement Parts - Part Codes Diagrams: RDTH38CL02 RDTH38CL02 RDTH38CR02 RDTH38CR02 RDTH38CL01 RDTH38CL01 RDTH38CR01 RDTH38CR01 Figure 28a� Replacement Door Part Codes - CR = Right Figure 28� Replacement Door Part Codes - CL = Left NAME DATE Description DIMENSIONS ARE IN INCHES...
H*38DF-CLCR Corner Gas Fireplace Appendix Appendix A: Venting Terminations Location Canada* USA** clearance to the termination frame above grade, veranda, porch, deck, or balcony 12 inches 12 inches 12 inches 12 inches clearance to top of doors or operable windows clearance to sides or bottom of door or operable windows 12 inches 9 inches...
The duration of any implied warranty with respect to this Montigo Gas Appliance is limited to the duration of the foregoing warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you.
H*38DF-CLCR Corner Gas Fireplace Appendix Appendix C: State of Massachusetts Amendment (Gas Fireplace / Equipment sold in the State of Massachusetts) 5.08: Modifications to NFPA-54, Chapter 10 (1) Revise NFPA-54 section 10�5�4�2 by adding a second exception as follows: Existing chimneys shall be permitted to have their use continued when a gas conversion burner is installed, and shall be equipped with a manually reset device that will automatically shut off the gas to the burner in the event of a sustained back-draft (2) Revise 10�8�3 by adding the following additional requirements:...
Page 38
H38DF CLCR Corner Gas Fireplace XG0213 - 150204.2...
