  • Page 1 M2A.1000 Owner’s Manual...

  • Page 2: Front / Rear View

    Front/Rear view Low Level Input High Level Input Gain Controll Low pass cutting adjustment Sub Sonic adjustment Bass Boost adjustment EBC (External Remote control) EBC ON/OFF switch Led indicator Line Output Fuses 12V (DC) power terminal Remote terminal GND terminal + Terminal - Terminal 16 17...

  • Page 3: Technical Data

    • Class D mono channel power amplifier • 500 watts into 2 ohms load • 300 watts into 4 ohms load • P-Mosfet on amplifier stage • Variable Low pass x-over at 24dB/oct • Variable Sub sonic filter from 20 to 50Hz at 24dB/oct •...
  • Page 4 Crossover and Setting (Eng) The cut frequency is selectable between 30 to 300 Hz. Low pass cutting adjustment (FR) La fréquence de coupure passe bas est réglable de 30 à 300Hz. (IT) La frequenza di taglio è selezionabile fra 30 a 300 Hz. (D) Filterfrequenz einstellbar von 30 bis 300 Hz.

  • Page 5: Speakers Connection

    � � � ������ ������� � (Eng) Minimal acceptable Impedance 2 ohm. To adhere itself to the illustrations for the connections. (FR) Impédance minimale 2 ohm. Suivre les illustrations pour les branchements. (IT) Minima Impedenza accettabile 2 ohm. Attenersi alle illustrazioni per i collegamenti (D) Minimale Anschlußimpedanz 2 Ohm.

  • Page 6: Power Connection

    Power connection ���� �� �������� ������ CAR CHASSIS CAR CHASSIS (Eng) Connect the Positive (+12V) directly to the Battery of the car. To make sure itself to insert a fuse of adequate amperage in order protect the system. Connect the Ground in to the car chassis, close as possible to the amplifier. (FR) Relier la borne +Battery de l’amplificateur directement à...

  • Page 7: Input Setting

    Low Level Input (Eng) Low level OR High level - (FR) Avec des RCA ou avec des câbles haut-parleur- (D) Niedriges Niveau ODER hohes Niveau. - (SP) Nivel bajo O alto nivel (Eng) Connect the Loudspeakers output coming from the car radio, in to the High level input of the amplifier.
