M2A.250
2
P
CHANNEL
OWER AMPLIFIER
Illustration Guide
For more informations <www.macrom.ch>
Input setting
Filter setting
Flat
Response
20Hz
20Hz
20kHz
or
FILTER
Low pass
or
High pass
High Level
Input
R+
R -
L -
L+
GND
or
Low Level
Input
ST / mono
selector
Gain Control Adjust
high pass
filter control
20Hz
20Hz
30Hz
or
Low pass
20Hz
20Hz
30Hz
600Hz
filter control
600Hz
20kHz
20kHz
