Avaya Solution & Interoperability Test Lab
Application Notes for Konftel 300 Conference Unit with
Avaya Communication Manager - Issue 1.0
These Application Notes document compliance testing the Konftel 300 conference unit with
Avaya IP and digital telephones controlled by Avaya Communication Manager. The Konftel
300 attaches to the analog port of an Avaya Media Gateway and enables meeting or
conference participants to simultaneously participate in a telephone conversation.
Information in these Application Notes has been obtained through DevConnect compliance
testing and additional technical discussions. Testing was conducted via the DevConnect
Program at the Avaya Solution and Interoperability Test Lab.
MRR; Reviewed:
SPOC 5/1/2008
Abstract
Solution & Interoperability Test Lab Application Notes
©2008 Avaya Inc. All Rights Reserved.
1 of 10
konftel300-CM

Advertisement

loading

Related Manuals for Konftel 300

Summary of Contents for Konftel 300

  • Page 1 These Application Notes document compliance testing the Konftel 300 conference unit with Avaya IP and digital telephones controlled by Avaya Communication Manager. The Konftel 300 attaches to the analog port of an Avaya Media Gateway and enables meeting or conference participants to simultaneously participate in a telephone conversation.
  • Page 2 1. Introduction The purpose of these Application Notes is to illustrate how the Konftel 300 conference unit can be used within a telephone system consisting of Avaya IP and digital telephones controlled by Avaya Communication Manager. The Konftel 300 conference unit attaches to the analog port of an Avaya Media Gateway, and contains a microphone and loudspeaker, which effectively extends the range from which the telephone can be used to include an area of 30 square meters.
  • Page 3 The “off-hook/flash” key must be used for this purpose, in the same manner as the “flash” key is used for Avaya analog telephones: when the Konftel is in the “off hook” state, depression of the “off-hook/flash” key causes the Konftel 300 to send a “flash” signal to Avaya Communication Manager.
  • Page 4 Avaya 4620 SIP Telephone 2.2.2 Avaya 9640 H.323 Telephone Avaya IA 770 INTUITY AUDIX N5.0-12.0 Konftel 300 1.8.469 EU Table 2: Version Numbers of Equipment and Software 3. Configuration 3.1. Configuration of the Avaya S8300 Media Server The configuration and verification operations illustrated in this section were performed using the Avaya Communication Manager System Administration Terminal (SAT).
  • Page 5 3.1.2. Configure Interface to Konftel Use the add station <x> command to allocate a station for Konftel 300 where <x> is the extension for the Konftel unit as shown in Table 1. Parameter Usage Enter the station type for an analog telephone.
  • Page 6 Use the change feature-access-codes command to assign unused feature codes to those features used by the Konftel 300 as shown in the following Table 5. Note the “*7” entry for the dial plan shown in Figure 3 is used by these entries.
  • Page 7 change feature-access-codes Page 2 of FEATURE ACCESS CODE (FAC) Contact Closure Pulse Code: *726 Data Origination Access Code: *727 Data Privacy Access Code: *728 Directed Call Pickup Access Code: *729 Directed Group Call Pickup Access Code: *730 Emergency Access to Attendant Access Code: *731 EC500 Self-Administration Access Code: *732 Enhanced EC500 Activation: *733 Deactivation: *734...
  • Page 8 Verify that the Konftel 300 can initiate transfer and conference operations using its “flash” key. Verify that the keypad keys on the Konftel 300 can be used to navigate the menu of a voice mail system or other service. Verify that Konftel 300 can redial numbers using the “Last Number Dialed” access code”.
  • Page 9 Document Number 03-300509. [2] Feature Description and Implementation for Avaya Communication Manager, January 2008, Issue 6, Document Number 555-245-205. [3] User Guide Konftel 300 (English), available at www.konftel.se. MRR; Reviewed: Solution & Interoperability Test Lab Application Notes 9 of 10 SPOC 5/1/2008 ©2008 Avaya Inc.
  • Page 10 2008 Avaya Inc. All Rights Reserved. © Avaya and the Avaya Logo are trademarks of Avaya Inc. All trademarks identified by ® and ™ are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. The information provided in these Application Notes is subject to change without notice.
