Fuji Xerox DocuCentre 9000 Quick Reference Manual
  1. Manuals
  2. Brands
  3. Fuji Xerox Manuals
  4. Copier
  5. DocuCentre 9000
  6. Quick reference manual
Fuji Xerox DocuCentre 9000 Quick Reference Manual

Fuji Xerox DocuCentre 9000 Quick Reference Manual

Hide thumbs Also See for DocuCentre 9000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual

Advertisement

Table of Contents
loading

Related Manuals for Fuji Xerox DocuCentre 9000

Summary of Contents for Fuji Xerox DocuCentre 9000

  • Page 2 The data saved in the hard disk of the machine may be lost if there is any problem in the hard disk. Fuji Xerox is not responsible for any direct and indirect damages arising from or caused by such data loss. Fuji Xerox is not responsible for any breakdown of machines due to infection of computer virus or computer hacking.

  • Page 3: Table Of Contents

    Table of Contents Before Using the Machine ..................5 Preface ........................6 About This Guide......................7 Guides Supplied...................... 7 Organization of this Guide ..................8 Conventions ......................8 Product Overview ...................... 9 Machine Components....................10 Main Body ......................10 Power On / Off......................14 Powering On ......................
  • Page 4 Registering Mailboxes ....................41 System Settings Procedure..................43 Paper and Other Media ....................45 Paper Type.........................46 Paper Size ......................46 Weights of Usable Paper ..................46 Paper type ......................47 Loading Paper ......................49 Loading Paper in Trays 1 to 2................49 Loading Paper in Trays 3 to 4................50 Loading Paper in tray 5 (bypass)................51 Loading Paper in Trays 6 to 7................52 Loading Paper in Interposer ..................52...
  • Page 5 Document Jams......................98 Stapler Faults ......................101 Staple Jams in the Staple Cartridge ..............102 Staple Jams at staple cartridge for booklet............103 Solving Curled Output ..................... 104 Index........................107...

  • Page 7: Before Using The Machine

    1 Before Using the Machine This chapter contains descriptions about how to use this document. Preface ......................6 About This Guide ..................7...

  • Page 8: Preface

    1 Before Using the Machine Preface Thank you for selecting our DocuCentre 9000 and Document Centre 1100/900. This guide provides all the necessary copy/print/scan operating procedures, maintenance information like how to clear paper jams, daily care, setting various items, and precautions.

  • Page 9: About This Guide

    Guides for Optional Accessories Optional accessories are also available for the machine. User Guides are provided with the optional accessories exclusively for the DocuCentre 9000 and Document Centre 1100/900. These User Guides are referred to as "guides for optional accessories".

  • Page 10: Organization Of This Guide

    1 Before Using the Machine Organization of this Guide This guide consists of the following chapters. 1 Before Using the Machine Describes how to use this document, as well as cautions on using the product safely and legally. 2 Product Overview Describes basic information such as identifying the major components, how to switch the machine on and off, how to use the touch screen, and how to set the power saver feature.

  • Page 11: Product Overview

    2 Product Overview This chapter describes basic operation about the machine, such as the names of each component, switching on and off of the machine, and the operation of the touch screen and power saving settings. Machine Components.................10 Power On / Off ....................14 About the Circuit Breaker................15 Power Saver Mode ..................16 Control Panel ....................20...

  • Page 12: Machine Components

    2 Product Overview Machine Components This section describes the main components and their functions of the DocuCentre 9000 and Document Centre 1100/900 (hereinafter called "the machine"). Main Body Component Function Document cover Holds the document down. Control panel It consists of operation buttons, LED indicators and a touch screen. Refer to "Control Panel"...
  • Page 13 Machine Components Component Function Left cover Opens slightly just when opening the top cover. Open widely when removing the jammed paper. Front cover Open this cover to remove the jammed paper. <Confirmation> indicator This indicator lights to confirm that the document is loaded correctly. Document guides Use this guides to align the edges of the document.
  • Page 14 2 Product Overview Finisher D2, Booklet finisher D2 36 35 Component Function Interposer (Cover/ Load papers for covers or transparency separators. Papers loaded here Transparency separator will not be used for copying or printing. tray) De-curl button Press this button to decurl copied paper. Output tray Receives copies when you select [Automatic sorting], [Collated], [Uncollated] or normal copy.
  • Page 15 Machine Components Component Function Staple cartridge This cartridge contains staples. Remove this cartridge to replace staples and clear staple jams. Punch scrap container Collects the scraps from the puncher. Open throw away the scraps. Receives copies when you select Tri-Fold In or Tri-Fold out. Tri-Fold output tray Press this button to open Tri-Fold output tray.

  • Page 16: Power On / Off

    Switch on the power before operating the machine. After the power is on, it will take about 6 minutes for DocuCentre 9000 and Document Centre 900 or about 5 minutes for Document Centre 1100 to warm up before you can start making copies.

  • Page 17: About The Circuit Breaker

    About the Circuit Breaker About the Circuit Breaker The machine is provided with a circuit breaker. In the event of a current leakage, the breaker will automatically cut off the power circuit to prevent any leakage or fire from occurring. The circuit breaker is normally On ("l") position as shown in the figure.

  • Page 18: Power Saver Mode

    2 Product Overview Power Saver Mode The machine is installed with a Power Saver feature that will automatically cut off the electricity to the machine if no copy or print data is received for a certain duration. The Power Saver feature has two modes, a [Low Power mode] and [Sleep mode]. The machine enters the [Low Power mode] after the preset time has elapsed if the machine is left unused for a fixed period of time.
  • Page 19 Power Saver Mode Select [System Settings]. Select [System Settings]. Select [Common Settings]. Select [Machine Clock/Timers].
  • Page 20 2 Product Overview Select [8. Auto Power Saver], and select [Change Settings]. Using [ ], configure a power saver mode migration time from 1 to 240 minutes, in 1 minute increments. From Last Selection to Low Power Mode Set the time to move to the [Low Power Mode] after the last operation. Note •...

  • Page 21: Exiting The Power Saver Mode

    Power Saver Mode Exiting the Power Saver Mode The following describes how to exit the Power Saver mode. The Power Saver mode is exited in the following instances: By pressing the <Power Saver> button Receiving jobs Press the <Power Saver> button.

  • Page 22: Control Panel

    2 Product Overview Control Panel The following describes the names and functions of components on the control panel.       Component Function Touch screen This display displays messages required for operation and buttons for various features. You can directly touch the touch screen to instruct operations in screens and set features.
  • Page 23 Control Panel Component Function <Clear All> Returns the statuses of all displayed services to their default values. The machine will be reset to the state after it is turned on. In text descriptions, these buttons are indicated as the <Clear All> button.

  • Page 25: Basic Operation

    3 Basic Operation This chapter describes basic operation about the machine. Copying Procedure ..................24 Printing......................32 Scanning Procedure ...................33 Printing Copy & Print Jobs Document Procedure........39 Registering Mailboxes ................41 System Settings Procedure ................43...

  • Page 26: Copying Procedure

    3 Basic Operation Copying Procedure This section describes the basic copy operations. The following shows the copy flow and reference sections. Step1 Loading Documents ......................24 Step2 Selecting Features ......................26 Step3 Entering the Quantity......................27 Step4 Starting the Copy Job......................28 Step5 Confirming the Copy Job in the Job Status ..............28 Step1 Loading Documents There are two methods for loading documents: Document feeder...
  • Page 27 Copying Procedure Remove any paper clips and staples before loading documents. Shift the document guide gently to touch the document edges. Adjust the movable document guides to just touch the edge of the document stack. Note • The <Confirmation> indicator lights when the document is loaded correctly.

  • Page 28: Step2 Selecting Features

    3 Basic Operation Step2 Selecting Features You can select the features from the [Copy] tab. Note • The features displayed depend on the configuration of the machine. • To use the [Login Setup] feature or [Auditron Administration] feature, you need a UserID and Password, or just a UserID.

  • Page 29: Step3 Entering The Quantity

    Copying Procedure Copy Copies scanned documents. Copy & Save Copies scanned documents and then save them as a data to the mailbox on the machine.You can print saved data from the Mailbox or change settings. Save Only Save scanned documents as a data to the mailbox on the machine. You can print saved data from the Mailbox or change settings.

  • Page 30: Step4 Starting The Copy Job

    3 Basic Operation Step4 Starting the Copy Job Press the <Start> button. Important • If a document has been set in the document feeder, do not press the document while it is being conveyed. Note • If a problem occurs, an error   ...

  • Page 31: Stopping The Copy Job

    Copying Procedure Confirm the job status. Note • Select [ ] to display the previous screen and select ] to display the next screen. Stopping the Copy Job To cancel copying, follow the procedure below. Select [Stop] on the touch screen or press the <Stop>...

  • Page 32: Saving Scanned Documents

    3 Basic Operation Saving Scanned Documents Save scanned documents as a data to the mailbox on the machine. To use mailbox, select [Copy & Save] or [Save Only]. Note • The maximum pages stored in the machine is about 35,000 pages for the A4 portrait. This figure could be used only as a guide, since the maximum scanned pages depend on the types, sizes, and direction of the document.
  • Page 33 Saving Scanned Documents No. of Documents When a mailbox is selected, and it contains documents, the number of stored documents is displayed. Document List Select a box and press this button to check or delete documents stored within. Document List Check or delete documents stored within a mailbox.

  • Page 34: Printing

    3 Basic Operation Printing Describes print procedures. Print procedures vary depending on the application software you are using.For more information, refer to the documentation provided with each application. Select [Print] from the application’s [File] menu. Confirm the [Printer Name] and click [Properties] if necessary. Configure the properties if necessary.

  • Page 35: Scanning Procedure

    Scanning Procedure Scanning Procedure This section describes basic scan operations.The following shows the scan flow and reference sections. Step1 Loading Documents ......................33 Step2 Selecting Features ......................35 Step3 Starting the Scan Job......................36 Step4 Confirming the Scan Job in the Job Status............... 37 Step5 Saving the Scanned Data....................
  • Page 36 3 Basic Operation Remove any paper clips and staples before loading documents. Adjust the movable document guides to just touch the edge of the document. Note • When loading a large document, such as A3, open the document stopper rightward. Set the document facing up (side 1 for 2 sided document) in the document feerder.

  • Page 37: Step2 Selecting Features

    Scanning Procedure Step2 Selecting Features You can select features from the [Basic Scanning] tab. From the [Menu] tab, you can select from 4 scan modes:E-mail, Scan to Mailbox, Job Template, and Scan to FTP/SMB. E-mail Scans a document and sends the scanned data as an e-mail attachment. Scan to Mailbox Scans a document and saves the scanned data to the machine’s mailbox.

  • Page 38: Step3 Starting The Scan Job

    If appropriate, select features to configure from each tab. Note • The screen at right is from DocuCentre 9000. Step3 Starting the Scan Job Press the <Start> button. Important • If a document has been set in the document feeder, do not press the document while it is being conveyed.

  • Page 39: Step4 Confirming The Scan Job In The Job Status

    Importing can be done in the following ways: Import from an Application Network scan driver is used. Import using Mailbox Viewer 2. Fuji Xerox’s application software, Mailbox Viewer 2 is used. Import using CentreWare Internet Services CentreWare Internet Services is used.

  • Page 40: Stopping The Scan Job

    3 Basic Operation Importing Using WebDAV WebDAV is used. Stopping the Scan Job Follow the procedure below to cancel a scan. Press either [Stop] on the touch screen or the <Stop> button on the Control Panel. <Stop> button    Select [Stop]. Note •...

  • Page 41: Printing Copy & Print Jobs Document Procedure

    Printing Copy & Print Jobs Document Procedure Printing Copy & Print Jobs Document Procedure Print Copy Documents procedure steps and their references are listed below. Step1 Opening the [Check Mailbox] Screen................39 Step2 Selecting Box Type ......................40 Step3 Selecting a Box ........................ 40 Step4 Printing Documents......................

  • Page 42: Step2 Selecting Box Type

    3 Basic Operation Step2 Selecting Box Type Select [Copy & Print Jobs]. Step3 Selecting a Box Access to the selected box may be restricted, depending on authorization settings. Select a Box. Step4 Printing Documents Select a Copy & Print Jobs document to be printed and select [Change Settings/Print].

  • Page 43: Registering Mailboxes

    Registering Mailboxes Registering Mailboxes Register mailboxes to store copied and scanned documents. Up to 500 mailboxes can be registered. It is convenient to make separate mailboxes, for example for copied documents and for scanned documents, according to the purpose. You can decide which mailbox to use according to your purpose as each mailbox can be used for copied documents or scanned documents.
  • Page 44 3 Basic Operation When creating a new Mailbox, a password setting screen appears. If not setting a password 1) Select [Off], and select [Save]. When setting a password 1) Select [On], and enter the password. 2) Select [Save]. Select the item to be set, and select [Change Settings].

  • Page 45: System Settings Procedure

    System Settings Procedure System Settings Procedure To make or change the system settings, it is necessary to be in System Administration mode. This section describes the basic procedure for system settings. Press the <Log In / Out> button. < Log In / Out > button Enter the system administrator ID with the numeric keypad or a...
  • Page 46 3 Basic Operation Select the item to be set. Set any features. After settings the feature, select [Save]. When the settings are completed, select [Close] until the [System Settings] screen appears. Select [Exit].

  • Page 47: Paper And Other Media

    4 Paper and Other Media Describes the types of paper that can be used on the machine, precautions when handling paper, and how to load paper in trays Paper Type ....................46 Loading Paper ....................49 Changing the Size of Paper in Trays ............55...

  • Page 48: Paper Type

    To make full and effect use of the machine's performance, we recommend using only paper recommended by Fuji Xerox. If you want to use paper not recommended by Fuji Xerox, contact our Customer Support Center. Warning Do not use conductive paper such as carbonic paper or coated paper.

  • Page 49: Paper Type

    Paper Type Paper Tray Weight Loadable quantity Paper tray 8 60-220g/m / Ream weight : 52-172kg 200 (FX P paper) (Interposer) Note • GSM is a measure of the substance of paper expressed in grams per square. × • Ream weight is the weight of a 788 1,091 mm ream consisting of 1,000 sheets.
  • Page 50 4 Paper and Other Media Storing and Handling Paper Please Keep the Following Points in Mind When Storing Paper Store paper inside a cabinet or other dry place. Paper that has absorbed moisture can cause paper jams and image quality defects. After opening a package of paper, wrap up the remaining paper to store it.

  • Page 51: Loading Paper

    Loading Paper Loading Paper This section describes how to load paper. About types of paper loaded in trays The machine automatically detects the size and orientation of loaded paper in trays. The paper type, however, must be set.Normally, plain paper is set to each of the trays. Change the paper type settings if you load other paper types, Paper can also be named, and set as user-defined paper.

  • Page 52: Loading Paper In Trays 3 To 4

    4 Paper and Other Media Push the tray in gently until it comes to a stop. Loading Paper in Trays 3 to 4 Following describes the procedure for loading paper in trays 3 to 4. Pull out the tray towards you until it stops.

  • Page 53: Loading Paper In Tray 5 (Bypass)

    Loading Paper Loading Paper in tray 5 (bypass) When printing or copying with paper that does not match the sizes or types in trays 1 to 4 and the optional trays 6 to 7, use tray 5 (bypass). Following describes how to load paper into tray 5 (bypass).

  • Page 54: Loading Paper In Trays 6 To 7

    4 Paper and Other Media Loading Paper in Trays 6 to 7 Following describes the procedure for loading paper in the optional trays 6 to 7. Pull out the tray towards you until it stops. Warning When pulling out the paper tray, do it slowly.

  • Page 55: Loading Tab Paper

    Loading Paper Loading Tab Paper Following describes the procedure for loading a tab paper in trays 3 to 4, tray 5 (bypass) and the interposer. Loading tab papers in trays 3 to 4 Pull out the tray towards you until it stops.
  • Page 56 4 Paper and Other Media Loading tab paper in tray 5 (bypass) Open tray 5 (bypass). Note • If necessary, extend the extension flap.The extension flap can be extended in two stages.When pulling out the extension flap, do it gently. Hold the center of the paper guides and slide them to the desired paper size.

  • Page 57: Changing The Size Of Paper In Trays

    Changing the Size of Paper in Trays Changing the Size of Paper in Trays This section describes how to change the paper size for the Trays 3 to 4 and the optional trays 6 and 7. Note • If you need to change the paper size for trays 1 and 2, contact our Customer Support Center.

  • Page 58: Changing The Size Of Paper In Trays 6 To 7

    4 Paper and Other Media Changing the Size of Paper in Trays 6 to 7 Following describes how to change the paper size on trays 6 to 7. Note • When changing the paper size to non-standard size loaded in trays 6 and 7, contact your Customer Support Center.

  • Page 59: Maintenance

    5 Maintenance This chapter describes how to replace consumables. Replacing Toner Cartridges................58 Replacing the Waste Toner Container............61 Replacing the Staple Cartridge..............64 Replacing The Staple Scrap Container ............66 Replacing the Staple Cartridge for Booklet..........68 Emptying Punch Scrap Container...............70...

  • Page 60: Replacing Toner Cartridges

    Use a broom or a wet cloth to wipe off spilled toner. Never use a vacuum cleaner for the spills. It may catch fire by electric sparks inside the vacuum cleaner and cause explosion. If you spill a large volume of toner, contact your local Fuji Xerox representative.
  • Page 61 If you have a used toner cartridge no longer needed, contact your local Fuji Xerox representative for its disposal. Important • Pull out the toner cartridge gently. Otherwise, toner may fly out of the cartridge. • Proper disposal of unwanted toner cartridges is required. Toner cartridge containers should not be opened with force and must be returned to our Customer Support Center.
  • Page 62 5 Maintenance Hold the toner cartridge with the arrow mark facing up Push the toner cartridge slowly to the end and turn the right until it aligns with the lock sign. Close the left cover of the body.

  • Page 63: Replacing The Waste Toner Container

    Use a broom or a wet cloth to wipe off spilled toner. Never use a vacuum cleaner for the spills. It may catch fire by electric sparks inside the vacuum cleaner and cause explosion. If you spill a large volume of toner, contact your local Fuji Xerox representative.
  • Page 64 If you have a used waste toner container no longer needed, contact your local Fuji Xerox representative for its disposal. Important • Proper disposal of unwanted toner container is required. Toner cartridge containers should not be opened with force and must be returned to our Customer Support Center.
  • Page 65 Replacing the Waste Toner Container Hold the center part on the top of the bottle and insert it as far as possible. Important • When inserting the waste toner container, do not hold the grip. Close the waste toner bottle cover. Close the front cover.

  • Page 66: Replacing The Staple Cartridge

    5 Maintenance Replacing the Staple Cartridge When it is time to replace a staple cartridge, a message appears on the display. When this message appears, replace the staple cartridge with a new one. Important • The use of staple cartridges not recommended by Xerox may impair quality and performance.
  • Page 67 Replacing the Staple Cartridge Push a new staple cartridge into the unit. Push the removed unit back to the original position. Close the Finisher right cover. Note • A message will be displayed and the machine will not operate if the Staple Finisher's right cover is even slightly open.

  • Page 68: Replacing The Staple Scrap Container

    5 Maintenance Replacing The Staple Scrap Container A message is displayed when the staple scrap container is full. Follow the displayed instruction and replace the staple scrap container. Important • Replace the staple scrap container while the machine is on. for 100 sheets XF Note •...
  • Page 69 Replacing The Staple Scrap Container Push the staple scrap container from its bottom by holding the R5. Important • Never put your fingers onto the top end surface of the staple scrap container when pushing it. Push the R5 until the lever aligns with the lock sign.

  • Page 70: Replacing The Staple Cartridge For Booklet

    5 Maintenance Replacing the Staple Cartridge for Booklet When a Finisher is installed and it is time to replace the staple cartridge for booklet, a message appears on the display. When this message appears, replace the staple cartridge with a new one. Important •...
  • Page 71 Replacing the Staple Cartridge for Booklet Return the unit to its original position. Close the Finisher right cover. Note • A message will be displayed and the machine will not operate if the Staple Finisher's right cover is even slightly open.

  • Page 72: Emptying Punch Scrap Container

    5 Maintenance Emptying Punch Scrap Container The message will be displayed, when it is time to empty the punch scrap container. Discard the scraps according to the message. When pulling the punch scrap container out to dispose the punch scraps, ensure that all scraps are discarded.

  • Page 73: Problem Solving

    6 Problem Solving This section describes troubles that may occur with the machine and their solutions. Fault Clearance Procedure.................72 Image Quality Problems ................73 Paper Jams....................74 Document Jams..................98 Stapler Faults....................101 Solving Curled Output................104...

  • Page 74: Fault Clearance Procedure

    6 Problem Solving Fault Clearance Procedure If a fault or problem occurs, there are several ways in which you can identify the type of fault. Once a fault or problem is identified, establish the probable cause, and then apply the appropriate solution. If a fault occurs, first refer to the screen messages and animated graphics and clear the fault in the order specified.

  • Page 75: Image Quality Problems

    Image Quality Problems Image Quality Problems Various situations can affect the quality of the output. Check the following conditions to ensure optimum copy performance. If you still cannot resolve the problem, contact the System Administrator. Do not locate the machine in direct sunlight or near a radiator. Follow regular maintenance schedules for cleaning areas, such as the document glass and output trays.

  • Page 76: Paper Jams

    Otherwise, it may cause injuries or burns. Switch off the product promptly and contact your local Fuji Xerox representative. This section describes how to remedy paper jams that occur at the following locations: The references are described below.

  • Page 77: Paper Jams In Trays 1 To 4

    Paper Jams Paper Jams in Trays 1 to 4 Following describes how to remedy paper jams that occur on trays 1 to 4. Pull out the tray where the paper jam occurred. Important • Paper is sometimes torn and remains inside the machine if you draw out a tray without checking the paper jam position.

  • Page 78: Paper Jams In Duplex Module[3]

    6 Problem Solving Pull out transport unit [4]. Lift up the lever [4a], and then remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine. Return lever [4a] to the original position. Push the tray 2 in gently until it comes to a stop.

  • Page 79: Paper Jams In Tray 5 (Bypass Tray)

    Paper Jams Move the release lever [3a] to remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine. Open the lever and then remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine.

  • Page 80: Paper Jams In Trays 6 To 7 (High Capacity Feeder Tray)

    6 Problem Solving Insert the paper into the tray with the printing side facing up until its leading edge lightly comes up against the paper feed entrance. Paper Jams in Trays 6 to 7 (High Capacity Feeder Tray) Following describes how to remedy paper jams that occur on trays 6 to 7. Pull out the tray where the paper jam occurred.

  • Page 81: Paper Jams In Lower Left Cover

    Paper Jams Open the cover [1e], and then remove the jammed paper and all paper loaded in the Interposer. Important • When two or more sheets of paper are loaded, remove all of the sheets from the tray. Note • If paper is torn, check for any torn pieces of paper inside the machine.

  • Page 82: Paper Jams Inside Body

    6 Problem Solving Paper Jams inside body The following describes how to remedy paper jams that occur at the transfer module of the body. Make sure that the machine has stopped before opening the front cover. Turn the green lever at the center of the transfer module to the right until it is in the horizontal position and then pull the transfer module...
  • Page 83 Paper Jams If the jammed paper occurs at the top of the transfer module or inside the fuser unit, remove the jammed paper by pulling it out towards the left. If the jammed paper cannot be removed, lift up the lever [2c] and then remove the jammed paper.
  • Page 84 6 Problem Solving Shift the lever [3b] on the right of the fuser unit as necessary and then remove the jammed paper. Important • If the jammed paper remains inside and it is difficult to remove, pull out the duplex module after returning the transfer module to the original position.

  • Page 85: Paper Jams Inside Finisher Left Cover

    Paper Jams Paper Jams Inside Finisher Left Cover This section describes how to remedy paper jams that occur at the following locations:The references are described below. Paper jams at lever 1a and Knob1c .................... 83 Paper jams at lever 1d ........................ 84 Paper jams at lever 1b ........................
  • Page 86 6 Problem Solving Paper jams at lever 1d Make sure that the machine has stopped, and then open the left cover on the light finisher. Move lever [1d] upwards and remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine.

  • Page 87: Paper Jams Inside Finisher Right Cover

    Paper Jams Return lever [1b] to the original position. Close the Finisher left cover. Note • A message will be displayed and the machine will not operate if the Staple Finisher's left cover is even slightly open. Paper Jams Inside Finisher Right Cover This section describes how to remedy paper jams that occur at the following locations:The references are described below.
  • Page 88 6 Problem Solving Return lever [3b] and [3d] to the original position. Close the Finisher right cover. Note • A message will be displayed and the machine will not operate if the Staple Finisher's right cover is even slightly open. Paper jams at lever 3e and Knob3c Make sure that the machine has stopped, and then open the right...
  • Page 89 Paper Jams Paper jams at lever 3g and Knob3f Make sure that the machine has stopped, and then open the right cover on the light finisher. Move lever [3g] and turn knob [3f] to the left. Remove the jammed paper. Note •...

  • Page 90: Paper Jams At Z Folding Unit

    6 Problem Solving Move lever [4b], turn knob [3a] to the right, and remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine. Return lever [4b] to the original position. Close the Finisher right cover.
  • Page 91 Paper Jams Move lever [2a] and turn knob [3a] anti-clockwise. Remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine. Return lever [2a] to the original position. Close the Finisher right cover. Note •...
  • Page 92 6 Problem Solving Close the Finisher right cover. Note • A message will be displayed and the machine will not operate if the Staple Finisher's right cover is even slightly open. Paper jams at knob 2c, levers 2e/2f and tri-fold output tray 2d. Make sure that the machine has stopped, and then open the right cover on the light finisher.
  • Page 93 Paper Jams Paper jams at tri-fold output tray 2d and lever 2g Make sure that the machine has stopped, and then open the right cover on the light finisher. Pull out the tri-fold output tray [2d], swing lever [2g], and remove the jammed paper.

  • Page 94: Paper Jams At Output Area Of Finisher

    6 Problem Solving Pull out unit 4. Turn knob [4a] to the left to remove all the jammed paper from the left side of the unit 4. Note • If paper is torn, check for any torn pieces of paper inside the machine.

  • Page 95: Paper Jams At Finisher Tray

    Paper Jams Paper jams at finisher tray Remove jammed paper from the finisher tray. Note • If paper is torn, check for any torn pieces of paper inside the machine. Close and open the right cover of the finisher. Note •...

  • Page 96: Paper Jams At High Capacity Tray Unit

    6 Problem Solving Paper Jams at High Capacity Tray Unit This section describes how to remedy paper jams that occur at the following locations: The references are described below. Paper jams in Lower Left Cover ....................94 Paper jams at lever 1a and Knob1c .....................95 Paper jams at lever 1d .........................96 Paper jams at lever 1b .........................95 Note...
  • Page 97 Paper Jams Paper jams at lever 1a and Knob1c Open the front cover of the high capacity tray unit. Move lever 1a to the rightward and turn knob 1c to the right. Remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine.
  • Page 98 6 Problem Solving Move lever [1b] to the rightwards and turn knob [1c] to the right. Remove the jammed paper. Note • If paper is torn, check for any torn pieces of paper inside the machine. Return lever [1b] to the original position.
  • Page 99 Paper Jams Return lever [1d] to the original position. Close the front cover of the high capacity tray unit. Note • A message will be displayed and the machine will not operate if the High Capacity Tray Unit’s front cover is even slightly open.

  • Page 100: Document Jams

    6 Problem Solving Document Jams If a document jams on the document feeder, the machine stops, and an error message is displayed on the display. Remedy the document jam according to the instructions displayed, and then load the document again on the document feeder. This section describes how to remedy paper jams that occur at the following locations: Document jams at cover......................98 Document jams at output area....................100...
  • Page 101 Document Jams When the inside of the left cover is indicated, remove the jammed document. Close the top cover of the inner cover until you hear it click into place. Close the left cover of the document feeder until you hear it click into place. If the document cannot be found, pick up the document feeder slowly, and remove the document if it is there.
  • Page 102 6 Problem Solving Document jams at output area Open the document cover. Open the belt area while gripping the lever, and remove the jammed document. Gently return the belt area to the original position. Put the DADF back in place. Make sure that the document is not torn, wrinkled or folded, and load the document again following the instructions displayed on the display.

  • Page 103: Stapler Faults

    Stapler Faults Stapler Faults Below describes stapler troubles when the Finished is installed. Follow the procedures on the following pages when copies are not stapled or when staples are bent. Contact our Customer Support Center if the problem persists after you have tried the following solutions.

  • Page 104: Staple Jams In The Staple Cartridge

    6 Problem Solving Staple Jams in the Staple Cartridge The following describes remedy for staple jams in the staple cartridge. Make sure that the machine has stopped, and then open the front cover on the light finisher. Hold the R1 at the position shown in the diagram.

  • Page 105: Staple Jams At Staple Cartridge For Booklet

    Stapler Faults Staple Jams at staple cartridge for booklet The following describes remedy for staple jams in the staple cartridge for booklet. Make sure that the machine has stopped, and then open the front cover on the light finisher. Pressing the lever to the right, pulling out the cartridge.

  • Page 106: Solving Curled Output

    6 Problem Solving Solving Curled Output You can correct the curling of the output by pressing the De-curl button. The De-curl button functions both in suspension and in operation if the power of the machine is on. Note • To change the curling correction mode while the machine is in operation, press the De-curl button and then the change will be applied immediately.
  • Page 107 Solving Curled Output Mode and function of De-curl button The following describes the mode and function of <De-curl> button. De-curl button Functions Indicator Mode < AUTO Performs curling correction automatically. > The curling correction is automatically performed according to the paper size or output orientation. It is recommend that this feature be used in Auto mode.

  • Page 109: Index

    Index Symbols fuser..............11 <C> (Clear) button ..........21 Image Quality Problems ........73 interposer.............. 12 All Services button ..........20 Interrupt button/indicator........21 booklet output tray ..........12 Job in Memory indicator ........21 booklet output tray button ........12 Job status button ..........
  • Page 110 punch scrap container ..........13 The maximum fill line ........49, 50, 52 Toner cartridges............58 Review button ............21 toner cartridges .............11 right cover .............12 Toner cover............10 Touch screen ............20 Tray 1..............10 Tray 2..............10 Saving the Scanned Data ........37 Tray 3..............10 Selecting Box Type..........40 Tray 4..............10 Sleep Mode............16 Tray 5..............10...
  • Page 111 DocuCentre 9000, Document Centre 1100/900 Quick Reference Guide DE3629E2-3 (Edition 1) November 2007 Fuji Xerox Co., Ltd. © Copyright 2007 by Fuji Xerox Co., Ltd.
