SDM-9000 Satellite Modem
SDM-9000 "TYPE"
VER: 6.1.1
CONFIGURATION #X
x = 1, 2, 3, 4, or 5

4.2.1.4 Configuration Save

This feature allows the user to program configuration parameters into memory on the
M&C. There are five memory locations that may be used to store specific configuration
setups that are used frequently. This feature speeds up the configuration process and
allows faster configuration changes.
After setting all configuration parameters to the desired settings, enter the Configuration
Save menu (Figure 4-6) and select memory location 1, 2, 3, 4, or 5. Press [ENTER] to
execute the save.
Rev. 4
FUNCTION SELECT
CONFIGURATION
Key:
ACCESS TO
SUBMENU

Figure 4-6. Configuration Save Menu

CONFIGURATION
SAVE
CONDITIONAL OR
Parameter Information
OPTION-DEPENDENT
Operation
4–19
