Parts List - LG WM2277H series Training Manual

This parts list is included with part numbers for the newer (Date Code 608 and
later) version of WM2677. For part numbers for the earlier version, see the
original service manual and the service bulletins included in this training manual.
Loc # Part No
*001 3829ER3025L
*002 3890EZ3524A
*003 3W20018B
*004 3828ER3027G
A100 ABJ30921703
A101 3550ER1028A
A102 4830ER3001A
A103 4930ER3014A
A104 4011FR3159E
A105 4011FR3159D
A106 4011FR3159F
A110 3457ER1006L
A111 4810ER3021C
A130 3551ER0023C
A131 4930ER4005A
A133 2W20017E
A140 4775ER2002A
A141 4930ER4018A
A150 3581ER1008J
A151 3212ER1023A
A152 3212ER1016A
A153 3650ER2004A
A154 4026ER4004B
A155 3650FA3489A
A200 3041ER0001C
A201 4810ER3006A
A220 4779ER3002A
A275 5215FD3715J
A276 5215FD3715K
A300 3110ER2003B
A303 5006ER3009A
A310 5006ER2003H
A410 6601ER1006E
WM2277 WASHER

PARTS LIST

Description
Owner's Manual
Box
Wrench (packed in base of shipping container)
Service Manual
Cabinet Assembly
Cover, Rear
Bushing, drain hose
Holder, drain hose
Shipping Bolt Assembly, Short
Shipping Bolt Assembly, Long
Shipping Bolt Assembly, Long with cord clip
Plate Assembly, Top (incl. hinges)
Bracket, Hinge (2 required)
Cover Assembly, Cabinet
Holder (stud)
Clamp Assembly, Outer Gasket
Hinge Assembly
Holder (stud)
Door Assembly
Frame, Door (Outer)
Frame, Door (Inner)
Handle
Locker, Hook
Handle (handhold) (4 required)
Base Assembly, Cabinet
Bracket, Base
Leg Assembly
Hose, Hot Inlet (Red)
Hose, Cold Inlet (Blue)
Case
Cap, Drain Hose
Cap, Cover
Switch Assembly, Pressure
PAGE 67 of 84 TRAINING MANUAL
