Owner's Manual Washing Machine WM2277HW WM2077CW Please read this manual carefully. It provides instructions on safe installation, use, and maintenance. Retain it for future reference. Record the model and serial numbers of your machine and report this information to your dealer if your machine requires service.
Important Safety Information ...3 Specifications...4 Installation Instructions ...5 Preparation Before Washing...10 Using the Dispenser ...11 Cycles ...13 How to Use the Washer...14 Maintenance ...17 Troubleshooting Guide ...20 Warranty ...23 ■ Direct Drive System The advanced Brushless DC motor directly drives the drum without belt and pulley.
WARNING To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic precautions, including the following: • Read all instructions before using the washer.
■ Permissible water pressure: 4.5 ~ 145 PSI (30 ~ 1000 kPa) Specifications subject to change by manufacturer. Accessories ■ 1) Per IEC 60456, washes the equivalent of a 3.72 cu. ft. agitator washer. Water Circulation Nozzle (WM2277HW) Front-loading Washing Machine 120V~ 60Hz 68.6 cm (W) X 75.6 cm (D) X 98.3 cm (H), 129.1 cm (D, door open)
Properly ground washer to conform with all governing codes and ordinances. To reduce the risk of electric shock, do not install the washer in humid spaces. The base opening must not be obstructed by carpeting when the washing machine is installed on a carpeted floor.
• Carpeting and soft tile surfaces are not recommended. • Never install the washer on a platform or weakly supported structure. ■ Power outlet Must be within 60 in. (1.5 m) of either side of the washer.
INSTALLATION INSTRUCTIONS ■ Electrical connection • Do not use an extension cord or double adapter. • If the supply cord is damaged, it must be replaced by a qualified person in order to avoid a hazard. • If the machine will not be used for an extended time, unplug it and shut off the water supply. •...
INSTALLATION INSTRUCTIONS ■ Installation of drain hose • The drain hose should not be placed higher than 96 in. from the bottom of the washer. • Properly securing the drain hose will protect the floor from damage due to water leakage.
Lock nut (Use a leveling tool.) • After the washer is level, tighten the lock nuts up against of the base of the washer. All lock nuts must be tightened. Diagonal Check...
Wash lint producers and lint collectors separately. • Check all the pockets to make sure that they are empty. Things such as clip, matches, pens, coins, and keys can damage both your washer and your clothes. • Close zippers, hooks, and strings to make sure that these items do not snag on other clothes.
3. Close the dispenser drawer. ■ About detergent Low sudsing detergent is recommended for this washer. Use the manufacturer's recommended amount. If low sudsing detergent is not available, a reduced amount of regular detergent may be used. Because reducing the amount of detergent may reduce cleaning, it is important to pretreat stains, sort carefully by color and soil level, and avoid overloading.
Page 13
USING THE DISPENSER 2. Main Wash Detergent Compartment • Add measured detergent to this compartment for Main wash. Detergent is flushed from the dispenser at the beginning of the cycle. Either powdered or liquid detergent can be used. • Liquid or powdered color-safe bleach may be added to the main wash compartment along with the same type of liquid or powdered detergent.
Speed, Soil Level, and Option (See page 13). • The preset settings can be changed anytime before Start. 3. Start/Pause • Use this button to start/stop the washer. 4. Delay Wash • Allows the start of any cycle to be delayed for 1~12 (9) hours.
Page 16
HOW TO USE THE WASHER 5. Custom Program • Custom Program allows you to store a customized wash cycle for future use. • To make a Custom Program: 1. Select a cycle. 2. Select Wash/Rinse Temperature, Spin Speed, and Soil Level.
Power You can lock the washer while it is operating. DOOR LOCKED • Lights whenever the door of the washer is locked. • The door can be unlocked by pressing the Start/Pause button to stop the washer.
MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock hazards. When disposing of the appliance, cut off the power cable, destroy the plug, and disable the door lock to prevent young children from being trapped inside.
NOTE: Do not use any cleaning substance on the drawer opening other than water because it will drain into the tub. If this should happen, set the washer for a rinse and spin cycle to remove any cleaning substance from the washer before doing a load of laundry.
NOTE: Remove hard water deposits using only cleaners labeled as safe for washing machines. ■ Winterizing instructions If the washer is stored in an area where freezing can occur or moved in freezing temperatures, follow these winterizing instructions to prevent damage to the washer: 1.
Stop washer and rearrange wash load. Adjust the leveling feet. Make sure all four feet are in firm contact with the floor, while the washer is in the spin cycle with load. Check and tighten hose connections. Unclog drain pipe. Contact plumber if necessary.
Page 22
Close the door and press the Start/Pause button. After pressing the Start/Pause button, it may take a few moments before the clothes washer begins to spin. The door must lock before spin can be achieved. If the imbalance is detected or if the suds removing program operates, the wash time shall be increased.
Page 23
• The water overfills due to the faulty water valve. • The water level sensor malfunction. • Overload in motor. • Overload in motor. • The washer experienced a power failure. Solution Check another tap in the house. Fully open tap. Straighten hose.
