• ENC Yb BIST(PB) Check
30) Select page: 3, address: 10, set data: 8C, and press the PAUSE
button.
31) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
32) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
33) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
34) When the playback system from IC351(VFD) to IC643 (AOI)
is normal, the display data (combination data) of page: 3,
address: 16 and 17 agrees with any combination as shown
below.
NTSC model
PAL model
Address
Data
Address
16
83
17
9E
• ENC Ca BIST(PB) Check
35) Select page: 3, address: 10, set data: 8D, and press the PAUSE
button.
36) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
37) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
38) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
39) When the playback system from IC351(VFD) to IC643 (AOI)
is normal, the display data (combination data) of page: 3,
address: 16 and 17 agrees with any combination as shown
below.
NTSC model
Address
Data
16
FE
22
17
68
CA
• ENC Cb BIST(PB) Check
40) Select page: 3, address: 10, set data: 8E, and press the PAUSE
button.
41) Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
42) Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
43) Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
44) When the playback system from IC351(VFD) to IC643 (AOI)
is normal, the display data (combination data) of page: 3,
address: 16 and 17 agrees with any combination as shown
below.
NTSC model
Address
Data
16
B2
DE
17
E7
EE
45) Select page: C, address: 51, set data: 03, and press the PAUSE
button.
46) Only for the DCR-TRV510/TRV510E model, select page: C,
address: 60, set data: 08, and press the PAUSE button.
47) Select page: 0, address: 01, and set data: 00.
Data
16
CC
17
ED
PAL model
Address
Data
16
70
43
17
D5
E4
PAL model
Address
Data
16
ED
9A
17
CB
1E
2. Recording System Check
2-1. Preparations for recording
1)
Playback the BIST check tape.(WR5-6ND(NTSC), WR5-
6CD(PAL))
2)
Select page: 3, address: 10, set data: C0, and press the PAUSE
button.
3)
Select page: 3, address: 11, set data: 07, and press the PAUSE
button.
4)
Enter the stop mode.
5)
While keep the HOLD switch of the adjusting remote
commander at ON(SERVICE) position, eject the BIST check
tape and insert a tape for recording in place of the tape.
6)
Enter the camera recording mode.
Note: Perform the following checks in the camera recording
mode.
2-2. IC351(VFD) BIST(REC) Check
1)
Select page: 3, address: 12, set data: 10, and press the PAUSE
button.
2)
Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
3)
Select page: 3, address: 13, set data: 04, and press the PAUSE
button.
4)
When the recording system from IC351(VFD) to IC301(SFD)
is normal, the display data (combination data) of page: 3,
address: 14 and 15 agrees with any combination as shown
below.
NTSC model
Address
Data
14
D5
15
0B
2-3. IC301(SFD) BIST(REC) Check
1)
Select page: 0, address: 01, and set data: 01.
2)
Select page: C, address: AC, set data: 21, and press the PAUSE
button.
3)
Select page: C, address: AD, set data: 01 (NTSC) or data: 03
(PAL), and press the PAUSE button.
4)
Select page: 3, address: 12, set data: 08, and press the PAUSE
button.
5)
Select page: 3, address: 12, set data: 00, and press the PAUSE
button.
6)
Select page: 3, address: 13, set data: 03, and press the PAUSE
button.
7)
When the recording system from IC301(SFD) to IC303(LIP)
is normal, the display data (combination data) of page: 3,
address: 16 and 17 agrees with any combination as shown
below.
NTSC model
Address
Data
16
00
BC
4C
17
15
CE
CF
8)
When the recording system from IC301(SFD) to IC302(TFD)
is normal, the display data (combination data) of page: 3,
address: 18 and 19 agrees with any combination as shown
below.
NTSC model
Address
Data
18
F7
4F
54
19
F6
69
80
5-59
PAL model
Address
Data
14
34
15
8A
PAL model
Address
Data
F0
16
2D
A2
14
17
F5
7B
PAL model
Address
Data
EC
18
6C
23
1F
19
C7
76
61
EE
2F
1A
01
4E
0E
BF
