Lincoln Electric PRINCE IM818 Operator's Manual

Lincoln Electric PRINCE IM818 Operator's Manual

Gmaw push-pull gun
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GMAW
Push-Pull Gun
Prince
Safety Depends on You
Lincoln arc welding equipment is
designed and built with safety
in mind. However, your overall
safety can be increased by proper
installation...and thoughful opera-
tion on your part. DO NOT
INSTALL, OPERATE OR REPAIR
THIS EQUIPMENT WITHOUT
READING THIS MANUAL AND
THE SAFETY PRECAUTIONS
CONTAINED THROUGHOUT.
And, most importantly, think before
you act and be careful.
OPERATOR'S MANUAL
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
RETURN TO MAIN MENU
OPERATOR'S MANUAL
®
XL/Spool Gun
Model #350 (factory model)
For use with Cabinet K2259-1
LINCOLN
ELECTRIC
World's Leader in Welding and Cutting Prodcuts
Sales and Service through Subsidiaries and Distributors Worldwide
IM818
Copyright © 2003 Lincoln Global Inc.
®
MK 091-0531
April 2003
Rev A

Advertisement

Table of Contents
loading

Related Manuals for Lincoln Electric PRINCE IM818

Summary of Contents for Lincoln Electric PRINCE IM818

  • Page 1 GMAW Push-Pull Gun OPERATOR'S MANUAL Prince Safety Depends on You Lincoln arc welding equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation...and thoughful opera- tion on your part. DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT READING THIS MANUAL AND...
  • Page 2 Prince ® XL - Owner's Manual - Page i...
  • Page 3 Prince ® XL - Owner's Manual - Page ii...
  • Page 4 Prince ® XL - Owner's Manual - Page iii...
  • Page 5 Prince ® XL - Owner's Manual - Page iv...
  • Page 6 Prince ® XL - Owner's Manual - Page v...
  • Page 7 Thank You Please Examine Carton and Equipment For Damage Immediately When this equipment is shipped, title passes to the purchaser upon receipt by the carrier. Consequently, claims for material damaged in shipment must be made by the purchaser against the transportation company at the time the shipment is received. Please record your equipment identification information below for future reference.

  • Page 8: Table Of Contents

    Table of Contents AFETY ONSIDERATIONS ... S NSTALLATION ... 3 ECHNICAL PECIFICATIONS UPPORT QUIPMENT EQUIRED ... 3 ORCH ONNECTION ... 4 NSTALLING POOL SSEMBLY ... 5 NTERCONNECTIONS ... S PERATION ... 4 ENERAL ... 6 ARRELS ... 6 ONTROLS AND ETTINGS ...
  • Page 9 THIS PAGE INTENTIONALLY BLANK...

  • Page 10: Installation

    ECTION NSTALLATION ECHNICAL ® XL T RINCE Wire Capacity • .023”-.045” (0.6 - 1.2mm) solid and hard wire • .030” - 1/16” (0.8 - 1.6mm) aluminum and cored wire Wire Speed • 750 ipm (19.0 mpm) max. Duty Cycle - 100% All ratings are at 25V using Argon Gas •...

  • Page 11: Installing Spool Assembly

    place. A small spool liner (MK P/N 003-0198) is used on the spool gun and held in place by the same set screw. The gas hose is secured over the barbed gas fi tting with a tie wrap. The cabinet end of the gas hose uses our standard gas fi tting (1/8” - 27 nps), whereas the spool gun uses a 5/8”...

  • Page 12: Interconnections

    NTERCONNECTIONS ® PRINCE XL TORCH COBRAMATIC ® I CABINET (150-005,150-006, 150-205, 150-206, K1853-1 & K2259-1) ® PRINCE XL SPOOL GUN WC-1 WELD CONTROL BOX 115VAC PLUG NOTE: The Posa Start feature permits the WC-1 to be used in combination with any Constant Current DC power source with an open circuit voltage in exces of 55 volts.

  • Page 13: Barrels

    the slave motor in the cabinet, combined with the pull of the torch motor, causes the wire to literally fl oat friction-free through the wire conduit. The 24VDC torch motor is controlled by a 3-3/4 turn potentiometer in the torch handle.

  • Page 14: Drive Roll And Idler Rolls

    RIVE DLER OLLS ENERAL ® The Prince XL torch comes standard with knurled drive rolls which will handle wire diameters from .023 - 1/16 inch. Optional grooved drive rolls are also available for feeding aluminum wire if desired (see Optional kits). Drive roll tension is accomplished by means of a pressure adjusting allen screw located on the left hand side of the torch.

  • Page 15: Accessories

    3. Tighten. 4. Using a 5/32” hex wrench, turn the Idler Roll tension screw into the gear- box housing and reference the Gearbox Assembly drawing to adjust the pressure against the drive roll. Lock washer must be under idler roll or it will not turn freely. ECTION CCESSORIES ONTACT...

  • Page 16: Barrel Assemblies

    ARREL SSEMBLIES ALL BARRELS RATED AT 100% DUTY CYCLE STANDARD Straight, 003-2151 12” 18” W PTIONAL ATER ARREL SSEMBLIES 12” Straight Air/Water Cooled Barrel Assembly ..003-2156 12” Curved Air/Water Cooled Barrel Assembly ..003-2158 18”...

  • Page 17: Prince Spool Gun Controls

    MK200 C ONTACTOR P/N 001-3066 PA-L1 S POOL ONTROL INCOLN P/N 005-0676 Connects directly to Lincoln Electric power supplies (42V system) with 14-Pin (X-clocked) amphenol connectors, such as: CV 250 CV 300 CV 655 DC 400 DC 655 V350-Pro (factory model)
  • Page 18 PA-G1 S POOL ONTROL ENERIC P/N 005-0264 This Generic Torpedo is designed to hook-up to CV power supplies that supply an auxiliary 26 VAC @ 1.7 amps and uses a closing contact signal. The unit is supplied with bare wires that must be connected to the power supply.

  • Page 19: Maintenance

    ECTION AINTENANCE ERIODIC Maintenance of the torch will normally consist of a general cleaning of the wire guide system, including tubes, drive rolls, and conduits at regular inter- vals. Remove spatter build-up from inside of nozzles with a hardwood stick. The only parts on the Prince conduit, contact tips, gas cups, barrel liners, drive and idler rolls.

  • Page 20: Recommended Spare Parts List

    Recommended Spare Parts List Part Number Description 615-0007 Conduit 15’ 615-0008 Conduit 25’ 005-0661 Potentiometer Kit 003-0568 Micro Switch 005-0633 Handle Kit (MK) 511-0101 Drive Roll (LE) KP2219-1 (MK) 005-0686 Idler Roll (LE) KP2220-1 Prince ® XL - Owner's Manual - Page 13 Part Number Description 325-0206...

  • Page 21: Troubleshooting

    ECTION ROUBLESHOOTING Regardless of which torch or feeder used, all MK Products push-pull guns operate on the same principle. The 115 VAC or 42VAC slave motor in the feeder runs at a fast, constant speed, but has very low torque. It is always trying to feed more wire than the torch motor wants, and when the motor gets all it wants, it slows the slave motor, preventing a bird’s nest.

  • Page 22: Troubleshooting Guide

    Trouble 115/42VAC control fuse in feeder. No wire feed at torch, feeder no Micro-switch defective/not being operating, i.e. no slave motor or brake activated. solenoid. Broken electrical cable. 4 amp fuse (F1) in feeder/Control box blown. Bad potentiometer. No wire feed at torch, feeder operating properly.

  • Page 23: Testing The Torch

    ESTING ORCH OTOR HECK Remove the torch connector from the cabinet. Using the torch Amphenol, check the resistance across pins “A” and “B” (motor leads). The resistance across the motor should be between 5-10 ohms. If an open circuit or short exist, check the motor leads and motor indepen- dently.

  • Page 24: Ppendices

    ECTION PPENDICES IAGRAMS K2296-2 003-1972 K2297-2 KP2298-1 Straight Barrel Assembly ...21 KP2298-2 45° Barrel Assembly ...22 Air Cooled Lead Assembly ...23 Spool Gun Lead Assemlby ...24 Electrical Control Cable...25 Electrical Schematic...26 Prince XL ARTS ISTS / 313-725 ® XL E (LE) (MK) RINCE...
  • Page 25 Prince ® XL - Owner's Manual - Page 18...
  • Page 26 XPLODED MK P/N 003-1972 Note 1: Item numbers 2, 5, and 11 can be purchased as Kit (MK P/N) 005-0686 or (LE P/N) KP2220-1 Note 2: If Cobramatic Wire Feeder is equipped with a gas solenoid kit, a modifi ed gas value stem (p/n 431-1080) must be installed in torch to allow gas fl...
  • Page 27 Prince ® XL - Owner's Manual - Page 20...
  • Page 28 TRAIGHT ATER OOLED LE P/N KP2298-1, MK P/N 003-2151 200 AMP, 100% D YCLE Prince . 7”, E ARREL XPLODED Straight Air/Water Cooled Barrel Assy. 003-2151 No. Qty. Part No. 002-0642 Brazed Barrel Str AW 003-2213 Assy Taper Lock 303-0010 O-Ring 0.489 ID x 0.070 OD 303-0094 O-Ring 0.301 ID x 0.070 OD...
  • Page 29 45° C URVED ATER OOLED LE P/N KP2298-2, MK P/N 003-2152 200 AMP, 100% D YCLE Prince . 7”, E ARREL XPLODED 45° Curved Air/Water Cooled Barrel Assy 003-2152 No. Qty. Part No. 002-0670 Assy Bend Barrel 45° AW 003-2213 Assy Taper Lock 303-0010 O-Ring 0.489 ID x 0.070 Width...
  • Page 30 OOLED SSEMBLY ® Prince LE P/N Conduit Length #2 Pwr Cable* (MK P/N) KP2072-30 15’/4.5m (615-0007) KP2072-28 25’/7.6m (615-0008) KP2072-29 50’/15.2m (615-0068) *MK part numbers Prince XL Air Cooled Cable Assemblies Electrical Cable* 001-2527 005-0268 001-2528 005-0269 001-1042 005-0272 ® XL - Owner's Manual - Page 23 Gas Hose* Snake Skin*...
  • Page 31 POOL SSEMBLY Spool Gun Lead Assemblies Length #2 Power Cable* 25’/7.6m 843-0484 50’/15.2m 843-0485 75’/22.9m 843-0562 *MK part numbers **Call technical support for details Prince Electrical Gas Hose* Cable* 005-0269 552-0202 005-0272 552-0203 843-0561** 552-0206 ® XL - Owner's Manual - Page 24 Snake Skin* 931-0122 931-0123...

  • Page 32: Electrical

    LECTRICAL ONTROL ABLE Prince ® XL - Owner's Manual - Page 25...
  • Page 33 ® XL E RINCE LECTRICAL Prince ® XL - Owner's Manual - Page 26...
  • Page 34 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com ALABAMA AIRGAS - SOUTH, INC. Birmingham, AL 205/251-6835 DIXIE WELDING SUPPLY Attalla, AL 256/538-6157 INDUSTRIAL WELDING SERVICES Quinton, AL 205/674-3258 KIBRO, INC. Theodore, AL 251/653-4672 WELDING ENGINEERING SUPPLY CO. Prichard, AL 334/457-8681 WELDING MACHINE HOSPITAL...
  • Page 35 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com PRAXAIR DISTRIBUTION, INC. Bakersfi eld, CA 661/321-9922 R. J. KATES San Diego, CA 619/565-6960 RED-D-ARC, INC. Carson, CA 310/233-3327 SIMS-ORANGE WELDING SUPPLY Santa Ana, CA 714/549-9393 SOUTHWEST WELDER REPAIR Fontana, CA 909/357-1661 SWEINHART ELECTRIC CO., INC.
  • Page 36 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com Mc CULLOUGH ELEC. MOTOR SVC. Atlanta, GA 404/688-5251 HAWAII DC ELECTRIC, INC. Aiea, HI 808/483-8900 IDAHO NORCO Boise, ID 208/336-1643 ROSSITER ELECTRIC Idaho Falls, ID 208/529-3665 ILLINOIS CMS ELECTROMECHANICAL SERVICES, INC.
  • Page 37 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com WELDING EQUIPMENT Louisville, KY 502/636-0545 LOUISIANA GT SVCS OF MORGAN CITY Morgan City, LA 985/385-4135 RED BALL OXYGEN CO. Shreveport, LA 318/425-3211 WELDERS EQUIPMENT CO. Broussard, LA 337/837-5701 WELDERS SUPPLY &...
  • Page 38 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com 3D SUPPLIES, INC. Jackson, MS 601/353-3330 MONTANA VALLEY WELDERS SUPPLY Billings, MT 406/256-3330 NEVADA SIERRA WELDING SUPPLY CO. Sparks, NV 775/359-0542 NEW HAMPSHIRE WELDING SYSTEMS SVC. Raymond, NH 603/895-4700 NEW JERSEY INDUSTRIAL ELECTRIC SERVICE CO.
  • Page 39 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com O.E. MEYER CO. Sandusky, OH 419/621-4201 OHIO AIR PRODUCTS Canton, OH 330/821-2771 RICK’S WELDER REPAIR SERVICE Eastlake, OH 440/269-1204 S.D. NOLD, INC. Lisbon, OH 330/424-3134 VALLEY NATIONAL GASES Cincinnati, OH 513/241-5840 VALLEY NATIONAL GASES...
  • Page 40 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com NEXAIR Memphis, TN 901/523-6821 QUALITY WELD’G EQUIPMENT Nashville, TN 615/726-5282 TRAMCO Bristol, TN 423/968-4499 TEXAS AIRGAS - SOUTHWEST, INC. Austin, TX 512/835-0202 AIRGAS - SOUTHWEST, INC. Houston, TX 713/462-8027 DENISON OXYGEN Denison, TX...
  • Page 41 MK Warranty Repair Stations Please visit our website for up-to-date listing at www.mkproducts.com WEST VIRGINIA CARDINAL SALES & SERVICE, INC. Clarksburg, WV 304/622-7590 WILLARD C. STARCHER Spencer, WV 304/927-2520 WISCONSIN INTERSTATE WELDING SALES CORP. Appleton, WI 920/734-7173 MOSINEE MACHINE & ELECTRIC Mosinee, WI 715/693-0858 PRAXAIR DISTRIBUTION, INC.
  • Page 44 HIS PAGE INTENTIONALLY BLANK...

  • Page 45: Limited Warranty

    LIMITED WARRANTY Effective February 1, 2003 This warranty supersedes all previous MK Products warranties and is exclusive, with no other guarantees or warranties expressed or implied. LIMITED WARRANTY - MK Products,Inc.,Irvine,California warrants that all new and unused equipment furnished by MK Products is free from defects in workmanship and material as of the time and place of delivery by MK Products.
