12. Remove the heat sink from its package and rotate the heat-sink handle to the
13. Remove the cover from the bottom of the heat sink.
14. Position the heat sink above the microprocessor and align the clips of the heat
15. Press on the top of the heat sink and rotate the lever to the closed position.
If you have other devices to install or remove, do so now. Otherwise, go to

"Completing the installation."

Completing the installation
To complete the installation, complete the following steps:
1. If you removed the front bezel, slide the bezel onto the front of the server
2. If you removed the top-cover bracket, reinstall it. Slide the blue latches into the
3. Place the top cover over the top of the server.
4. Slide the top cover forward; then, press down on the cover handle until it clicks
5. Connect the cables and power cords to the rear of the server. For more

Connecting the cables

Notes:
1. Be sure to turn off the server before you connect any cables to or disconnect
2. For additional cabling instructions, see the documentation that comes with the
Clips
Tabs
fully open position.
sink with the tabs next to the microprocessor socket.
chassis.
locked position.
into place.
information, see "Connecting the cables."
any cables from the server.
optional devices. It might be easier for you to route any cables before you install
certain optional devices.
Heat sink
Clips
Tabs
Chapter 2. Installing optional devices
59
