TR-9500
TREADMILL
Handlebar
AK26-00356-0001
Handrail End Cap(4)
OK26-01232-0000
Anti Skid Pads(2)
OK26-02003-0000
Rear End Cap(LT)
SK26-00326-0000
Rear End Cap(RT)
SK26-00327-0000
Display Console
AK26-00419-0001(R) Eng/Eng
AK26-00419-0002 Ger/Met
AK26-00419-0003 Eng/Met
AK26-00419-0005 Spn/Met
AK26-00419-0007 Jap/Met
Stop Switch Kit
FK26-00002-0051
Handrail Cover
OK26-01463-0000
Frame Decal(RT)
OK26-01434-0000
Frame Decal(LT)
OK26-01432-0000
GK26-00001-XXXX
SN:300000-302935
Overlay Bezel
AK26-00597-0001 Eng/Eng
AK26-00597-0002 Ger/Met
AK26-00597-0003 Eng/Met
AK26-00597-0005 Spn/Met
AK26-00597-0007 Jap/Met
Front End Cap(RT)
SK26-00328-0000
Front End Cap(LT)
SK26-00329-0000
Wheel(2)
OK26-01501-0000
Rev. 11 Oct 2006
Advertisement
Related Manuals for Life Fitness TR-9500
Summary of Contents for Life Fitness TR-9500
- Page 1 TR-9500 TREADMILL Display Console AK26-00419-0001(R) Eng/Eng AK26-00419-0002 Ger/Met AK26-00419-0003 Eng/Met AK26-00419-0005 Spn/Met AK26-00419-0007 Jap/Met Stop Switch Kit FK26-00002-0051 Handlebar AK26-00356-0001 Handrail End Cap(4) OK26-01232-0000 Anti Skid Pads(2) OK26-02003-0000 Rear End Cap(LT) SK26-00326-0000 Rear End Cap(RT) SK26-00327-0000 SN:300000-302935 Overlay Bezel AK26-00597-0001 Eng/Eng...
- Page 2 TR-9500 TREADMILL Display Console Cable AK26-00400-0000(upper) AK26-00399-0000(lower) Lift Screw Bearing 0017-00006-0117 Deck OK26-01201-0004 Deck Hardware GK26-00002-0052 Pinch Guard(2) OK26-01539-0000 GK26-00001-XXXX SN:300000-302935 Front Roller SK26-00312-0000 Lift Motor OK26-01404-0000 Striding Belt Rear Roller Belt OK26-02204-0001 OK26-01421-0000 Idler Pulley OK26-01542-0000 Lift Nut Pulley...
- Page 3 TR-9500 TREADMILL 8“ Line Cord 0017-00003-0693 12“ Line Cord 0017-00003-0743 200v +Line Cord 0017-00003-0710 Continental Line Cord 0017-00003-0696 Wax Nozzle 0017-00009-0842 Debris Brush GK26-00002-0026 Drive Motor SK26-00408-0001(115v) SK26-00408-0002(230v) Drive Belt OK26-01592-0000 ROLLER-ASSY: FRNT; STEEL;PUR.E NC KIT: SERV; MFG; EMERSON;DOML 10-MPH BM MANUAL: OP/CLR;...
