Overview
Icons
Table 1: Icons on the phone buttons
Icon
Phone
Phone On-hook/Off-hook
Mute microphone
Volume control
Table 2: Icons on the touch screen
Icon
Mute Alert
Error
Message
Warning
Dial pad
Features
Contacts
Settings
Last number redial
Ringer off
Conference
Drop participant
Description
Description
Icon
Hold
Mute participant
Unmute
LED status indicators
LED color
Steady red
Microphones are on mute.
Flashing red
A call is on hold.
Steady blue
A call is in progress.
Flashing blue
An incoming call is ringing.
Settings Menu
Main menu
Icon
Sub option
option
Call settings
Pair Contacts
to Calls
Screen & Sound
Brightness
Options
Language
Button Clicks
Error Tones
Backup/Restore
Backup
Procedure
Restore
Procedure
Network Info
Audio
Parameters
IP Parameters To view the information related to IP such
Quality of
Service
Miscellaneous To view information about the phone model
Description
Description
Purpose
To pair incoming calls and contacts.
To increase or reduce the brightness of the
touch screen.
To change the language on the phone.
To enable or disable the sound of button
clicks.
To enable or disable error tones.
To backup the settings for the display
language, the button clicks, the error tone,
and the pairing contacts on your phone.
To restore the information that you have
backed up.
To view information about audio
parameters such as received coding,
packet loss, packetization delay, one way
network delay, and network jitter delay
during a call.
as phone IP address, HTTP server IP
address, HTTPS server IP address, subnet
mask, router IP address, call server IP
address, and information about 802.1x
supplicant, VLAN IDs, and VLAN test.
To view the values for QoS parameters
such as L2 Audio, L2 Signaling, L3 Audio,
and L3 Signaling.
number and serial number, MAC address,

Advertisement

loading

Related Manuals for Avaya B189

Summary of Contents for Avaya B189

  • Page 1 Icon Description Overview Hold Icons Table 1: Icons on the phone buttons Mute participant Icon Description Unmute Phone Phone On-hook/Off-hook LED status indicators Mute microphone LED color Description Volume control Steady red Microphones are on mute. Flashing red A call is on hold. Table 2: Icons on the touch screen Steady blue A call is in progress.
