Océ CS7400 Series
User Manual
0706443 Rev B

Advertisement

Table of Contents
loading

Related Manuals for Oce CS7400 Series

Summary of Contents for Oce CS7400 Series

  • Page 1 Océ CS7400 Series User Manual 0706443 Rev B...
  • Page 2 Fax: +1 604 273 2775 regarding combining a MacDermid ColorSpan printer with a cutter. Should any http://www.oce.com MacDermid ColorSpan printer be combined with a cutter, such combination should only be made in the sole discretion of the customer, at the customer's sole risk, and MacDermid ColorSpan disclaims any liability for such combination.

  • Page 3: Regulatory Statements

    Regulatory Statements FCC-A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Related Documentation

    Related • Release Notes — describes new versions of the printer’s embedded software and other new information not included Documentation in this user manual. • Material Safety Data Sheets — information for safe han- dling of the inks and printhead flush used with the printer. For instructions on using a third-party RIP with the printer, refer to the documentation that accompanies it.

  • Page 5: Table Of Contents

    Table of Contents Regulatory Statements ......... . . iii FCC-A .
  • Page 6 Calibrating the Moveable Fence....... . 2-22 Checking Jet Health ......... . . 2-24 Purge .
  • Page 7 Technical Specifications Specifications..........A-2 Electrical Power.
  • Page 8 viii Table of Contents...

  • Page 9: Getting Started

    Chapter 1 Getting Started This chapter shows you how to get started using your printer. It includes these topics: • Operating Requirements (page 1-2) • Important Operating Notes (page 1-8) • Quick Tour (page 1-17) • Special Features (page 1-20) Getting Started...

  • Page 10: Operating Requirements

    Operating Choose a location for the printer before you unpack it. Keep the following requirements in mind: Requirements • Use the supplied power cord. Plug it directly into a grounded Electrical electrical outlet. Do not lengthen the power cord with an extension cord;...

  • Page 11: Environmental

    Environmental • Make sure the room is well ventilated, with a temperature and relative humidity within specifications (see “Specifica- tions” on page A-2). Optimal printing occurs within these ranges. • The high power UV light emitted by the curing lamps reacts with oxygen and produces ozone.

  • Page 12: Connecting The Rip

    Connecting the RIP To connect the printer to a RIP, follow this procedure: 1. Power off the computer you will be using to run the RIP. Step 1: Install the VideoNet Card and Cable 2. Install the VideoNet printer interface card into an available PCI expansion slot.

  • Page 13: Step 2: Install The Videonet Protocol

    6. Power on the computer. After Windows starts, it detects the new interface card and installs the driver software. The VideoNet networking protocol is used to communicate with Step 2: Install the VideoNet the printer. These instructions assume a familiarity with Protocol Microsoft Windows XP administrative functions.
  • Page 14 5. Click the Install button. 6. Select Protocol. 7. Click the Add button. 8. Click Have Disk... 9. Click Browse. 10. Browse to the folder on the ColorSpan DVD (for example, D:\Videonet\Windows XP). This displays a file named videonet.inf in the File Name field.

  • Page 15: Step 3: Install The Rip Software

    16. Right-click the VideoNet connection icon, then click Properties. 17. The window should now display all services and protocols assigned to the VideoNet card. 18. Uncheck all protocols except ColorSpan VideoNet by click- ing on the boxes with check marks in them. 19.

  • Page 16: Important Operating Notes

    Unlike other Important Operating UV CURE INK IS PERISHABLE. • inks used in wide format printing, UV cure ink Notes has a limited shelf life. Plan to rotate your ink stock and use it promptly by the date printed on the ink box. •...
  • Page 17 minimal amount of isopropyl alcohol and dry them thor- oughly before printing. • DO NOT set heavy objects on the power cord or printer cable; do not bend the cables or force them into contorted positions. • DO NOT place heavy objects anywhere on the printer. Important Operating Notes...

  • Page 18: Safety Warnings

    Safety Warnings • UV light — the ultraviolet (UV) curing lamps emit high power UV light. The printer must be operated with all safety shield- ing installed to protect the operator from eye and skin dam- age. When operated according to manufacturer’s instructions, safety glasses or other protective clothing are not necessary.

  • Page 19: Deutsch

    Deutsch • UV-Licht – die ultravioletthärtenden Lampen strahlen Hochleistungs-UV-Licht ab. Der Drucker muss mit allen installierten Sicherheitsabschirmungen betrieben werden, um den Bediener vor Augen- und Hautschäden zu schützen. Sicherheitsbrillen oder andere Schutzkleidung ist nicht erforderlich, wenn gemäß den Herstelleranweisungen gear- beitet wird.
  • Page 20 el peso máximo de carga de las mesas de entrada y salida, según lo especificado en la etiqueta. • Tinta - Lea y ponga en práctica las recomendaciones de seguridad recogidas, en la Hoja de Datos de Seguridad del Material (Material Safety Data Sheet - MSDS), para la tinta y exponga dicho documento en el área de trabajo, tal y como requiere la legislación vigente.

  • Page 21: Français

    Français • Lumière UV — Les lampes à séchage ultraviolet (UV) dif- fusent une puissance de lumière UV importante. L'impri- mante doit être utilisée en tenant compte de toutes les mesures de sécurité mises en place pour protéger l'opéra- teur de blessures aux yeux et sur la peau. Quand vous uti- lisez l'imprimante, les lunettes de protection et vêtements de protection ne sont pas nécessaire.

  • Page 22: Italiano

    lithium en accord avec la réglementation de gestion des déchets locale, régionale ou gouvernementale. • Luce Ultravioletta (UV) — Le lampade UV, emettono raggi Italiano ultravioletti ad alta intensita'. Bisogna operare il plotter con tutti i filtri di protezione installati, per proteggere l'operatore da eventuali esposizioni dannosi agli occhi e alla pelle.
  • Page 23 • Residui pericolosi — All' interno del gruppo elettrico del plotter, si trova una batteria al litio il quale se non sostituita in maniera corretta puo' rischiare di esplodere. Per tale motivo, solamente personale tecnico specializzato deve eseguire tale operazione. Per lo smaltimento della batteria usata o danneggiata, verificare le modalita' locali, provinciali o nazi- onali in materia.

  • Page 24: Daily Shutdown Not Recommended

    DO NOT POWER DOWN THE PRINTER. Power is required to Daily Shutdown Not maintain vacuum to the printheads, which keeps ink from seep- Recommended ing out. If power is unexpectedly removed from the printer, print- head vacuum will be lost and ink will leak from the printheads. The amount of ink lost will be limited to the ink currently in the printheads, not the ink in the ink supply boxes which has not yet been pumped to the printheads.

  • Page 25: Quick Tour

    Quick Tour 18,19 Fig. 1-2. Major parts of the printer Quick Tour 1-17...
  • Page 26 1. UV-shielded access cover 2. Touch-screen control panel 3. Integrated output table 4. Output media fence 5. Electronics box (inside enclosure) 6. Ink supply boxes 7. Profiler docking station 8. Media load (lower pinch rollers)/unload (raise pinch rollers) switch 9. Media advance foward/backward switch 10.
  • Page 27 Fig. 1-3. Front Page screen 1. Media information 11. Settings 2. Printer status 12. Tools 3. Ink levels 13. Move media forward/backward 4. UV lamps status (L=left side, R=right side) 14. Go Online/Go Offline switch 5. Covers status (open or closed) 15.

  • Page 28: Special Features

    Special Features • Printheads — variable drop size, piezoelectric printheads, Printheads 192 jets per head. • Off-Head System (OHS) — 1-liter bulk ink boxes with inte- Ink System grated filters. No-drip quick connectors simplify ink box replacement. • Onboard vacuum/pressure (VP) system — provides vac- uum to maintain negative printhead pressure, and air pres- sure to purge the printheads or ink tubes without removing them from the printer.

  • Page 29: Calibration

    • Advanced pinch roller design — the molded pinch rollers are self-aligning to prevent media skew. Any individual pinch roller can be snapped up and out of the way to avoid interfer- ing with the edge of the media. • Adjustable media fence —...
  • Page 30 quently-used functions. A menu provides access to less-fre- quently used functions and troubleshooting help. • User assistance — control panel features online help, inter- active procedures, and diagnostics to assist the user “on- the-fly,” reducing training and troubleshooting time. 1-22 Special Features...

  • Page 31: Printing

    Chapter 2 Printing This chapter shows you how to set print mode and media options, load ink and media, and print: • Configure Printing (page 2-2) • Configure Media (page 2-6) • Load and Print on Rigid Media (page 2-10) •...

  • Page 32: Configure Printing

    Configure Printing The printer can print in several different modes for the combina- tion of quality, resolution, and speed that you require. Addressable Resolutions and Maximum Print Speeds Print Modes Model High Quality Production Billboard 1200x600 CS7440 / CS7460 24 sf/h (2.25 m 48 sf/h (4.5 m 97 sf/h (9 m CS7445 / CS7465...
  • Page 33 The printer can print in both directions (bidirectional) or in one direction only (unidirectional). Unidirectional printing can occur in either direction. Printing occurs at about half the speed of the corresponding bidirectional print mode. Unidi- rectional printing eliminates the bidirectional misalignment that occurs when printing on media that is not perfectly flat.
  • Page 34 The following table shows the print mode and resolution combinations supported by each of these modes: 600x600 600x300 1200x600 Normal BB, PQ, HQ BB,PQ,HQ Fine Text PQ, HQ — PQ, HQ Sharp Edge PQ, HQ PQ, HQ BB=Billboard; PQ=Production Quality; HQ=High Quality The Unsupported Setup Job Handling menu appears.
  • Page 35 • If the media is wrinkling or warping from the heat of the lamps, lower the setting. When you select a lamp setting, the shutter aperture screen appears. 8. Adjust the shutter apertures, or press Press  (Proceed) to continue. You can select the aperture (opening amount) for each shut- ter, and/or completely close one of the shutters, during print- ing.

  • Page 36: Configure Media

    Configure Media Before the printer will accept a print job, it must be configured for a specific media type. The currently-configured media type, if any, is displayed in the upper left corner of the control panel. You can load a new media type (see the following procedure), or reload the previously loaded media (see “Reload Media”...
  • Page 37 Fig. 2-1. Media settings screen • If you pressed a media name, a list of settings appears (see Fig. 2-1). From this screen you can change the Media Settings, change the Print Mode, Select Media again, or Proceed to loading the media. To load media, press the ...
  • Page 38 Observe the media as the fan speed changes. If the media is lifting off the platen, increase the fan speed. If the media advance seems impeded by the vacuum, decrease the fan speed. After you save your changes by pressing the  (Pro- ceed) key, the Leading Edge Static Control screen appears.

  • Page 39: Unload Media

    Unload Media To unload media (raise the pinch rollers and switch off the platen vacuum), press the Unload Media key on the Front Page screen, or press the Load/Unload switch on the back of the printer to the Unload position. If the control panel displays the media type you intend to use, Reload Media press the Reload Media key (or press the Load/Unload switch to...

  • Page 40: Load And Print On Rigid Media

    Load and Print on 1. If loaded, unload any roll-fed media. Rigid Media 2. If necessary, slide the roll-fed media edge holders out of the way of the media path. 3. Open the input and output media tables, and unfold and lock the legs into position.
  • Page 41 The following screen appears. Fig. 2-3. Load media screen 8. Unlock the adjustable media fence by loosening the locking knob, and slide it to the right (toward the service station end of the printer). Locking knob Rail Fence Fig. 2-4. Adjustable fence 9.
  • Page 42 10. Slide the adjustable media fence against the right side of the media. Then lock it in place. At this point you can also adjust the speed of the vacuum fans, or switch them on or off. If the sheet is warped or not being held down, increase the vacuum fans or raise the pinch rollers.
  • Page 43 After briefly displaying the measured width of the media, the control panel displays the media and margin measurements (see Fig. 2-6): • To change the margins, press the Margin Settings key. Note The minimum Trailing Margin is 6 inches (15.2 cm), to enable the pinch rollers to advance the media.
  • Page 44 16. Send a print job from the RIP. For multiple copy jobs, the printer control panel will prompt for the next sheet a short time before the previous sheet is done printing. Load the subsequent sheet as before, and press the  (Proceed) key, or press the Load/Unload switch to the Load position, or press the optional foot pedal switch.

  • Page 45: Load And Print On Roll-Fed Media

    Load and Print on 1. If opened, retract the rigid media input and output table extensions, and fold the table legs, tables, and adjustable Roll-Fed Media media fence down into their storage positions. Fig. 2-7. Tables stored for roll-fed printing 2.
  • Page 46 3. Load the supply spool onto its bracket. Insert the end of the spool with the pin into the left spool holder, then insert the other end of the spool into the right spool holder. 4. Unspool enough media to reach past the pinch rollers, and smooth out the media across the platen.
  • Page 47 and calculating margins, to prevent printing on the media edge holders. Fig. 2-9. Media edge holder (left shown) (Yes) or  (No) key. 11. Press the • If you press Yes, the printer prompts you to position the edge holders at the sides of the media. Then position the edge holders.
  • Page 48 To display the Media Wizard and view or change media and margin settings for the currently loaded media, touch the media info panel in the upper left corner of the Front Page screen. 2-18 Load and Print on Roll-Fed Media...

  • Page 49: Loading Ink

    Loading Ink The amount of ink in the ink supply box is tracked by the printer software and recorded on its corresponding profiler. The control panel displays a bar graph with the ink levels in each ink box. When the control panel shows that the ink is low, replace the ink box with a full ink box of the same color.

  • Page 50: Unloading An Empty Ink Box

    Unloading an Empty 1. Remove the profiler. Ink Box 2. Grasp the metal connector where the ink tube enters the printer, and push it up to release the ink supply tube. 3. Lift the box out of its holder and turn the box upside down so the ink tube is pointing up.

  • Page 51: Printing Tips

    Printing Tips • Rigid cut-sheet media — use only flat, unwarped, undam- ° aged sheets, with parallel opposite edges and 90 corners. Load the media from the back of the printer; loading from the front will cause interference with the UV blocking brushes. •...

  • Page 52: Calibrating The Moveable Fence

    Calibrating the The moveable fence is calibrated at the factory to be parallel to the top surface of the media, at a height just above the top of the Moveable Fence table rollers (lower than the thickest media that will be used on the printer).
  • Page 53 4. Using a 5 mm hex wrench, loosen the two set screws (shown below) that secure the vertical position of the move- able fence. Fig. 2-13. Height adjustment screws 5. Place a long, flat, thin metal ruler on top of one column of table rollers.

  • Page 54: Checking Jet Health

    Checking Jet Health Under most conditions, AutoJet jet substitution and the printer’s automated printhead service station keeps the printheads clean and operating without your intervention. Should operator clean- ing of the printheads become necessary, the printer also pro- vides several printhead-cleaning tools to accomplish this. If you notice a decrease in print quality, one or more inkjets may be clogged.

  • Page 55: Map Out Missing Jets

    Map Out Missing Jets If the Prime Bars reveal blank lines after a Purge, the corre- sponding jets should be mapped out. When all missing jets have been substituted, printed output will appear as if all jets are working. You can map jets out temporarily (“soft bad jets”) or permanently (“hard bad jets”).

  • Page 56: Uv Lamp Operation And Maintenance

    UV Lamp Operation The printer’s two UV lamps (on the left and right sides of the printhead carriage) emit the high-intensity ultraviolet light that is and Maintenance necessary to cure the UV ink. The lamps have a limited life, during which the amount of UV light emitted slowly decreases, eventually reaching a level that will no longer cure the ink.
  • Page 57 tion page where this is listed (on the Front Page, touch the printer status message to reveal the System Information pages). Replacing the bulbs as a pair is recommended. If the total oper- ating time for the right and left bulbs is significantly different, printing artifacts may be visible due to uneven ink curing.
  • Page 58 2-28 UV Lamp Operation and Maintenance...

  • Page 59: Using The Control Panel

    Chapter 3 Using the Control Panel This chapter describes the functions of the control panel. • Overview (page 3-2) • Front Page (page 3-3) • Menu Tree (page 3-6) • Menus (page 3-7) Using the Control Panel...

  • Page 60: Overview

    Overview The touch-screen control panel shows you the printer’s current status, and enables you to interact with the printer when chang- ing media and ink, respond to an error condition, or configure options. The control panel provides various forms of online user assistance: The ? button provides an explanation of the current function, with some guidance for what to do next.

  • Page 61: Front Page

    Front Page The Front Page is the primary control panel interface. You can initiate the most common operations from this screen. Fig. 3-1. Front Page 1. Media information — media name, size, print area, printable length. Press here to display the Media Wizard. 2.
  • Page 62 • Job Tracking Log — list of the last ten print jobs, with diagnostic information. • Media Tracking Log — the amount of sheet fed and roll fed media printed since the reset button on this screen was pressed. 3. Ink levels — numeric and graphic ink levels; line marks “low ink”...
  • Page 63 is provided by the media advance switch on the back of the printer.) 14. Go Online/Go Offline switch — switches network communi- cations on and off between the printer and RIP. 15. Sleep/Wake — Sleep Mode powers down the UV lamps, printheads, carriage, and media drive motors, but maintains vacuum to the printheads to prevent ink leakage.

  • Page 64: Menu Tree

    Menu Tree This menu tree reflects version 1.11 of the embedded printer software. Refer to the Release Notes for more recent versions. Options shown in italics are dynamically hidden depending on the printer mode. Calibrate Printer Localization Auto Calibrations Units of Measure AutoBidi Calibration Time Format AutoH2H Calibration...

  • Page 65: Menus

    Menus The printer’s less-often used functions are accessed via the menus. The printer has these menus and functions: • Calibrate Printer (see below) • Printer Settings (page 3-8) • Tools (page 3-12) • Warnings & Actions (page 3-13), shown in Expert Messages Mode only •...

  • Page 66: Printer Settings

    • Manual Calibrations — allows you to calibrate the printer visually, without the printer’s digital imaging sensor. Inaccu- rate judgments by the operator during these tests could result in substandard output. See “Manual Calibrations” on page 4-8 for instructions. • Service Calibrations —...
  • Page 67 • Printing Delay — slows throughput (media advance speed) MEDIA WIZARD to allow the media to cool between passes, preventing warp- ing of rigid media or curling of roll-fed media. • Gutter Settings — determines the appearance of the top and side gutters: •...
  • Page 68 • Trailing Margin — defines the margins on the trailing edge of cut-sheet media, between 6.0 and 24.0 inches (15.3 to 61.0 cm). You can position an image anywhere on the media by setting the right margin (horizontal or x distance from the right edge) and leading margin (vertical or y distance from the leading edge).
  • Page 69 • Maximal with Skew Reporting — same as Maximal, but also reports the amount of skew on the control panel Choose Minimal for fastest throughput, Maximal for greatest precision and skew detection when printing edge-to-edge. • Quality Check — determines how AutoTune errors are handled (see “AutoTune”...

  • Page 70: Tools

    tion values must be reestablished by running AutoSet or manual calibrations. Tools To display this menu, press the Tools button on the Front Page screen. • Turn UV Lamps On/Off — enables you to turn on or off the UV lamps manually instead of automatically when the printer detects a print job.

  • Page 71: User Diagnostics

    • Printheads Procedures • Load Ink in All Heads — fills all printheads with ink, as when initially installing the printer. • Fill Heads with Ink — fills one or more of the printheads you select with ink. • Empty Heads (Fill With Air) — fills the printheads with air. User Diagnostics User Diagnostics presents an interactive troubleshooting pro- gram to diagnose problems before calling technical support.
  • Page 72 3-14 Menus...

  • Page 73: Calibrating The Printer

    Chapter 4 Calibrating the Printer This chapter explains how to calibrate the printer for the best possible output: • When to Calibrate (page 4-2) • AutoJet (page 4-3) • AutoTune (page 4-4) • Auto Calibrations (page 4-6) — AutoBiDi Calibration, AutoH2H (Head-to-Head) Calibration, AutoJet Calibration, Full AutoSet •...

  • Page 74: When To Calibrate

    When to Calibrate When to run Calibration Function When printing a large group of print AutoTune (page 4-4) Automatic jet maintenance during jobs extended printing periods. When loading a new media (but not Linearization (see ONYX docu- Linearization of colors. when loading a new roll of the same mentation) media)

  • Page 75: Autojet

    AutoJet AutoJet detects individual inkjets that are misfiring or not firing at all. During subsequent printing, the printer compensates for these jets by using other jets in their place, ensuring maximum print quality without reducing print speed. You can also identify and map missing jets manually from the Manual Calibrations menu (see “Manual Jet Mapping”...

  • Page 76: Autotune

    AutoTune AutoTune runs AutoJet maintenance automatically at intervals you specify. You can use the Quality Check Mode feature to handle AutoJet errors (with or without user intervention). Auto- Tune is shown on the menu only when roll-fed media is loaded. 1.
  • Page 77 Attended Mode — user must press  (Proceed) to • acknowledge the error and print the job (if one is pend- ing), or  (Cancel) to cancel printing. • OFF — no quality check is performed, all jobs will print. 2.

  • Page 78: Auto Calibrations

    Auto Calibrations The printer’s piezo printheads are aligned at the factory. Head and bidirectional calibrations should be necessary only rarely (for example, when the heads have been moved within the car- riage or replaced). 1. Press the Calibrate key from the Front Page screen, then press Auto Calibrations in the menu.
  • Page 79 Fig. 4-1. Auto calibration patterns and reports Auto Calibrations...

  • Page 80: Manual Calibrations

    Manual Calibrations When you run the calibrations from this menu, you evaluate the calibration test patterns visually and enter the calibration values via the control panel. Note The manual BiDi and X head calibrations are time- consuming and can be error-prone, but is necessary when calibrating transparent media or other media that the printer’s digital image sensor cannot cali- brate.

  • Page 81: Media Feed Calibration

    Media Feed Calibration This calibration allows you to calibrate the accuracy of the media advance. Inaccurate media advance can result in blank spaces between print swaths (too much advance) or overlapping swaths (too little advance). The Media Wizard stores this value by media type, and displays a media feed number (MFN), which you can record for subsequent entry.
  • Page 82 sure and adjust the media advance as needed until the pat- tern is exactly 34 inches (900 mm) long. 10-inch (250 mm) calibration — prints a 10-inch (or 250 mm) test pattern so you can verify its length with an accurate metal ruler.
  • Page 83 To avoid cutting the 10-inch (250 mm) pattern from the media web, copy the marks from the printed pat- tern to the long edge of a letter-size (or A4) sheet of paper. Then measure the transferred marks and adjust the media advance as needed until the marks are exactly 10 inches (250 mm) apart.

  • Page 84: Manual Bidi Registration

    Manual BiDi Registration Bidirectional registration is a method to align each of the print- heads so that dot placement is accurate in both directions along the X axis (along the direction of printhead travel). The bidirectional registration pattern consists of a series of verti- cal lines.
  • Page 85 Use a printer’s loupe to select the pattern, since the lines in the patterns may be difficult to see. Fig. 4-3. BiDi Registration patterns (2 heads per color, six color version shown) 5. Press the  or  control panel keys repeatedly until the number next to the pattern that is closest to aligned perfectly is displayed.
  • Page 86 The control panel message increments the head number by one. 7. Repeat steps 4 through 6 for each of the heads. When you have entered registration values for all heads, the control panel displays this message: Registration Successful 4-14 Manual Calibrations...

  • Page 87: Manual X Head Registration

    Manual X Head Precise positioning of each drop of ink is essential for optimal print quality. This is possible only if you register all printheads in Registration the printhead assembly to each other in the X (along the length of the platen) direction. This is a two-part process: •...
  • Page 88 Use a printer’s loupe or magnifying glass if the patterns are difficult to see. Fig. 4-4. Sample head calibration patterns (1 head per color, six color version shown) 5. Press the  or  control panel keys repeatedly until the number next to the pattern that is closest to aligned perfectly is displayed.
  • Page 89 6. Press  (Proceed). The control panel message increments the head number by one. 7. Repeat steps 4 through 6 for each of the heads. When you have entered registration values for all of the pat- terns, the control panel displays this message: Registration successful.

  • Page 90: Manual Jet Mapping

    Manual Jet Mapping Jets that are missing or misfiring are usually detected by the AutoJet calibration. Alternatively, you can map out jets manually using the Manual Jet Mapping function. You may want to manu- ally map weak or misdirected jets that AutoJet does not substi- tute.
  • Page 91 The printer prints a jet map test pattern. Fig. 4-5. Sample jet mapping pattern (Head 1 shown) If a line segment is missing or broken, the jet number shown next to it is out. A code letter if present provides further infor- mation: R —...

  • Page 92: Report Individual Bad Jets

    • Report individual hard bad jets — enables you to report a “hard” bad jet, which will not be checked or reen- abled by AutoJet. • View current bad jets — lists the bad jets on a given printhead. • Clear individual bad jets —...

  • Page 93: Clear Individual Bad Jets

    Clear Individual Bad Jets When you select Clear Individual Bad Jets, the control panel displays the following prompt: Head 1: Press Proceed to clear a bad jet. 10. Press  and  to select a head number, then press  (Proceed).

  • Page 94: Clear All Bad Jets For A Head

    18. Repeat steps 16 and 17 for each head you want to check for bad jets. 19. When you are finished clearing bad jets, press . The control panel displays the previous menu. Clear All Bad Jets for a Head When you select Clear All Bad Jets for a Head, the control panel displays the following prompt: Head 1: Press Proceed to clear all bad jets.

  • Page 95: Print Jet-Out Lines

    Press  (Proceed). The control panel displays this • message: Do you want to clear the hard bad jets? • Press No to clear the soft bad jets only. • Press Yes to clear both the hard and soft jets. The control panel displays this message: All reported bad jets have been cleared.

  • Page 96: Linearization

    Linearization As the density of an image varies from highlights to shadows, or from lighter tints to darker tints, the printer should accurately reproduce these areas in a predictable, or linear, fashion. The process of linearization (or color calibration) involves printing and reading color test patches, and calibrating the printer to ensure that the expected and printed densities will match.

  • Page 97: Service Calibrations

    Service Calibrations This section shows you how to perform the following service calibrations. For best results, you should perform all three cali- brations in this order: • Head Height • Media Thickness Sensor • Service Station 1. Remove any media that may be loaded across the platen. Calibrating the Head Height 2.
  • Page 98 4. Press the middle button (indicated by the text “Both Ends”) to lower the rail just until the gauge cannot be pulled out. Fig. 4-7. Head height calibration 5. Press the Left End “slow” or “fast” Up button to lower the rail until the gauge can move in and out with slight friction between the carriage and platen.
  • Page 99 The control panel asks whether to accept the current head heights.  12. Press to save the calibration. The control panel prompts you to remove the head height gauge and ensure that the platen is clear of all obstructions. 13. Press  (Proceed) to return the carriage to its home position.

  • Page 100: Calibrating The Media Thickness Sensor

    Calibrating the Media 1. Verify the carriage head height and calibrate the head height if needed. Thickness Sensor 2. From the Front Page, select Calibrations > Service Cali- brations > Media Thickness Sensor Calibration. • If you already entered this calibration from the previous calibration, skip this step and go to the next step.
  • Page 101 7. Turn the sensor clockwise one-half turn to achieve a smaller range reading, or counterclockwise to achieve a larger sen- sor range reading. 8. Tighten the two nuts that secure the media thickness sensor. 9. Press  (Proceed) to run the sensor’s height test again (see step 2 on page 4-28 for instructions).

  • Page 102: Calibrating The Service Station

    Calibrating the 1. From the Front Page, select Calibrations > Service Cali- brations > Service Station Calibration. Service Station • If you already entered this calibration from the previous calibration, skip this step and go to the next step. The control panel prompts you to remove media if any media is loaded.
  • Page 103 4. Press the Carriage Left and Right keys to center the car- riage over the wipers. Fig. 4-10. Center the carriage at these two points over the wipers 5. Press Service Station Up and Down keys to lower the ser- vice station so that the wipers are touching and slightly deflecting against the printheads.
  • Page 104 7. When you are finished calibrating the service station posi- tion, press  (Proceed). The control panel asks whether to accept the current align- ment.  • To accept and save the calibration, press To return to the positioning screen, press  and return to •...

  • Page 105: Technical Specifications

    ppendix Technical Specifications Technical Specifications...

  • Page 106: Specifications

    Specifications • Weight: 581 pounds (264 kg) • Height: 57.1" (145 cm) • Depth: • With tables folded: 27.6" (70 cm) • With tables raised: 81.1" (206 cm) • With tables raised and slider table extended: 127.8" (325 cm) • With tables raised and slider table and wire supports extended: 170.6"...

  • Page 107: Electrical Power

    • Maximum rigid media length — 98 inches (249 cm) • Print width — 0.25 inch (6.35 mm) right and left margin on flexible media. Edge-to-edge printing available on rigid media. • UV energy source — Dual high-energy, user-replaceable UV bulbs.
  • Page 108 • 220 VAC, 16 Amps, single phase, with IEC 60309 wall receptacle (Europe) NEMA L6-20R IEC 60309 locking wall receptacle wall receptacle (North America/Japan) (Europe) North America: If your building receives power from a standard three-phase supply, note that the printer will use only two of the three phases.
  • Page 109 Required power cord (supplied with printer): • North American (UL/CSA approved), length 8.2 feet (2.5 m), • European (Harmonized), length 8.2 feet (2.5 m) Specifications...

  • Page 110: Supplies And Accessories

    Supplies and Consult Océ for an updated listing of supported ink and media. Accessories Use only genuine Océ IJC740 UV Curable inks and printhead flush in the printer. Use of any other inks or cleaning fluids could damage the printer and will void the warranty. Supplies and accessories are available from Océ...

  • Page 111: Troubleshooting

    Appendix B Troubleshooting This appendix explains how to prevent and diagnose printing problems and provides information about getting help from Océ. For other software-specific troubleshooting procedures, refer to your application software documentation or the other documentation listed on page iv of this manual. For answers to RIP-related questions, consult the documentation that accompanies it.

  • Page 112: Troubleshooting Checklist

    Troubleshooting Before you troubleshoot your printer, make sure that it is prop- erly installed as described in Chapter 1, Getting Started. Checklist Follow the steps in this checklist to isolate and resolve printing problems. 1. Does the printer’s power come ON? YES: Go to question 2.
  • Page 113 • The connection from the client to the local area network may not be configured correctly. See your system admin- istrator for assistance. • The cable between your computer or network and the RIP computer may not be securely connected at both ends.
  • Page 114 • Head strike — if the printheads strike the media, press the Purge button on the Front Page screen of the control panel, to expel any ink and other debris introduced into the ink jets by the head strike. Then check how the media is tracking from the supply spool.

  • Page 115: Warranty Claims

    Warranty Claims The printer is covered by a manufacturer’s limited warranty, which includes the printheads. The piezo printheads are designed to remain in service for the life of the printer. The printer incorporates many automatic and manual features for preventing clogs from occurring, and for recovering inkjets that do become clogged (see “Recover Missing Ink Jets”...
  • Page 116 procedures, failure to perform user maintenance as defined in the User Manual or contamination of the ink supply due to improper handling of the ink or ink system • Printheads which have not been properly maintained as defined in the User Manual, and printheads with jet-outs that AutoJet is able to substitute in Production print mode •...

  • Page 117: Diagnostics

    Diagnostics The printer includes a series of self-diagnostic tests designed to help solve printer hardware problems. If one of the tests encoun- ters an error, and error message appears, which includes: • Error code — always write down this code for future refer- ence by Technical Services.

  • Page 118: Océ Technical Services

    Adobe Acrobat format. Océ also offers a variety of technical support options via the World Wide Web and e-mail: World Wide Web http://www.oce-dgs.com E-mail DGS.support@dgs.oceusa.com ...call Océ Technical Services directly. Be ready to supply the If All Else Fails...

  • Page 119: Index

    Index Index-1...
  • Page 120 ESD hazard 2-21 Advance Media Past Brushes 3-5 Apertures 2-5 ATTN key 1-19, 3-5 Fence Auto Calibrations 3-7, 4-6 calibrating 2-22 AutoBiDi Calibration 4-6 Fill Heads With Flush 3-13 AutoH2H Calibration 4-6 Fill Heads With Ink 3-13 AutoJet Calibration 4-3, 4-6 Fine Text 2-3 AutoSet 4-6 Fine Text mode 2-3...
  • Page 121 MFN 4-9 Specifications A-1 Media Feed Number (MFN) 4-9 Standby Wait 3-11 Media Measure Type 3-10 Stiff Roll-Fed Media Handling 3-11 Media Out Sensor 2-8 Supplies and accessories A-6 Media Skew Lines 3-12 Media width 1-20, 2-8 Media Wizard 2-9 Tips 2-21 MFN 4-9 Trailing margin 3-10...
  • Page 122 Index-4...
