Effects - PRESONUS StudioLive RM32AI Owner's Manual

5.0 A Tour of UC Surface Features
5.7 Fat Channel

5.7.9 Effects

Effects (FX) Editor. UC Surface offers two reverbs and two delays,
which can be accessed and edited using the FX Editor by clicking or
tapping the FX Edit button in the selected FX Flex Channel.
When the FX Editor opens, you'll find the following features functions:
FX Label. This displays the current Effects Label (A, B, C, or D).
You'll find the reverbs under FX A and B and the delays under FX C and D.
FX Type Menu. This displays the current Effect Type, and
lets you choose from the list of available options:
REVERBS
Ambiance
Small Room
Bright Room
Small Hall
Bright Hall
Warm Hall
Gated Hall
Large Hall
Plate
FX Parameters. The following parameters are available based
on the type of effect you've selected from the Preset list:
Reverb Parameters
Decay. The time (in seconds) required for the
reflections (reverberation) to die away.
Predelay. This is the time (in milliseconds) between the end of the initial
sound and the moment when the first reflections (reverb) are heard.
Adjusting the predelay changes the apparent size of the room without
having to change the overall decay time. This gives your mix a little more
transparency by leaving space between the original sound and its reverb.
Early Reflections. Early reflections are those that reach the
listener a few milliseconds after the direct signal, and your brain
uses them to identify the size of the room you're in.
If you're trying to simulate a specific type of room, this parameter is
extremely important because it lets you set the level (in decibels) of the early
reflections. The louder the early reflections, the smaller the room will seem.
The following list shows the available parameters for different reverb types:
Gated Halls and Plate reverbs: Decay and Predelay
General Halls and Rooms: Decay, Predelay, and Early Reflection
DELAYS
Mono Delay
Filter Delay
Stereo Delay
Ping Pong Delay
